| Ref | Part Number | Description |
|---|
| 1 |
112-1705 |
ROLLER-WIEHLE, PLASTIC Price: $276.69 |
| 1 |
532170551 |
CONTROL.THROTTLE/CHOKE.BLACK Price: $22.99 |
| 2 |
112-1707 |
SHAFT-ROLLER, WIEHLE Price: $73.35 |
| 2 |
817240408 |
SCREW Price: $3.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
532137352 |
MUFFLER.LT.BRIGGS.14HP.IC/OHV Price: $29.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 6 |
114-5411 |
NUT-LOCK, BEARING This part replaces 114-3745. Price: $24.46 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 13 |
532272293 |
Gasket Eng 1 313 Id Tin Plated (AYP part number) This part replaces 532165291. Price: $7.99 |
| 23 |
532169837 |
SHIELD.BROWNING.DBR.GUARD Price: $7.99 |
| 31 |
532430646 |
TANK ASM.FRONT.CARB.1.5GA.E10 This part replaces 532420721. Price: $279.99 |
| 32 |
532430219 |
CAP ASM.FUEL.2.25"FRT.CARB Price: $39.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
532401137 |
LINE.FUEL.20"FRONT.EMI Price: $9.99 |
| 40 |
532124028 |
GROMMET T Price: $3.99 |
| 72 |
532192334 |
SCREW.SOCKET HD.5/16-1 Price: $2.99 |
| 109 |
532448562 |
KIT.PURGE.LINE.55" This part replaces 532414119. Price: $14.99 |
| 111 |
532448562 |
KIT.PURGE.LINE.55" This part replaces 532414119. Price: $14.99 |
| 114 |
532414116 |
CRADLE.CANISTER.CARBON Price: $19.99 |
