| Ref | Part Number | Description |
|---|
| 1 |
498583 |
CYLINDER ASSY Price: Call Us |
| 1 |
98-7779 |
WATER PUMP ASM Price: $315.48 |
| 2 |
399265 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 3 |
391086 |
SEAL, OIL Price: Call Us |
| 4 |
493304 |
BASE ASSEMBLY, CRANKCASE Price: Call Us |
| 5 |
493457 |
HEAD, CYLINDER #1 Price: Call Us |
| 5A |
493458 |
HEAD CYLINDER #2 Price: Call Us |
| 6 |
98-7784 |
GASKET-PUMP, WATER Price: $22.37 |
| 7 |
271867 |
GASKET, CYLINDER HEAD #1 Price: Call Us |
| 7 |
98-7439 |
BOLT Price: $1.00 |
| 7A |
271868 |
GASKET, CYLINDER HEAD #2 Price: Call Us |
| 8 |
495754 |
BREATHER ASSEMBLY #1 Price: Call Us |
| 8 |
98-7786 |
STUD Price: $1.52 |
| 9 |
27803 |
GASKET, VALVE COVER Price: Call Us |
| 9 |
98-7535 |
WASHER-SPRING Price: $0.32 |
| 10 |
94830 |
SCREW, SEMS Price: Call Us |
| 10 |
98-7534 |
NUT Price: $0.48 |
| 11 |
280225 |
TUBE, BREATHER Price: Call Us |
| 11 |
98-7605 |
BOLT Price: $0.84 |
| 12 |
271188 |
GASKET, CRANKCASE COVER,.005" Price: Call Us |
| 12 |
271189 |
GASKET, CRANKCASE COVER,.009" Price: Call Us |
| 12 |
273390 |
GASKET Price: Call Us |
| 13 |
94565 |
SCREW, CYLINDER HEAD Price: Call Us |
| 15 |
94239 |
PLUG, OIL DRAIN Price: Call Us |
| 16 |
394028 |
CRANKSHAFT Price: Call Us |
| 19 |
399264 |
BUSHING Price: Call Us |
| 20 |
291675 |
SEAL, OIL Price: Call Us |
| 22 |
693973 |
SCREW Price: Call Us |
| 23 |
491180 |
FLYWHEEL & RING GEAR ASSY, MAGNETO Price: Call Us |
| 24 |
222698 |
KEY, FLYWHEEL Price: Call Us |
| 25 |
498584 |
PISTON ASSEMBLY STANDARD SIZE Price: Call Us |
| 25 |
498585 |
PISTON ASSEMBLY .010" OVERSIZE Price: Call Us |
| 25 |
498586 |
PISTON ASSEMBLY .020" OVERSIZE Price: Call Us |
| 25 |
498587 |
PISTON ASSEMBLY .030" OVERSIZE Price: Call Us |
| 26 |
394959 |
RING SET, PISTON, STANDARD SIZE Price: Call Us |
| 26 |
394960 |
RING SET, PISTON,.010" OVERSIZE Price: Call Us |
| 26 |
394961 |
RING SET, PISTON,.020" OVERSIZE Price: Call Us |
| 26 |
394962 |
RING SET, PISTON,.030" OVERSIZE Price: Call Us |
| 27 |
263129 |
LOCK, PISTON PIN Price: Call Us |
| 28 |
498319 |
PIN, PISTON, STD SIZE Price: Call Us |
| 28 |
498320 |
PIN ASSY., PISTON, .005" OVERSIZE Price: Call Us |
| 29 |
394306 |
ROD ASSEMBLY, CONNECTING Price: Call Us |
| 29 |
397158 |
ROD ASSEMBLY, CONNECTING Price: Call Us |
| 32 |
95017 |
SCREW Price: Call Us |
| 33 |
390420 |
VALVE, EXHAUST Price: Call Us |
| 34 |
261528 |
VALVE, INTAKE Price: Call Us |
| 35 |
65906 |
SPRING, INTAKE VALVE Price: Call Us |
| 36 |
26828 |
SPRING, EXHAUST VALVE Price: Call Us |
| 40 |
221596 |
RETAINER, INTAKE VALVE Price: Call Us |
| 41 |
292260 |
RETAINER, EXHAUST VALVE Price: Call Us |
| 42 |
494553 |
KEEPER VALVE Price: Call Us |
| 45 |
261368 |
TAPPET, VALVE Price: Call Us |
| 46 |
214484 |
GEAR, CAM Price: Call Us |
| 47 |
393415 |
OIL SLINGER ASSEMBLY Price: Call Us |
| 48 |
499945 |
SHORT BLOCK Price: Call Us |
| 50 |
213290 |
MANIFOLD, INTAKE Price: Call Us |
| 51 |
271412 |
GASKET, CARBURETOR & INTAKE ELBOE Price: Call Us |
| 51A |
270884 |
GASKET, INTAKE MANIFOLD MOUNTING Price: Call Us |
| 54 |
93208 |
SCREW, SEMS INTAKE MANIFOLDING MOUNTING Price: Call Us |
| 73 |
224781 |
SCREEN Price: Call Us |
| 75 |
222511 |
WASHER SPRING Price: Call Us |
| 78 |
94834 |
SCREW, SEMS Price: Call Us |
| 91 |
693483 |
BODY ASSY Price: Call Us |
| 94 |
491538 |
VALVE ASSEMBLY, CARBURETOR IDLE Price: Call Us |
| 95 |
690718 |
SCREW, SLOTTED Price: Call Us |
| 97 |
693485 |
SHAFT Price: Call Us |
| 98 |
807923 |
KIT Price: Call Us |
| 102 |
693509 |
GASKET Price: Call Us |
| 104 |
693506 |
PIN Price: Call Us |
| 105 |
692078 |
VALUE Price: Call Us |
| 107 |
693482 |
BODY Price: Call Us |
| 108 |
693505 |
VALVE Price: Call Us |
| 109 |
693498 |
SHAFT Price: Call Us |
| 117 |
693499 |
JET Price: Call Us |
| 117 |
693507 |
JET Price: Call Us |
| 121 |
491539 |
CARBURETOR OVERHAUL KIT Price: Call Us |
| 122 |
280319 |
SPACER, CARBURETOR Price: Call Us |
| 125 |
693480 |
CARBURETOR Price: Call Us |
| 130 |
693504 |
VALVE Price: Call Us |
| 133 |
693512 |
FLOAT Price: Call Us |
| 146 |
94196 |
KEY, TIMING GEAR Price: Call Us |
| 147 |
693508 |
JET Price: Call Us |
| 161 |
496599 |
BODY, AIR CLEANER Price: Call Us |
| 163 |
271411 |
GASKET AIR CLEANER Price: Call Us |
| 177 |
271170 |
SEAL, OIL FILLER CAP Price: Call Us |
| 186 |
230318 |
CONNECTOR, IMPULSE PUMP Price: Call Us |
| 187 |
499167 |
LINE Price: Call Us |
| 188 |
94930 |
SCREW Price: Call Us |
| 202 |
262683 |
LINK, GOVENOR Price: Call Us |
| 209 |
262352 |
SPRING, GOVERNOR Price: Call Us |
| 209A |
261563 |
SPRING, GOVERNOR IDLE Price: Call Us |
| 219 |
394348 |
GEAR, GOVERNOR Price: Call Us |
| 220 |
222773 |
WASHER, THRUST Price: Call Us |
| 222 |
491282 |
PLATE ASSEMBLY, GOVERNOR CONTROL Price: Call Us |
| 227 |
491297 |
LEVER ASSEMBLY, GOVERNOR Price: Call Us |
| 235 |
224995 |
SHIELD, SPITBACK Price: Call Us |
| 240 |
394358 |
FILTER, FUEL Price: Call Us |
| 267 |
93897 |
SCREW, SEMS Price: Call Us |
| 278 |
94942 |
WASHER Price: Call Us |
| 279 |
94830 |
SCREW, SEMS Price: Call Us |
| 297 |
94289 |
NUT, WING Price: Call Us |
| 304 |
495588 |
HOUSING, BLOWER Price: Call Us |
| 305 |
690960 |
SCREW, HEX Price: Call Us |
| 306 |
222846 |
SHIELD, CYLINDER Price: Call Us |
| 306A |
223734 |
SHIELD, CYLINDER Price: Call Us |
| 307 |
94930 |
SCREW Price: Call Us |
| 309 |
497596 |
MOTOR, STARTER Price: Call Us |
| 310 |
94003 |
BOLT Price: Call Us |
| 311 |
497608 |
BRUSH SET Price: Call Us |
| 332 |
230674 |
NUT, HEX Price: Call Us |
| 333 |
394891 |
ARMATURE GROUP MAGNETRON IGNITION Price: Call Us |
| 334 |
691061 |
SCREW, ARMATURE MOUNTING Price: Call Us |
| 337 |
802592 |
PLUG, SPARK Price: Call Us |
| 356 |
494705 |
WIRE, STOP Price: Call Us |
| 358 |
495868 |
IN GASKET SET Price: Call Us |
| 359 |
92791 |
WASHERLOCK Price: Call Us |
| 365 |
93970 |
SCREW, SEMS, CARBURETOR MOUNTING Price: Call Us |
| 373 |
90576 |
NUT, HEX Price: Call Us |
| 383 |
89838 |
WRENCH SPARK PLUG Price: Call Us |
| 386 |
693490 |
GASKET Price: Call Us |
| 391 |
693487 |
BODY Price: Call Us |
| 392 |
693491 |
SPRING Price: Call Us |
| 395 |
224816 |
BAFFLE, AIR, CYLINDER #2 Price: Call Us |
| 404 |
223882 |
WASHER, GOVERNOR CRANK, INSIDE Price: Call Us |
| 423 |
691100 |
SCREW Price: Call Us |
| 425 |
94823 |
SCREW ROUND HEAD Price: Call Us |
| 432 |
693492 |
CAP Price: Call Us |
| 434 |
693493 |
COVER Price: Call Us |
| 435 |
693494 |
SCREW Price: Call Us |
| 441 |
222875 |
CLAMP, OIL FILLER Price: Call Us |
| 445 |
394019 |
CARTRIDGE AIR CLEANER Price: Call Us |
| 447 |
93343 |
SCREW, SEMS Price: Call Us |
| 449 |
94694 |
SCREW, HEX HEAD Price: Call Us |
| 474 |
393474 |
STATOR, ALTERNATOR, DUAL CIRCUIT Price: Call Us |
| 482 |
93621 |
SCREW, SEMS Price: Call Us |
| 505 |
92278 |
NUT, HEX Price: Call Us |
| 507 |
398525 |
INSULATOR ASSEMBLY Price: Call Us |
| 510 |
497606 |
DRIVE, STARTER Price: Call Us |
| 513 |
398003 |
CLUTCH ASSEMBLY Price: Call Us |
| 520 |
93722 |
TERMINAL, SPADE Price: Call Us |
| 523 |
494947 |
CAP AND DIPSTICK Price: Call Us |
| 525 |
495348 |
TUBE, OIL FILLER Price: Call Us |
| 544 |
497603 |
ARMATURE, STARTER Price: Call Us |
| 551 |
222892 |
COVER, BREATHER CYLINDER #2 Price: Call Us |
| 552 |
262332 |
LOWER BUSHING, GOVERNOR Price: Call Us |
| 552A |
262331 |
UPPER BUSHING GOVERNOR Price: Call Us |
| 562 |
93853 |
BOLT, GOVERNOR LEVER Price: Call Us |
| 567 |
94811 |
SCREW, HEX HEAD Price: Call Us |
| 569 |
272645 |
GASKET, CRANKCASE Price: Call Us |
| 573 |
491304 |
BACK PLATE ASSEMBLY Price: Call Us |
| 601 |
93053 |
CLAMP, HOSE, GREEN Price: Call Us |
| 615 |
94296 |
RETAINER, E-RING Price: Call Us |
| 615A |
93898 |
RETAINER-GOVERNOR SHAFT Price: Call Us |
| 616 |
491530 |
CRANK, GOVERNOR Price: Call Us |
| 634 |
491287 |
SEAL, GOVERNOR SHAFT Price: Call Us |
| 635 |
66538 |
ELBOW, SPARK PLUG Price: Call Us |
| 637 |
693510 |
WASHER Price: Call Us |
| 643 |
496700 |
CARTRIDGE PLATES AIR CLEANER Price: Call Us |
| 689 |
262337 |
SPRING, COMPRESSION Price: Call Us |
| 697 |
94773 |
SCREW, SEMS Price: Call Us |
| 726 |
391362 |
GEAR, RING Price: Call Us |
| 741 |
262989 |
GEAR, TIMING Price: Call Us |
| 783 |
693059 |
GEAR, PINION Price: Call Us |
| 797 |
94010 |
LOCKNUT, AIR CLEANER MOUNTING Price: Call Us |
| 797A |
693167 |
NUT (BRUSH RETAINER) Price: Call Us |
| 801 |
394860 |
CAP, DRIVE Price: Call Us |
| 802 |
497607 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 803 |
497604 |
HOUSING, STARTER Price: Call Us |
| 807 |
693511 |
SPACER Price: Call Us |
| 822 |
693497 |
WASHER Price: Call Us |
| 837 |
93415 |
SCREW, SEMS Price: Call Us |
| 847 |
495715 |
DIPSTICK & TUBE ASSY Price: Call Us |
| 851 |
493880 |
TERMINAL, IGNITION CABLE Price: Call Us |
| 858 |
693489 |
FUEL PUMP Price: Call Us |
| 859 |
693488 |
CARBURETOR Price: Call Us |
| 861 |
393397 |
PUMP REPAIR KIT Price: Call Us |
| 864 |
398349 |
ADAPTER Price: Call Us |
| 865 |
224774 |
COVER, AIR GUIDE Price: Call Us |
| 865A |
224775 |
COVER, AIR GUIDE Price: Call Us |
| 868 |
497212 |
SEAL, VALVE Price: Call Us |
| 869 |
261463 |
SEAT, INTAKE VALVE, STANDARD Price: Call Us |
| 870 |
262924 |
SEAT, EXHAUST VALVE, STANDARD Price: Call Us |
| 871 |
231218 |
GUIDE, INTAKE VALVE Price: Call Us |
| 871 |
261961 |
GUIDE, EXHAUST VALVE Price: Call Us |
| 877 |
393456 |
DIODE & CONNECTOR ASSY Price: Call Us |
| 878 |
393362 |
HARNESS, ALTERNATOR Price: Call Us |
| 881 |
495901 |
COVER PLATE Price: Call Us |
| 883 |
272250 |
GASKET MUFFLER Price: Call Us |
| 918 |
393815 |
HOSE (CUT TO SUIT) Price: Call Us |
| 934 |
94627 |
SCREW, SEMS 3/4" Price: Call Us |
| 947 |
693495 |
FUEL Price: Call Us |
| 955 |
693513 |
PLUG Price: Call Us |
| 967 |
272490 |
ELEMENT, FILTER Price: Call Us |
| 968 |
225008 |
COVER, AIR CLEANER Price: Call Us |
| 971 |
805540 |
SCREW Price: Call Us |
| 1005 |
498157 |
FAN Price: Call Us |
| 1006 |
224901 |
RETAINER, FAN Price: Call Us |
| 1019 |
496726 |
LABEL KIT Price: Call Us |
| 1036 |
499380 |
LABEL Price: Call Us |
| 1051 |
263080 |
RETAINER Price: Call Us |
| 1058 |
273688 |
OWNER'S MANUAL Price: Call Us |
| 1081 |
280860 |
SEAL, FILLER TUBE Price: Call Us |
| 1090 |
497605 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 1095 |
498047 |
GASKET Price: Call Us |
| 1125 |
94724 |
SCREW Price: Call Us |
| 1132 |
94675 |
SCREW, HEX HEAD Price: Call Us |
| 1136 |
94297 |
SCREW, PAN HEAD Price: Call Us |
| 1137 |
220680 |
WASHER Price: Call Us |
| 1138 |
94298 |
NUT, SQUARE Price: Call Us |
