| Ref | Part Number | Description |
|---|
| 1 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 1 |
596437601 |
Washers This part replaces 539104864. Price: $2.99 |
| 2 |
49-6200-01 |
LEVER-CUTTING This part replaces 49-6200. Price: $100.17 |
| 2 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 539107518. Price: $6.99 |
| 3 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 3 |
532133957 |
WHEEL GAGE DONUT This part replaces 539107610. Price: $11.99 |
| 4 |
93-7629 |
PAD-FOOT, BRAKE This part replaces 49-6170. Price: $25.13 |
| 5 |
49-6150 |
BRAKE FOOT PEDAL WA Price: $44.24 |
| 5 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 539107520. Price: $3.99 |
| 6 |
596134801 |
Nuts This part replaces 539107590. Price: $1.00 |
| 6 |
99-5650 |
MOW PAD & DECAL This part replaces 10-8250. Price: $15.33 |
| 7 |
10-6540 |
FOOT PEDAL WA *R Price: $94.63 |
| 7 |
596434404 |
Bolts This part replaces 539107608. Price: $4.99 |
| 8 |
49-6130 |
BRAKE SHAFT WA Price: $156.07 |
| 8 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 9 |
532405506 |
COVER.MANDREL.RH.46" Price: $19.99 |
| 9 |
99-6857 |
PAD-PEDAL, UPDATE KIT This part replaces 10-8240. Price: $25.77 |
| 10 |
51-0050 |
MOW/LIFT DECAL Price: $10.10 |
| 10 |
532405507 |
COVER.MANDREL.LH.46" Price: $19.99 |
| 11 |
49-6180 |
DISCONTINUED Price: Call Us |
| 11 |
531170601 |
SERVICE KIT BAFFLE CENT This part replaces 532403149. Price: $9.99 |
| 12 |
32121-35 |
PIN-ROLL Price: $0.79 |
| 12 |
531170701 |
SERVICE KIT BAFFLE FRONT This part replaces 532403150. Price: $11.99 |
| 13 |
49-6090 |
LH LIFT PVT/BKRT WA Price: $125.06 |
| 13 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $6.99 |
| 14 |
323-10 |
SCREW-HH Price: $0.89 |
| 14 |
532192557 |
BRKT.DEFLECTOR.38"2005+ Price: $7.99 |
| 15 |
49-6120 |
PAD-FOOTREST Price: $33.37 |
| 15 |
532405357 |
SHIELD.DEFLECTOR.MOWER.46"BLAC Price: $49.99 |
| 16 |
587125201 |
MANDREL.W/SPCR.BRG.SHRT.NONRVL This part replaces 539107515. Price: $49.99 |
| 16 |
84-8290 |
HYD CYLINDER ASSY This part replaces 72-9720. Price: $335.46 |
| 17 |
237-78 |
O-RING Price: $3.85 |
| 17 |
588586601 |
PULLEY.MANDREL.46" This part replaces 539113962. Price: $29.99 |
| 18 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 18 |
539107609 |
TORSION SPRING Price: $4.99 |
| 19 |
237-21 |
O-RING Price: $0.70 |
| 19 |
532105304 |
CAP-SLEEVE LT This part replaces 539107627. Price: $3.99 |
| 20 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 20 |
595297001 |
Rods This part replaces 539110462. Price: $4.99 |
| 21 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 21 |
532110452 |
NUT PUSH M This part replaces 539107626. Price: $2.99 |
| 22 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 22 |
75-9590 |
SPACER-CYLINDER Price: $6.55 |
| 23 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 23 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 24 |
32534 |
Lockwasher Price: Call Us |
| 24 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 25 |
322-1 |
SCREW-HH Price: $0.22 |
| 25 |
574689002 |
ARM, IDLER BLK This part replaces 522706202. Price: $79.99 |
| 26 |
589766102 |
Pulleys This part replaces 539132728. Price: $27.99 |
| 26 |
62-2660 |
FOOT STEP PAD Price: $14.96 |
| 27 |
596790301 |
Bushings This part replaces 539112076. Price: $5.99 |
| 27 |
HY4486 |
NUT UNF 1/2"NYLOC EXT THIN5/16 This part replaces 283-8. Price: $1.36 |
| 28 |
115-3259 |
KIT-SERVICE, PIN This part replaces 10-6110. Price: $39.21 |
| 28 |
539109562 |
WASHER 3/8 X 3/4 X .187 TK Price: $3.99 |
| 29 |
595901401 |
Bolts This part replaces 539100145. Price: $2.99 |
| 29 |
93-2096 |
LEVER-BRAKE This part replaces 71-1510. Price: $89.45 |
| 30 |
10-7820 |
PIVOT HINGE ASM Price: $504.57 |
| 30 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 31 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 31 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 539990799. Price: $2.99 |
| 32 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 32 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
| 33 |
282-2 |
YOKE Price: $30.04 |
| 33 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 34 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 34 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 539990122. Price: $2.99 |
| 35 |
3220-2 |
NUT-JAM Price: $0.50 |
| 35 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 36 |
27-2270 |
ROD-ADJUSTMENT, BRAKE Price: $32.18 |
| 36 |
539117245 |
V-BELT Price: $54.99 |
| 37 |
10-8100-01 |
STRAP-SHAFT, BRAKE This part replaces 10-8100. Price: $34.17 |
| 37 |
539108461 |
BOLT 1/4-20 X 1/2 HWST Price: $2.99 |
| 38 |
256-32 |
BUSHING Price: $9.99 |
| 38 |
596989801 |
Springs This part replaces 539120920. Price: $7.99 |
| 39 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 39 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 539107630. Price: $3.99 |
| 40 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 40 |
532137729 |
SCREW.1/4-20X5/8 This part replaces 539107631. Price: $3.99 |
| 41 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 41 |
596435201 |
Bolts This part replaces 539104870. Price: $2.99 |
| 42 |
595901901 |
Nuts This part replaces 539119124. Price: $2.99 |
| 43 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 43 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 44 |
3290-221 |
WASHER-SPRING Price: $3.12 |
| 44 |
598727201 |
Decks This part replaces 522744301. Price: $299.99 |
| 45 |
532416405 |
COUPLING.QUICK CONNECT Price: $8.99 |
| 46 |
539113224 |
DECAL, CAUTION Price: $4.99 |
| 46 |
62-2390-01 |
BAR-LH LIFT ARM This part replaces 62-2390. Price: $109.59 |
| 47 |
546540601 |
DECAL, DECK 2 BLADE MOWERS This part replaces 510240201. Price: $1.99 |
| 47 |
57-7650 |
SPRING-TORSION Price: $11.81 |
| 48 |
539913010 |
DECAL, CPSC Price: $3.99 |
| 48 |
63-8750 |
PIN-PIVOT Price: $4.20 |
| 51 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 52 |
62-2460 |
LIFT ARM ASM Price: $130.13 |
| 56 |
147-3120 |
BALL JOINT RECEIVER ASM This part replaces 8-7710. Price: $16.35 |
| 57 |
3220-3 |
NUT-HJ Price: $0.28 |
| 58 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 59 |
138-6311 |
ARM-PULL-ASSEMBLY-LH This part replaces 52-2740. Price: $29.91 |
| 60 |
3-1506 |
BUSHING Price: $2.42 |
| 61 |
21-8470 |
SHAFT-ROLLER Price: $62.10 |
| 62 |
131-4295 |
PIN-PIVOT This part replaces 10-6090. Price: $51.39 |
| 63 |
62-5070 |
DECAL-WARNING Price: $5.59 |
| 64 |
12-9050 |
DISCONTINUED Price: Call Us |
| 65 |
10-9090 |
DISCONTINUED Price: Call Us |
| 66 |
133-2337 |
ROLLER ASM This part replaces 52-2720. Price: $176.14 |
| 67 |
133-2378 |
BEARING This part replaces 251-141. Price: $23.28 |
| 68 |
3290-317 |
WASHER-SPRING Price: $1.40 |
| 69 |
138-6303 |
ARM-PULL-ASSEMBLY-RH This part replaces 52-2750. Price: $29.91 |
| 70 |
11-0160 |
ROLLER SHAFT SCREW ASM Price: $28.16 |
| 71 |
86-9810-01 |
L/H PULL FRAME ASM This part replaces 47-5970. Price: $327.77 |
| 72 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 73 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 74 |
10-7890 |
DISCONTINUED Price: Call Us |
| 75 |
10-8140 |
SPRING-LATCH, BRAKE Price: $18.38 |
| 76 |
10-7850 |
LATCH-BRAKE, PARKING Price: $111.12 |
| 77 |
10-7880 |
DISCONTINUED Price: Call Us |
| 78 |
74-3990 |
GREENSMASTER 3000 DECAL Price: $15.06 |
| 80 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 81 |
27-2830 |
PARKING BRAKE DECAL Price: $8.92 |
| 82 |
56-7970 |
CLAMP-TUBE Price: $10.02 |
| 83 |
32141-111 |
NUT-ADJUSTING Price: $6.09 |
| 84 |
3229-11 |
SCREW-CARR This part replaces 3229-22. Price: $0.99 |
| 85 |
10-6300 |
MOW PEDAL WA Price: $76.13 |
| 86 |
321-24 |
SCREW-HH This part replaces 321-23. Price: $2.31 |
| 87 |
49-6070 |
DISCONTINUED Price: Call Us |
| 88 |
49-6110-01 |
GUARD-ROD, TRANSMISSION This part replaces 49-6110. Price: $65.82 |
