| Ref | Part Number | Description |
|---|
| 1 |
1940385 |
Frame Price: Call Us |
| 2 |
1946434 |
Brushes Price: Call Us |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $49.99 |
| 3 |
1926618 |
Holder (Insulated) Price: Call Us |
| 4 |
1926622 |
Springs Price: Call Us |
| 5 |
1940477 |
Holder (Ground) Price: Call Us |
| 6 |
1938058 |
Brush Holder Pin Price: Call Us |
| 7 |
1960864 |
Lead (Ground) Price: Call Us |
| 8 |
120361 |
Brush Holder Nut Price: Call Us |
| 9 |
453435 |
Lockwasher Price: Call Us |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 Price: $7.99 |
| 10 |
1928015 |
Support Package Price: Call Us |
| 11 |
453468 |
Screw Price: Call Us |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $199.99 |
| 12 |
1955946 |
Grommet Price: Call Us |
| 12 |
532402980 |
PULLEY.ENGINE.ENX Price: $54.99 |
| 13 |
132255 |
Screw Price: Call Us |
| 14 |
9421423 |
Lockwasher Price: Call Us |
| 15 |
1114356 |
Switch Price: Call Us |
| 15 |
532433007 |
TANK.ASM.FRT.2.5 GAL.W/CAP.EPA Price: $119.99 |
| 16 |
1958679 |
Spring Plunger Price: Call Us |
| 17 |
1941113 |
Plunger Price: Call Us |
| 18 |
1951567 |
Lever Shift Price: Call Us |
| 18 |
581176101 |
CAP.FUEL.2 WAY VENT Price: $34.99 |
| 19 |
455106 |
Lever Pin Price: Call Us |
| 20 |
1932197 |
Lever Stud Price: Call Us |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN. Price: $19.99 |
| 21 |
1965225 |
Drive Housing (Incl. Bushing) Price: Call Us |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 22 |
1926640 |
Nut Price: Call Us |
| 23 |
9421424 |
Lockwasher Price: Call Us |
| 24 |
1838568 |
Thrust Collar Price: Call Us |
| 25 |
1928022 |
Retainer Ring Price: Call Us |
| 26 |
1928021 |
Collar Stop Price: Call Us |
| 27 |
809593 |
Pin Dowl Price: Call Us |
| 28 |
1941157 |
Drive Assembly Price: Call Us |
| 28 |
532137040 |
LINE.FUEL.20 Price: $3.99 |
| 29 |
1913960 |
Screw Price: Call Us |
| 29 |
532131780 |
Kit Spark Arrestor 1 25 Price: Call Us |
| 30 |
1950417 |
Armature Price: Call Us |
| 31 |
1914842 |
Washer-Brake Price: Call Us |
| 32 |
1955951 |
Coil Assembly Price: Call Us |
| 33 |
274738 |
Screw Price: Call Us |
| 34 |
1887021 |
Pole Shoe Price: Call Us |
| 35 |
1960908 |
Bolt Price: Call Us |
| 36 |
274875 |
Screw Price: Call Us |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $4.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
532159955 |
RP.EXHAUST.TUBE.LH.BS/TWIN This part replaces 581881101. Price: $27.99 |
| 71 |
532160589 |
RP.EXHAUST.TUBE.RH.BS/TWIN This part replaces 581881001. Price: $39.99 |
| 79 |
532183906 |
SCREW.SOCKET.HEAD.5/16-18 Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
532179953 |
BOLT HEX 7/16-20 X 3.75 GR. 5 Price: $3.99 |
| 87 |
532171877 |
BOLT, 5/16-18 X 1 3/4 Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 96 |
819091416 |
WASHER Price: $3.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
