| Ref | Part Number | Description |
|---|
| 1 |
09267300 |
PIN, PIVOT/TRUNNION Price: $6.45 |
| 2 |
09289300 |
ROD, BRAKE Price: $71.45 |
| 3 |
08328500 |
SG-COMP .142 X .710 X 2.00 Price: $18.45 |
| 4 |
06401013 |
WSHR-FLT .406X.812X.065 ZCC This part replaces 06436200. Price: $0.95 |
| 5 |
06500917 |
NUT-STD .375-16 G2 ZCC This part replaces 06529400. Price: $0.95 |
| 6 |
00258800 |
WMT, BRAKE CROSS SHAFT Price: $88.95 |
| 7 |
06700223 |
PIN, HAIR #225 .072X1.09 This part replaces 06714800. Price: $0.45 |
| 8 |
09267700 |
SLIDE, INTERLOCKING BRAKE Price: $20.45 |
| 9 |
05534100 |
BUSHING, FLANGED (WITH HOLE) Price: $36.95 |
| 10 |
05709200 |
RG-RTNG-EXT .625X.050 Price: $2.45 |
| 11 |
05518400 |
BSHG-FLG .762X1.0X.580X1.48 NY Price: $4.45 |
| 12 |
05503100 |
BSHG-FLG.500X.750X.750X1.000BR Price: $8.95 |
| 13 |
05500900 |
BSHG-SLV .750X1.000X.750 Price: $8.95 |
| 14 |
06608700 |
KEY-WDRF .19X.75 HRD #9 This part replaces 124549. Price: $0.95 |
| 15 |
00258600 |
WMT, BRAKE ARM Price: $61.45 |
| 16 |
05714600 |
RG-RTNG-EXT .689X.078 Price: $2.45 |
| 17 |
09268000 |
WMT, MECHANICAL BRAKE Price: $148.45 |
| 19 |
00277400 |
WMT, BRAKE ACTUATING This part replaces 09269300. Price: $76.95 |
| 20 |
06608400 |
KEY-WDRF .13X.63 HRD#5 Price: $2.45 |
| 21 |
05901803 |
BLT, HEX .31-18X1.25 G5 ZCC This part replaces 05947500. Price: $2.45 |
| 22 |
05717100 |
RG-RTNG-EXT .500X.050 (SNAP) Price: $2.45 |
| 23 |
07505200 |
KNOB-STEERING LOCK This part replaces 039360. Price: $19.95 |
| 24 |
09268400 |
LINKAGE, BRAKE ACTUATING Price: $26.95 |
| 25 |
09275900 |
INTERLOCK, SAFETY SWITCH Price: $15.45 |
| 26 |
09200600 |
PAD SET, DISK BRAKE Price: $46.95 |
| 27 |
06500904 |
NUT-LK-TOP-FLG .312-18 GF ZCC This part replaces 06543100. Price: $0.95 |
| 28 |
09268300 |
LINKAGE, BRAKE ACTUATING Price: $26.95 |
| 29 |
09314100 |
SLEEVE,SLIDING,ASSEMBLY Price: $484.45 |
| 30 |
06401112 |
WSHR, FLT .505X1.00X.062 ZCC This part replaces 06439200. Price: $0.95 |
| 31 |
09268100 |
WMT, PARKING BRAKE HUB Price: $132.95 |
| 32 |
07012600 |
FTG-LUBE .25-28X.256 YWZC Price: $3.45 |
