| Ref | Part Number | Description |
|---|
| 1 |
3219-14 |
NUT-HEX Price: $0.25 |
| 1 |
532186093 |
WHEEL.STEERING.LEGND2.GRY This part replaces 532193943. Price: $89.99 |
| 2 |
38-1670 |
MTNG BRKT W/38-1660 Price: $16.06 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
3253-17 |
WASHER-LOCK Price: $0.25 |
| 4 |
3290-134 |
SCREW Price: $0.27 |
| 4 |
538691101 |
SPINDLE.WLDMT.LH.16IN.TEX.X431 This part replaces 532403089. Price: $19.99 |
| 5 |
38-1650 |
FUEL GAUGE Price: $185.83 |
| 5 |
538691001 |
SPINDLE.WLDMT.RH.16IN.TEX.X431 This part replaces 532403090. Price: $19.99 |
| 6 |
44-2220 |
LEAD WIRE ASM Price: $9.24 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
233-35 |
KNOB Price: $8.06 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
218-533 |
LENS Price: $17.62 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
27-2360 |
SWITCH Price: $46.56 |
| 11 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 12 |
83-0820 |
GAUGE - AMMETER This part replaces 38-1660. Price: $76.09 |
| 13 |
218-539 |
DISCONTINUED Price: Call Us |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
42-9190 |
GLOW LAMP (F/W & PPP) Price: $89.59 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
26-6750 |
ENG TEMP SWITCH GAGE Price: $332.79 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
43-3970-03 |
INSTRUMENT PANEL This part replaces 43-3970. Price: $111.29 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
218-473 |
BOOT-SWITCH Price: $17.61 |
| 18 |
26-6740 |
TEMP RESET RELAY Price: $165.84 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
6-1659 |
SWITCH & BOOT ASM Price: $78.15 |
| 21 |
43-4000 |
CIRCUIT BREAKER Price: $116.55 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
3250-17 |
SCREW-PPH Price: $1.76 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
43-3990 |
CONTROL-THROTTLE Price: $49.39 |
| 24 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 25 |
43-0410 |
REGULATOR (F/W & PPP) Price: $416.45 |
| 26 |
3296-12 |
NUT-LOCK, NI Price: $1.29 |
| 26 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 27 |
43-1880 |
CONT UNIT (F/W ENG&PPP) Price: $434.93 |
| 28 |
3290-424 |
SCREW-SHH Price: $2.54 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 30 |
321-4 |
SCREW-HH Price: $0.99 |
| 31 |
3255-7 |
WASHER-LOCK/EXT Price: $1.39 |
| 32 |
3217-6 |
NUT-HEX Price: $1.19 |
| 33 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 34 |
43-3820 |
BUZZER SPACER Price: $2.80 |
| 35 |
3256-14 |
WASHER-FLAT Price: $0.39 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
119-2865 |
KIT-GM300 BUZZER, LOW OIL PRESSURE This part replaces 22-7820. Price: $135.43 |
| 37 |
3217-26 |
NUT-HEX Price: $0.25 |
| 38 |
3255-5 |
WASHER-LOCK, EXT Price: $0.25 |
| 39 |
218-515 |
BRACKET Price: $12.11 |
| 40 |
120-2244 |
HOURMETER This part replaces 12-9990. Price: $48.06 |
| 41 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 42 |
63-7590 |
RELAY Price: $78.15 |
| 43 |
70-1190 |
DISCONTINUED Price: Call Us |
| 44 |
321-6 |
SCREW-HH Price: $0.25 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
