| Ref | Part Number | Description |
|---|
| 1 |
5-1106-01 |
HINGE-BALL, RH This part replaces 5-1106. Price: $66.76 |
| 1 |
583304901 |
DECK SVCX 38"194251X431 This part replaces 532194251. Price: $279.99 |
| 2 |
5-1104-01 |
SOCKET ASM-HINGE,RH This part replaces 5-1104. Price: $165.99 |
| 3 |
11-9970 |
CENTER FRAME W.A. Price: $2,271.14 |
| 4 |
323-6 |
SCREW-HH Price: $0.66 |
| 5 |
4-8569 |
DISCONTINUED Price: Call Us |
| 6 |
32153-5 |
NUT-HEX Price: $1.59 |
| 6 |
529846401 |
SERVICE.KIT ARM.SUSPENSION.MOW This part replaces 532195186. Price: $14.99 |
| 7 |
5-1116-01 |
DISCONTINUED This part replaces 5-1116. Price: Call Us |
| 7 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 8 |
325-6 |
SCREW-HH Price: $1.42 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 9 |
12-0030 |
DISCONTINUED Price: Call Us |
| 10 |
12-0010 |
U BOLT W.A. Price: $81.76 |
| 11 |
581116302 |
BLADE.2 IN 1.38"DECK.BLACK This part replaces 532193957. Price: $14.99 |
| 11 |
6-0860 |
TRLG&3UNIT DRAWBAR WA*R Price: $840.26 |
| 12 |
5-1108 |
BOLT-HINGE CLAMP Price: $42.89 |
| 13 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 13 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532192872. Price: $49.99 |
| 14 |
5-1107-01 |
HINGE CAP ASM This part replaces 5-1107. Price: $161.71 |
| 14 |
587819701 |
KIT.MANDREL.NONGREASE.TALL This part replaces 532187281. Price: $49.99 |
| 15 |
5-1103-01 |
SOCKET ASM-HINGE, LH This part replaces 5-1103. Price: $146.47 |
| 16 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 17 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 18 |
323-7 |
SCREW-HH Price: $0.65 |
| 19 |
325-5 |
SCREW-HH Price: $1.20 |
| 19 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 20 |
5-1092 |
DISCONTINUED Price: Call Us |
| 21 |
5-1093 |
DISCONTINUED Price: Call Us |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 23 |
5-1094 |
FORK *R Price: $31.80 |
| 23 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 24 |
5-9390 |
LIFT HANDLE *B Price: $45.72 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
3-7877 |
GRIP-HANDLE Price: $10.69 |
| 25 |
532197026 |
SPRING.TORSION.DEFLECT Price: $8.99 |
| 26 |
287-2 |
DISCONTINUED Price: Call Us |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
5-1096 |
CHAIN-LIFT Price: $18.82 |
| 27 |
532401472 |
SHIELD.DEFLECTOR.MWR.38-7/97CM Price: $32.99 |
| 28 |
283-15 |
PIN-CLEVIS Price: $4.07 |
| 29 |
3272-16 |
PIN-COTTER Price: $0.31 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
5-2942 |
SHACKLE Price: $16.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 31 |
325-4 |
SCREW-HH Price: $0.95 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 32 |
12-0120 |
DISCONTINUED Price: Call Us |
| 32 |
531170001 |
SERVICE KIT PULLEY PULLEY.MAND This part replaces 532199789. Price: $17.99 |
| 33 |
5-1091 |
SPACER Price: $4.98 |
| 33 |
596134801 |
Nuts This part replaces 532400234. Price: $1.00 |
| 34 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 35 |
3-7254-01 |
DRAW BAR BRACKET This part replaces 3-7254. Price: $227.92 |
| 36 |
325-10 |
SCREW-HH Price: $1.82 |
| 37 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 38 |
5-1111 |
CASTOR WHEEL BUSHING Price: $10.11 |
| 38 |
532400140 |
BELT KEEPER.MANDREL.38"COATED This part replaces 532199541. Price: $39.99 |
| 39 |
5-1112 |
DRAWBAR PIN Price: $9.77 |
| 40 |
4-8669 |
DISCONTINUED Price: Call Us |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 41 |
12-0060 |
DISCONTINUED Price: Call Us |
| 42 |
5-1105-01 |
HINGE-BALL, LH This part replaces 5-1105. Price: $57.25 |
| 42 |
532198410 |
SPRING.TORSION.BRAKE Price: $4.99 |
| 43 |
5-1087 |
DISCONTINUED Price: Call Us |
| 43 |
532197256 |
SRPING.TORSION.RETAINE Price: $4.99 |
| 44 |
3290-256 |
PIN-HAIR Price: $1.01 |
| 45 |
4-8629 |
DISCONTINUED Price: Call Us |
| 46 |
5-1085 |
DRAWBAR COUPLER *R Price: $231.54 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
5-1086 |
SPRING REBOUND PIN Price: $86.79 |
| 48 |
5-1084 |
DISCONTINUED Price: Call Us |
| 49 |
5-1088 |
DISCONTINUED Price: Call Us |
| 50 |
3272-38 |
PIN-COTTER Price: $3.05 |
| 55 |
531169401 |
SERVICE KIT IDLER.ARM This part replaces 532197249. Price: $5.99 |
| 56 |
532199092 |
SPACER.RETAINER Price: $5.99 |
| 57 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 60 |
532199471 |
ARM BRAKE MOWER RH 38" Price: $14.99 |
| 63 |
532400130 |
BRAKE.ARM.LH.38"TEX.COATED This part replaces 532199470. Price: $14.99 |
| 64 |
532199918 |
LINKAGE.BRAKE.ASM.ZINC This part replaces 532199790. Price: $11.99 |
| 67 |
532403012 |
HANDLE.CLUTCH.CABLE.LT Price: $6.99 |
| 68 |
532408381 |
V-BELT Price: $37.99 |
| 69 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 70 |
532401246 |
CLUTCH.ASM.MANUAL.LT.PRED Price: $32.99 |
| 122 |
531169501 |
SERVICE KIT BELT KEEPER This part replaces 532197258. Price: $4.99 |
| 123 |
531169701 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532197259. Price: $6.99 |
| 144 |
531148901 |
SERVICE.KIT KEEPER BELT KEEPER This part replaces 532193414. Price: $3.99 |
| 145 |
532177968 |
PULLEY.IDLER.FLAT This part replaces 532193197. Price: $27.99 |
| 147 |
532401872 |
SPRING RETURN Price: $4.99 |
| 152 |
532435111 |
CABLE.CLUTCH.MANUAL. This part replaces 532408714. Price: $29.99 |
| 188 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 189 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 199 |
531170401 |
SERVICE KIT BAFFLE BAFFLE.VORT This part replaces 532400095. Price: $14.99 |
| 209 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
