| Ref | Part Number | Description |
|---|
| 1 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG Price: $149.99 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 2 |
92-4037 |
SCREW-HSH Price: $39.56 |
| 3 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 4 |
93-3604 |
GASKET Price: $20.04 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 5 |
93-1396 |
COUPLER Price: $212.18 |
| 6 |
354-78 |
FITTING-STR Price: $49.33 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
75-4400-03 |
ADAPTOR Price: $260.66 |
| 8 |
237-163 |
O-RING Price: $3.02 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
104-0050 |
HYD HOSE ASM Price: $215.76 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
104-0051 |
HYD HOSE ASM Price: $109.35 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT Price: $17.99 |
| 11 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 12 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK Price: $8.99 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 13 |
99-6933 |
PUMP-GEAR Price: $2,267.57 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
532121250 |
SPRING Price: $3.99 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
871110814 |
BOLT.HEX.BLACK Price: $8.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
810040800 |
LOCKWASHER Price: $5.99 |
