| Ref | Part Number | Description |
|---|
| 1 |
117-8470 |
LH TRAILING ARM ASM Price: $808.58 |
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 532405012. Price: $5.99 |
| 4 |
119-6200-03 |
HANDLE-LIFT Price: $228.52 |
| 5 |
119-2994 |
CRANK-LIFTING, RAKE Price: $81.90 |
| 5 |
532408703 |
DASH Price: $54.99 |
| 6 |
117-8490-03 |
HANDLE-TRIP Price: $36.41 |
| 7 |
117-8503-03 |
CRANK-BELL, LIFTING LH Price: $74.36 |
| 8 |
105-3450 |
GRIP-LEVER, LIFT Price: $6.25 |
| 9 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 10 |
3233-2 |
SCREW-CARR Price: $1.49 |
| 11 |
119-6188 |
TUBE-PIVOT Price: $4.23 |
| 12 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 13 |
13-0100 |
PIVOT-LINK, RAKE LIFT Price: $61.98 |
| 14 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532411046. Price: $149.99 |
| 15 |
1-633131 |
YOKE-LINKAGE, BRAKE This part replaces 282-22. Price: $14.99 |
| 16 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 17 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 18 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM Price: $129.99 |
| 19 |
95-8603 |
SPACER Price: $8.43 |
| 24 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
117-8506-03 |
MOUNT-GUARD Price: $49.01 |
| 28 |
3232-3 |
BOLT-CARR Price: $2.14 |
| 29 |
114-8417 |
NUT-HF, NI Price: $0.87 |
| 30 |
13-0480 |
SPRING Price: $30.51 |
| 32 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 33 |
3231-29 |
SCREW-CARR Price: $0.68 |
| 34 |
119-6217-03 |
SUPPORT-ARM, TRAILING Price: $12.33 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532196125. Price: $59.99 |
| 35 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 36 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
597652401 |
SERVICE KIT FENDER.TLT.CPH.615 This part replaces 532418714. Price: $219.99 |
| 52 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 58 |
531152601 |
SERVICE KIT DRAWBAR FENDER DRA This part replaces 532412280. Price: $44.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 130 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 138 |
532439747 |
HOLDER.CUP.LT.GREY This part replaces 532402954. Price: $4.99 |
| 150 |
532198512 |
AIR.DUCT.HOOD.TEX.GT.HUSQ Price: $29.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 159 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 180 |
532415063 |
CHASS.WLDMNT.TL.12GA/2P.48/54 Price: $169.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874520520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532404137 |
PLUG.HOLE.DASH.LOWER.12V.BLK Price: $4.99 |
| 196 |
547634701 |
CONSOLE.DECKLIFT.GREY.PKG.KIT This part replaces 532414580. Price: $17.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532416613. Price: $16.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532408606 |
TRIM.HUSQ.TG/CRD.SERVICE Price: $17.99 |
| 239 |
532110452 |
NUT PUSH M Price: $2.99 |
| 287 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
