MOWER LIFT / DECK LIFT
Parts (29)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 125-7247 | CASE ASM Price: $631.77 |
| 2 | 532422027 | SHAFT.ASM.CROSS.LIFT This part replaces 532195223. Price: $69.99 |
| 3 | 125-6944 | SEAL-OIL Price: $31.03 |
| 4 | 125-6936 | FLANGE Price: $508.81 |
| 5 | 125-6919 | STUD Price: $6.42 |
| 6 | 125-6972 | COVER-FILLER Price: $10.14 |
| 7 | 125-6977 | COVER Price: $8.10 |
| 7 | 532411555 | GRIP.HANDLE.LIFT.PVC.BLACK Price: $7.99 |
| 8 | 125-7107 | PIPE Price: $8.10 |
| 9 | 125-6909 | O-RING Price: $2.55 |
| 10 | 125-6957 | O-RING Price: $3.51 |
| 10 | 532196314 | SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 10 | 596322601 | Nuts This part replaces 873930600. Price: $2.99 |
| 11 | 125-7174 | WASHER-SEAL Price: $5.45 |
| 12 | 125-7197 | O-RING Price: $2.55 |
| 13 | 125-7214 | BOLT Price: $3.77 |
| 14 | 125-7214 | BOLT Price: $3.77 |
| 15 | 125-7216 | BOLT Price: $3.48 |
| 16 | 125-7221 | BOLT Price: $4.09 |
| 17 | 125-7224 | BOLT Price: $4.09 |
| 18 | 125-7229 | NUT Price: $3.12 |
| 19 | 125-6950 | COVER Price: $13.53 |
| 20 | 125-7199 | O-RING Price: $2.20 |
| 87 | 532194209 | PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 88 | 532410710 | SPRING.LIFT.ASSIST Price: $9.99 |
| 89 | 819171912 | WASHER Price: $3.99 |
| 91 | 589464807 | Links This part replaces 532195181. Price: $14.99 |
| 97 | 817000612 | SCREW, 3/8-16X3/4 Price: $3.99 |
| 98 | 581506903 | Links This part replaces 532195270. Price: $9.99 |
