Power Unit
Parts (56)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 119-0631 | ROLLER-SHOULDER, PLASTIC Price: $499.90 |
| 2 | 117-0957 | SHAFT-ROLLER, WIEHLE Price: $105.15 |
| 2 | 530042088 | Muffler Spring Price: $1.99 |
| 3 | 530071391 | Kit-Spark Arrestor Price: $7.99 |
| 4 | 530015953 | Screw-Cylinder Price: $1.99 |
| 6 | 530012353 | CYLINDER This part replaces 530069619. Price: $6.99 |
| 7 | 302-5 | FITTING-GREASE Price: $0.59 |
| 7 | 530069616 | Gasket-Cylind./Carb. Price: $6.99 |
| 8 | 530069769 | Kit-Carb. Adaptor Price: $24.99 |
| 9 | 530016014 | Screw Price: $1.99 |
| 10 | 530069616 | Gasket-Carb. Price: $6.99 |
| 12 | 530038747 | Plate-Choke Mounting Price: $1.99 |
| 13 | 530038686 | Shutter-Choke Price: $1.99 |
| 14 | 530052431 | Box-Air Price: $1.99 |
| 15 | 530015887 | Screw Price: $1.99 |
| 16 | 530036569 | Plate-Filter Support Price: $1.99 |
| 17 | 530036575 | Foam-Air Filter Price: $1.99 |
| 18 | 530036568 | Cover-Air Filter Price: $1.99 |
| 19 | 530015880 | Screw Price: $1.99 |
| 20 | 530015852 | Spacer-Choke Price: $1.99 |
| 21 | 530015254 | Washer Price: $1.99 |
| 23 | 530036404 | Ring-Piston Price: $4.99 |
| 24 | 530015162 | Retainer-Piston Pin Price: $1.99 |
| 25 | 530069615 | Assy-Connecting Rod Price: $14.99 |
| 26 | 530069616 | Gasket-Cylinder Price: $6.99 |
| 27 | 530036145 | Spacer-Module Price: $1.99 |
| 28 | 530055160 | Ignition Module Price: $34.99 |
| 29 | 530015954 | Screw Price: $1.99 |
| 30 | 581425901 | SWITCH, GROUND WIRE This part replaces 530014662. Price: $1.99 |
| 31 | 530014663 | Assy-Leadwire Price: $5.99 |
| 35 | 530016386 | SCREW This part replaces 530015810. Price: $5.99 |
| 36 | 530071356 | Kit-Momentary Price: $4.99 |
| 37 | 530027569 | Starter Handle Price: $1.99 |
| 38 | 530069232 | Kit-Rope Price: $3.99 |
| 39 | 530016080 | Screw Price: $1.99 |
| 40 | 530038604 | Coupling-Drive Price: $1.99 |
| 41 | 530023817 | Starter Dog Spring Price: $1.99 |
| 42 | 530015941 | Retain. Ring-C'shaft Price: $1.99 |
| 43 | 530032124 | Outer Bearing Price: $4.99 |
| 44 | 530019179 | C'case Seal Price: $2.99 |
| 45 | 530015945 | Retainer Ring-C'case Price: $1.99 |
| 46 | 530032125 | Inner Bearing Price: $11.99 |
| 47 | 530069685 | Assy.-Fan Hsg/Shroud Price: $22.99 |
| 48 | 530015934 | Screw Price: $1.99 |
| 49 | 530016386 | SCREW This part replaces 530015810. Price: $5.99 |
| 50 | 114-5430 | ROLLER REBUILD KIT Price: $99.53 |
| 50 | 530054536 | Guard-Muffler Price: $1.99 |
| 55 | 545221701 | FLYWHEEL ASSY This part replaces 530069886. Price: $8.99 |
| 56 | 530015828 | Washer-Flat Price: $1.99 |
| 57 | 530015775 | Screw Price: $1.99 |
| 58 | 530027523 | Retainer-Can Price: $2.99 |
| 60 | 545008010 | STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 63 | 530014347 | Assy-Fuel Cap Price: $4.99 |
| 64 | 530095646 | Assy-Fuel Pickup Price: $2.99 |
| 65 | 530069247 | Kit-Fuel Line (Small) Price: $3.99 |
| 66 | 530069216 | Kit-Fuel Line (Large) Price: $3.99 |
