| Ref | Part Number | Description |
|---|
| 0010 |
1728070SM |
ROD, Lift Handle, 18-7/8" Price: $37.42 |
| 0040 |
1729652SM |
SPRING, Torsion Price: $5.71 |
| 0070 |
703409 |
NUT, 5/16-18, GR5 Price: $4.92 |
| 0100 |
1731417BMYP |
ARM, REAR LIFT ECOAT Price: $12.82 |
| 0101 |
1758146BMYP |
ARM, Rear Lift Price: $25.22 |
| 0110 |
1732426SM |
BOLT-SHLDR 5/16-18 0. Price: $3.62 |
| 0120 |
1727955SM |
ROD, Lift, Lower, 3/8 x 10 Long Price: $17.46 |
| 0150 |
1731894SM |
TRUNNION Price: $8.76 |
| 0160 |
5025394SM |
NUT, 3/8-16 HEX NYLOCK This part replaces 703158. Price: $3.82 |
| 0170 |
703333 |
NUT, 3/8-16 Price: $4.26 |
| 0180 |
703300 |
PIN, 3/32 X 1.6 Price: $3.50 |
| 0190 |
1727985BMYP |
QUADRANT, LIFT HEIGHT This part replaces 1727985SM. Price: $11.44 |
| 0200 |
1730264SM |
DECAL, Height Of Cut Price: $7.90 |
| 0210 |
1960252SM |
BOLT-RD HD SH SQ NK 1 Price: $3.29 |
| 0220 |
703161 |
NUT Price: $3.06 |
| 0230 |
703853 |
WASHER, 0.516IDX1OD Price: $4.49 |
| 0240 |
704054 |
PIN, 3/8-16 Price: $6.36 |
| 0250 |
1666294SM |
SPACER, .385 ID x .6697 OD x .455 Long Price: $4.64 |
| 0260 |
703570 |
CAPSCREW, Hex Head, 5/16-18 x 1 1/4 Price: $3.95 |
| 0270 |
1960044SM |
WASHER-0.312(0.33IDX1 Price: $3.61 |
| 0280 |
1728990ASM |
CLEVIS, Lift Price: $10.52 |
| 0290 |
1727935SM |
SPACER-PIVOT 0.330ID Price: $5.17 |
| 0300 |
1727954SM |
ROD, Lift .375 dia Price: $6.35 |
