| Ref | Part Number | Description |
|---|
| 1 |
63-7900-03 |
RACK This part replaces 63-7900. Price: $144.55 |
| 2 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 2 |
510437502 |
BAFFLE, DIVERTER 54"/60" LH Price: $44.99 |
| 3 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 3 |
521979701 |
PULLEY - 5.93 OVER PINS Price: $22.99 |
| 4 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 4 |
574197002 |
BRKT - CHUTE MTG BLACK Price: $59.99 |
| 5 |
525598202 |
PULLEYS This part replaces 525598201. Price: $39.99 |
| 5 |
94-9950 |
CONTROL - STEERING Price: $723.39 |
| 6 |
597087101 |
GSPW PULLEYS This part replaces 510019601. Price: $39.99 |
| 6 |
94-3059 |
HYD TUBE ASM Price: $104.59 |
| 7 |
510131202 |
SHIELD,BELT, 60" ORANGE Price: $59.99 |
| 7 |
94-3061 |
HYD TUBE ASM Price: $73.75 |
| 8 |
575265901 |
BLADE, 19" Price: $24.99 |
| 8 |
94-3090 |
HARNESS - WIRE, MAIN Price: $1,957.31 |
| 9 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 9 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 10 |
237-22 |
O-RING Price: $2.43 |
| 10 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 11 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 11 |
525485801 |
CHUTE, DISCHARGE 48-52 Price: $74.99 |
| 12 |
237-42 |
O-RING Price: $2.78 |
| 12 |
525486002 |
BRKT, CHUTE SUPPORT BLACK Price: $69.99 |
| 13 |
510263701 |
BEARING, IDLER ARM Price: $5.99 |
| 13 |
94-3060 |
HYD TUBE ASM Price: $108.71 |
| 14 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 14 |
94-3062 |
HYD TUBE ASM Price: $81.18 |
| 15 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 15 |
539131781 |
HHFS 3/8-16 X 2 3/4 Price: $4.99 |
| 16 |
510254502 |
SHIELD DUST This part replaces 510254501. Price: $3.99 |
| 16 |
75-2810 |
BRACKET-COLUMN, STEERING Price: $11.01 |
| 17 |
521996502 |
GSPW Nuts This part replaces 521996501. Price: $2.99 |
| 17 |
94-9951 |
COLUMN-STEERING Price: $366.29 |
| 18 |
21-9260 |
COVER-DUST Price: $8.19 |
| 18 |
525464701 |
HHFS 5/16-18 X 3/4 Price: $2.99 |
| 19 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 19 |
98-1471 |
WHEEL-STEERING This part replaces 94-3500. Price: $145.99 |
| 20 |
510022401 |
RHSNB 1/2-13 X 8 GR5 ZD Price: $22.99 |
| 20 |
88-3870 |
COVER-WHEEL Price: $13.83 |
| 21 |
107-2562 |
NUT-HEX This part replaces 94-9952. Price: $19.95 |
| 21 |
510022302 |
Screws This part replaces 510022301. Price: $5.99 |
| 22 |
105-3306 |
SPEEDOMETER KIT, RM6000 SERIES This part replaces 93-4213. Price: $424.47 |
| 22 |
596030801 |
Bolts This part replaces 539102933. Price: $3.99 |
| 23 |
596671401 |
Bolts This part replaces 539100472. Price: $3.99 |
| 23 |
93-1263 |
DECAL-TOWER Price: $46.56 |
| 23 |
94-4573 |
DISCONTINUED Price: Call Us |
| 24 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 24 |
93-7998-03 |
PLATE-INSTRUMENT This part replaces 93-7998. Price: $40.21 |
| 25 |
218-536 |
WASHER-LOCK Price: $1.09 |
| 25 |
596580801 |
Bolts This part replaces 539990209. Price: $2.99 |
| 26 |
3219-14 |
NUT-HEX Price: $0.25 |
| 26 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 539990187. Price: $2.99 |
| 27 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 27 |
539104763 |
U-CLIP 5/16-18 NUT RETAINER Price: $4.99 |
| 28 |
218-533 |
LENS Price: $17.62 |
| 28 |
525612802 |
Screws This part replaces 525612801. Price: $2.99 |
| 29 |
539130638 |
BEARING - 206KRR8 Price: $27.99 |
| 29 |
93-7480 |
LED-MINIATURE Price: $78.50 |
| 30 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 30 |
539119007 |
BLADE BOLT/WASHER Price: $8.99 |
| 31 |
574210602 |
Screws This part replaces 574210601. Price: $2.99 |
| 31 |
87-6620 |
SCREW Price: $1.29 |
| 32 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 32 |
596565001 |
Washers This part replaces 539109600. Price: $2.99 |
| 33 |
233-17 |
KNOB Price: $10.58 |
| 33 |
596433301 |
Bolts This part replaces 539130315. Price: $2.99 |
| 34 |
218-535 |
NUT-HEX Price: $0.34 |
| 34 |
574169601 |
ROLLER, GAUGE .635 BORN Price: $14.99 |
| 35 |
33103-025 |
SCREW-HHF Price: $0.54 |
| 35 |
574196402 |
Tubes This part replaces 574196401. Price: $5.99 |
| 36 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 36 |
574196502 |
Tubes This part replaces 574196501. Price: $17.99 |
| 37 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 37 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 38 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 38 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT This part replaces 539115620. Price: $2.99 |
| 39 |
598490501 |
Nuts This part replaces 539130653. Price: $7.99 |
| 39 |
95-1821 |
SPRING-COMPRESSION Price: $6.71 |
| 40 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 40 |
539130639 |
V-RING, 55MM Price: $5.99 |
| 41 |
322-7 |
SCREW-HH Price: $0.89 |
| 41 |
574722201 |
ASSY, IDLER ARM, PZ Price: $99.99 |
| 42 |
522729701 |
BEARING, IDLER PIVOT Price: $7.99 |
| 42 |
56-7972 |
CLAMP-TUBE Price: $13.55 |
| 43 |
588264802 |
BELT.5V.169.75 This part replaces 574285901. Price: $129.99 |
| 43 |
94-1447 |
STEERING RETURN TUBE ASM Price: $79.79 |
| 44 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 44 |
580943306 |
SPINDLE.ASSY.IRON This part replaces 525836401. Price: $279.99 |
| 45 |
340-68 |
FITTING-TEE, BULKHEAD Price: $36.00 |
| 45 |
522023401 |
WASHER, 3/8 THICK Price: $2.99 |
| 46 |
340-70 |
NUT-LOCK Price: $2.10 |
| 46 |
596435401 |
Bolts This part replaces 539101686. Price: $1.99 |
| 47 |
510015102 |
Pulleys This part replaces 510015101. Price: $49.99 |
| 47 |
92-7495 |
STEERING TUBE ASM Price: $148.27 |
| 48 |
340-117 |
CAP Price: $10.30 |
| 48 |
574202002 |
Hardware This part replaces 574202001. Price: $4.99 |
| 49 |
525465601 |
SPACER, IDLER PIVOT Price: $8.99 |
| 49 |
92-7622 |
DISCONTINUED Price: Call Us |
| 50 |
525310901 |
SPRING, TORSION, IDLER Price: $84.99 |
| 50 |
92-7494 |
REAR STEARING TUBE ASM Price: $150.03 |
| 51 |
574262202 |
Belt Keepers This part replaces 574262201. Price: $5.99 |
| 51 |
92-7606-03 |
BRACKET-BULKHEAD This part replaces 92-7606. Price: $13.64 |
| 52 |
56-7973 |
CLAMP-TUBE Price: $15.56 |
| 52 |
574262102 |
BELT.GUIDE.BLACK Price: $29.99 |
| 53 |
322-6 |
SCREW-HH Price: $0.45 |
| 53 |
596337801 |
Bolts This part replaces 539128101. Price: $4.99 |
| 54 |
596435701 |
Bolts This part replaces 539107271. Price: $2.99 |
| 54 |
75-1490 |
ROD-BRAKE, PARKING Price: $50.23 |
| 55 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 55 |
580943306 |
SPINDLE.ASSY.IRON This part replaces 525836001. Price: $279.99 |
| 56 |
539130643 |
CUP - DEBRIS Price: $6.99 |
| 57 |
539130641 |
SPACER - BEARING Price: $10.99 |
| 58 |
539130637 |
HUB - PULLEY Price: $29.99 |
| 59 |
596840301 |
Shields This part replaces 510262201. Price: $19.99 |
