| Ref | Part Number | Description |
|---|
| 1 |
218-497 |
DISCONTINUED PLEASE SEE NOTES Price: Call Us |
| 1 |
428142 |
Link, Deck Lift - LH Price: Call Us |
| 2 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 2 |
43-6210 |
DISCONTINUED Price: Call Us |
| 3 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 3 |
43-6280 |
DISCONTINUED Price: Call Us |
| 4 |
43-6420 |
BEZEL Price: $57.54 |
| 4 |
43086 |
BUSHING, SPEED ADJUSTMENT LEVER Price: Call Us |
| 5 |
04061-07 |
Pin, Cotter 3/16 x 1.0" Price: Call Us |
| 5 |
40-6410 |
DISCONTINUED X-REF Price: Call Us |
| 6 |
04040-07 |
Flatwasher, 1/2 - .531 x 1.062 x .095 Price: Call Us |
| 6 |
3251-2 |
SCREW-PPH Price: $0.27 |
| 7 |
04021-07 |
HEX LOCKNUT, ELASTIC STOP, 1/2-13 Price: Call Us |
| 7 |
3255-5 |
WASHER-LOCK, EXT Price: $0.25 |
| 8 |
43-6340 |
DISCONTINUED Price: Call Us |
| 8 |
431072 |
Joint, Swivel Price: Call Us |
| 9 |
32122-44 |
SCREW-HH Price: $0.76 |
| 9 |
452962 |
Lift Bellcrank Weldment Price: Call Us |
| 10 |
04041-08 |
Flatwasher, 3/4 (.766 x 1.250 x .060) Price: Call Us |
| 10 |
3217-26 |
NUT-HEX Price: $0.25 |
| 11 |
04050-02 |
RETAINING RING, 3/4" EXTERNAL "E" Price: Call Us |
| 11 |
43-6400 |
DISCONTINUE Price: Call Us |
| 12 |
43-6120 |
DISCONTINUED Price: Call Us |
| 12 |
48114-04 |
GREASE FITTING, STR. 1/4-28 SELF TAP. Price: Call Us |
| 13 |
2412-76 |
DISCONTINUED Price: Call Us |
| 13 |
428143 |
Link, Deck Lift - RH Price: Call Us |
| 14 |
43-6190 |
DISCONTINUED Price: Call Us |
| 14 |
485351 |
Pin Assembly, Deck Height Price: Call Us |
| 15 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 15 |
43986 |
Spacer, Pusharm - Axle Price: Call Us |
| 16 |
3218-1 |
NUT-JAM Price: $1.29 |
| 17 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 18 |
3217-5 |
NUT-HEX Price: $0.25 |
| 18 |
43985 |
Spacer, Pusharm - Deck Price: Call Us |
| 19 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 19 |
424489 |
Bracket, Push Arm Link Price: Call Us |
| 20 |
04001-145 |
Bolt, Hex Head 1/2-13 x 3-1/2" Price: Call Us |
| 20 |
32117-1 |
NUT-INSERT Price: $3.32 |
| 21 |
04001-52 |
Bolt, Hex Hd. 1/2-13 x 2-1/2" (lower) Price: Call Us |
| 21 |
43-6270 |
DISCONTINUED Price: Call Us |
| 22 |
04001-49 |
Bolt, Hex Head 5/16-18 x 3.00" Price: Call Us |
| 22 |
321-10 |
SCREW-HH Price: $1.29 |
| 23 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 23 |
321-4 |
SCREW-HH Price: $0.99 |
| 24 |
43-6260 |
DISCONTINUED Price: Call Us |
| 24 |
44220 |
Rod, Deck Lift Price: Call Us |
| 25 |
04040-09 |
Flatwasher, 5/8" (.656 x 1.312 x .095") Price: Call Us |
| 25 |
3272-48 |
PIN-COTTER Price: $0.25 |
| 26 |
04021-19 |
Locknut, Hex 1/2-13 Center Lock Price: Call Us |
| 26 |
43-8440 |
SPACER Price: $25.63 |
| 27 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 27 |
462887 |
Lever Assembly (incl. Grip) Price: Call Us |
| 28 |
43-6130 |
DISCONTINUED Price: Call Us |
| 29 |
3245-31 |
SCREW-HSH Price: $12.15 |
| 30 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 31 |
43-6170 |
DISCONTINUED Price: Call Us |
| 32 |
321-2 |
SCREW-HH Price: $2.79 |
| 33 |
43-6310 |
DISCONTINUED Price: Call Us |
| 34 |
42-1720 |
CORE-FIELD, COIL Price: $387.41 |
| 35 |
256-273 |
BUSHING-FLANGE Price: $4.55 |
| 36 |
43-6200 |
SPRING-COMPRESSION Price: $20.42 |
| 37 |
144-6182 |
PLATE-CLUTCH This part replaces 43-6110. Price: $25.59 |
| 39 |
43-6320 |
COLLAR Price: $24.71 |
| 40 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 41 |
43-6330 |
DISCONTINUED Price: Call Us |
| 42 |
43-7980 |
DISCONTINUED Price: Call Us |
| 43 |
3249-2 |
DISCONTINUED Price: Call Us |
| 44 |
3217-29 |
NUT-HEX Price: $0.25 |
| 45 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 46 |
28-4110 |
SWITCH-LIGHT Price: $41.30 |
| 47 |
218-498 |
NUT-LOCK Price: $0.68 |
| 485718 |
Grip, |
Deck Transport Lock Price: Call Us 485718 |
