| Ref | Part Number | Description |
|---|
| 1 |
710-04483 |
SCREW 1/4-20 x .500 Price: $5.97 |
| 2 |
710-0599 |
Screw, 1/4-20, 0.500 Price: $3.86 |
| 3 |
710-0604A |
Screw, 5/16-18, 0.625 Price: $3.96 |
| 4 |
731-04591A |
Cup Holder Price: $13.84 |
| 5 |
736-0607 |
Lock Washer, 5/16 Price: $3.66 |
| 6 |
783-04587E |
FENDER This part replaces 783-04587A. Price: $299.62 |
| 7 |
783-1489C |
Seat Mounting Bracket This part replaces 783-1489B. Price: $17.99 |
| 8 |
723-04025 |
Foot Pad, Abrasive, RH Price: $29.02 |
| 9 |
723-04026 |
Foot Pad, Abrasive, LH Price: $29.04 |
| 10 |
712-04063 |
Nut, Flange Lock, 5/16-18, GrF Price: $3.56 |
| 11 |
720-04061 |
Knob, 3/8-16, .875 Price: $4.67 |
| 12 |
732-1184 |
Spring, Exten., .84 Dia x 4.6 Lg Price: $10.23 |
| 13 |
738-0296 |
Scr., Shlder, .437 x .268, 5/16-18 Price: $3.93 |
| 14 |
738-04012C |
Shoulder Screw, .625 x .145, 3/8-16 This part replaces 738-04012A. Price: $4.75 |
| 15 |
783-04081A |
Pivot Bracket, Seat Price: $26.56 |
| 16 |
783-0209D |
Lift Bracket, Seat Price: $14.21 |
| 17 |
757P06245 |
MEDIUM BACK SEAT This part replaces 757-04021A. Price: $196.09 |
| 18 |
710-0227 |
Screw, #8-18 x .50 Price: $3.90 |
| 19 |
726-0279 |
Plate, Insulator Price: $3.22 |
| 20 |
925-1303 |
Outer Seat SPring This part replaces 725-1303. Price: $5.58 |
| 21 |
725-1439 |
Spring Switch, Inner Price: $7.18 |
