| Ref | Part Number | Description |
|---|
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD This part replaces 532416480. Price: $69.99 |
| 1 |
98-9339 |
GAUGE-FUEL Price: $115.28 |
| 2 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 3 |
233-33 |
KNOB Price: $13.70 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 4 |
94-5626 |
FLEXIBLE DRAW LATCH ASM Price: $42.59 |
| 5 |
112-6561 |
WARNING LIGHT ASM This part replaces 98-9306. Price: $121.84 |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
98-9308 |
GAUGE-TEMPERATURE Price: $112.90 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
93-5961 |
BOOT-LEVER Price: $56.35 |
| 8 |
104-9316 |
SCREW-TAP, PPH Price: $0.87 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
104-9261 |
DISCONTINUED Price: Call Us |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
104-9296 |
DECAL-CONTROL Price: $27.94 |
| 11 |
104-9251-03 |
PLATE-INSTRUMENT Price: $95.17 |
| 12 |
99-8352 |
SWITCH-BACKLAP, MASTER Price: $91.81 |
| 13 |
322-8 |
SCREW-HH Price: $1.26 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 15 |
93-5547 |
BUSHING-NYLON Price: $6.15 |
| 16 |
104-1499-03 |
BRACKET-BLOCK, FUSE Price: $43.35 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 532408219. Price: $34.99 |
| 17 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 18 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 19 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
104-0027 |
BOX-CONTROL Price: $196.04 |
| 21 |
105-8289 |
SPRING-TORSION This part replaces 93-5509. Price: $15.05 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532420537. Price: $14.99 |
| 22 |
94-6767 |
DECAL-FUSES Price: $11.45 |
| 23 |
104-9298 |
DECAL-CONTROLLER Price: $6.16 |
| 24 |
104-1496 |
HINGE-PIN Price: $13.22 |
| 25 |
104-1497 |
HINGE-RECEIVER Price: $13.90 |
| 26 |
139-5984 |
CONTROLLER-ELECTRONIC This part replaces 92-5720. Price: $2,183.63 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 27 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 28 |
321-14 |
SCREW-HH Price: $0.55 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 29 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 30 |
322-3 |
SCREW-HH Price: $0.79 |
| 32 |
100-3894 |
HARNESS-ELECTRICAL Price: $1,713.76 |
| 33 |
94-6343 |
DECAL-IDENTIFICATION, WIRE Price: $6.86 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 36 |
115-5357-03 |
BRACKET-JOYSTICK This part replaces 93-5991-03. Price: $35.61 |
| 37 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 38 |
3290-354 |
NUT-SPEED Price: $9.99 |
| 39 |
3290-329 |
SCREW-PPH Price: $0.22 |
| 40 |
61-2990 |
SPACER Price: $33.75 |
| 41 |
32128-33 |
NUT-HF Price: $0.25 |
| 42 |
111332 |
SWITCH Price: $10.99 |
| 45 |
819183812 |
WASHER 9/16"ID, 2 3/8"OD Price: $7.99 |
| 51 |
873940800 |
NUT.HEX.1/2-20 Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532197246 |
BRKT.UPSTOP.GT/LT.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
