| Ref | Part Number | Description |
|---|
| 1 |
76-6010 |
SPACER Price: $18.94 |
| 1 |
IH-530502-R1 |
SHAFT Not Available Price: |
| 2 |
76-4240 |
DISCONTINUED Price: Call Us |
| 2 |
IH-384655-R1 |
LEVER Not Available Price: |
| 3 |
3274-87 |
SCREW-HSFH Price: $1.09 |
| 3 |
IH-384679-R11 |
PLATE ASSEMBLY Not Available Price: |
| 4 |
74-3640 |
DISC-MIDDLE Price: $195.30 |
| 4 |
IH-384677-R1 |
Bar Not Available Price: |
| 5 |
106-1021 |
DISC-ACTUATING This part replaces 74-3630. Price: $320.62 |
| 5 |
711-3073 |
SPACER-LIFT ARM .508 x .755 Not Available Price: |
| 6 |
3234-30 |
SCREW-HHF Price: $0.41 |
| 6 |
703-0400-0498 |
LOWER HITCH LINK (CUB YELLOW) Not Available This part replaces 703-0400. Price: |
| 8 |
76-8300-03 |
COVER-HOUSING, AXLE This part replaces 76-8300. Price: $14.53 |
| 8 |
IH-529176-R1 |
BRACKET, LIFT LEVER MOUNTING Not Available Price: |
| 9 |
32128-50 |
NUT-FLANGE Price: $1.78 |
| 10 |
84-1620-03 |
PLATE-SUPPORT, AXLE This part replaces 84-1620. Price: $19.85 |
| 11 |
92-9704-03 |
HOUSING-AXLE This part replaces 92-9704. Price: $1,379.19 |
| 12 |
92-9708 |
COLLAR-BEARING Price: $30.60 |
| 13 |
92-9710 |
BEARING Price: $81.81 |
| 14 |
92-9709 |
SPACER-BEARING Price: $75.52 |
| 15 |
32151-76 |
RING-RETAINING, INTERNAL Price: $4.66 |
| 16 |
92-9714 |
DISCONTINUED Price: Call Us |
| 17 |
86-5900 |
TIRE (26X12-12) 8-PLY Price: $229.98 |
| 18 |
104-0161 |
RIM This part replaces 217-124. Price: $404.23 |
| 19 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 20 |
23-7270 |
NUT-LUG Price: $10.37 |
| 21 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 22 |
92-9706 |
SPACER-AXLE, FLANGED Price: $89.64 |
| 23 |
112-8446 |
SEAL-V RING This part replaces 92-9712. Price: $4.26 |
| 24 |
84-1590 |
U-BOLT, FRONT AXLE Price: $23.41 |
| 25 |
325-15 |
SCREW-HH Price: $3.19 |
| 26 |
86-5430 |
DISCONTINUED Price: Call Us |
| 27 |
325-4 |
SCREW-HH Price: $0.95 |
| 28 |
92-7774 |
STUD Price: $47.95 |
| 29 |
92-7775 |
DISCONTINUED Price: Call Us |
| 30 |
92-7776 |
SPRING-EXTENSION Price: $13.09 |
| 31 |
92-7777 |
DISCONTINUED Price: Call Us |
| 32 |
92-7773 |
BALL Price: $13.09 |
| 501538204 |
501538204 |
SPACER Price: $7.99 |
| 502112201 |
502125602 |
MUFFLER This part replaces 502112201. Price: $64.99 |
| 503102302 |
502202101 |
DEFLECTOR This part replaces 503102302. Price: $9.99 |
| 503218201 |
503218201 |
SQUARE HEAD SCREW 5X57 Price: $3.99 |
| 732211422 |
732211401 |
LOCKNUT M5 This part replaces 732211422. Price: $2.99 |
