| Ref | Part Number | Description |
|---|
| 1 |
125-3488 |
GROOMER SHAFT ASM Price: $440.69 |
| 1 |
532850735 |
Control Bar (AYP part number) Price: $4.69 |
| 2 |
140-5606 |
SPACER-SS This part replaces 107-4430. Price: $2.49 |
| 2 |
532850724 |
Handle Grip (AYP part number) Price: $11.99 |
| 3 |
140-5581 |
BLADE-GR GROOMER, HELIX (0.028") This part replaces 110-2333. Price: $3.07 |
| 3 |
532194788 |
GUIDE.ROPE.STD.BLK.ZIN This part replaces 532132001. Price: $3.99 |
| 4 |
532145642 |
Upper Handle (AYP part number) This part replaces 532153817. Price: $37.99 |
| 5 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532153028. Price: $54.99 |
| 6 |
532183724 |
KNOB.HANDLE.KIT.SERVICE This part replaces 532131959. Price: $6.99 |
| 7 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 532063601. Price: $1.99 |
| 8 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $3.99 |
| 9 |
817021008 |
Screw, Hex Hd. Tap #10-24 x 1/2 (AYP part number) This part replaces 532750097. Price: $1.99 |
| 10 |
532130861 |
Engine Zone Control Cable Price: $8.99 |
| 11 |
532158755 |
SCREW.PAN.HEAD This part replaces 532144929. Price: $3.99 |
| 12 |
532051793 |
Hairpin Cotter (AYP part number) Price: $3.99 |
| 13 |
532183724 |
KNOB.HANDLE.KIT.SERVICE This part replaces 532136376. Price: $6.99 |
| 14 |
532077400 |
Hubcap (AYP part number) Price: $3.99 |
| 15 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $2.99 |
| 16 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 17 |
532801847 |
Wheel & Tire Assembly Price: $38.12 |
| 18 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532142748. Price: $3.99 |
| 19 |
532062335 |
Belleville Washer (AYP part number) Price: $6.99 |
| 20 |
532141730 |
Selector Spring (AYP part number) Price: $3.99 |
| 21 |
532701037 |
Selector Knob (AYP part number) Price: $2.99 |
| 22 |
532145935 |
ARM.AXLE.ASM.BZP This part replaces 532149857. Price: $3.99 |
| 24 |
532083816 |
Screw (AYP part number) Price: $3.99 |
| 25 |
532401629 |
SPACER.HEIGHT.ADJUSTER This part replaces 532146630. Price: $2.99 |
| 26 |
532700325 |
Wheel Adjusting Bracket (R.F./L.R.) (AYP part number) Price: $2.99 |
| 28 |
532192983 |
KIT HANDLE BRACKET LH/RH This part replaces 532153026. Price: $29.99 |
| 29 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $4.99 |
| 30 |
532153027 |
Handle Bracket Assembly (Left) (AYP part number) Price: $7.99 |
| 31 |
532111190 |
Clamp (AYP part number) Price: $3.99 |
| 32 |
873680600 |
LOCKNUT This part replaces 532751592. Price: $1.99 |
| 33 |
532007192 |
WIRE TIE This part replaces 532151517. Price: $3.99 |
| 34 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $2.99 |
| 35 |
532851084 |
Hex Head Screw 3/8-24 x 1-3/8 Price: $2.99 |
| 36 |
539990118 |
SLW 3/8 STD This part replaces 532850263. Price: $1.99 |
| 37 |
532851074 |
Hardened Washer (AYP part number) Price: $2.99 |
| 39 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532851514. Price: $11.99 |
| 40 |
532150406 |
Hex Head Thread Rolling Screw 3/8-16 x 1 (AYP part number) Price: $3.99 |
| 43 |
532700417 |
Throttle Control Price: $12.99 |
| 45 |
532428450 |
KIT.O-RING/WASHER This part replaces 532057143. Price: $5.99 |
| 46 |
532140544 |
Rear Skirt (AYP part number) Price: $10.99 |
| 47 |
532751649 |
Skirt Rod (AYP part number) Price: $3.99 |
| 48 |
532700279 |
Retainer Clip (AYP part number) Price: $3.99 |
| 49 |
532140862 |
Mulcher Door Assembly (Complete) (AYP part number) Price: $24.94 |
| 51 |
532087593 |
Hinge Door Bracket Assembly (AYP part number) Price: $3.99 |
| 52 |
532087590 |
Hinge Rod (AYP part number) Price: $5.50 |
| 53 |
532087589 |
Torsion Spring (AYP part number) Price: $3.99 |
| 54 |
812000014 |
E-Ring (AYP part number) Price: $3.99 |
| 55 |
532140864 |
Door Latch (AYP part number) Price: $5.46 |
| 56 |
532752118 |
Deflector Mulcher Price: $13.99 |
| 57 |
532751399 |
Bracket Grass Catcher Frame (AYP part number) Price: $8.99 |
| 58 |
874180410 |
Truss Head Screw Price: $3.99 |
| 532145665 |
Operator's |
Manual (English) Price: Call Us 532145665 |
| 532145666 |
Operator's |
Manual (French) (AYP part number) Price: Call Us 532145666 |
