| Ref | Part Number | Description |
|---|
| 1 |
98-9339 |
GAUGE-FUEL Price: $115.28 |
| 2 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 3 |
233-42 |
KNOB Price: $12.88 |
| 4 |
94-5626 |
FLEXIBLE DRAW LATCH ASM Price: $42.59 |
| 5 |
112-6561 |
WARNING LIGHT ASM This part replaces 98-9306. Price: $121.84 |
| 6 |
98-9308 |
GAUGE-TEMPERATURE Price: $112.90 |
| 7 |
93-5961 |
BOOT-LEVER Price: $56.35 |
| 8 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 9 |
104-9261 |
DISCONTINUED Price: Call Us |
| 10 |
104-9296 |
DECAL-CONTROL Price: $27.94 |
| 11 |
104-9251-03 |
PLATE-INSTRUMENT Price: $95.17 |
| 12 |
99-8352 |
SWITCH-BACKLAP, MASTER Price: $91.81 |
| 13 |
322-8 |
SCREW-HH Price: $1.26 |
| 14 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 15 |
93-5547 |
BUSHING-NYLON Price: $6.15 |
| 16 |
104-1499-03 |
BRACKET-BLOCK, FUSE Price: $43.35 |
| 17 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 18 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 19 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 20 |
104-0027 |
BOX-CONTROL Price: $196.04 |
| 21 |
105-8289 |
SPRING-TORSION This part replaces 93-5509. Price: $15.05 |
| 22 |
94-6767 |
DECAL-FUSES Price: $11.45 |
| 23 |
104-9298 |
DECAL-CONTROLLER Price: $6.16 |
| 24 |
104-1496 |
HINGE-PIN Price: $13.22 |
| 25 |
104-1497 |
HINGE-RECEIVER Price: $13.90 |
| 26 |
139-5984 |
CONTROLLER-ELECTRONIC This part replaces 92-5720. Price: $2,183.63 |
| 27 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 28 |
321-14 |
SCREW-HH Price: $0.55 |
| 29 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 30 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 32 |
104-9331 |
HARNESS-ELECTRICAL Price: $1,671.58 |
| 33 |
94-6343 |
DECAL-IDENTIFICATION, WIRE Price: $6.86 |
| 36 |
115-5357-03 |
BRACKET-JOYSTICK This part replaces 93-5991-03. Price: $35.61 |
| 37 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 38 |
3290-354 |
NUT-SPEED Price: $9.99 |
| 39 |
3290-329 |
SCREW-PPH Price: $0.22 |
| 40 |
61-2990 |
SPACER Price: $33.75 |
| 41 |
32128-33 |
NUT-HF Price: $0.25 |
| 42 |
111332 |
SWITCH Price: $10.99 |
| 503478901 |
503478901 |
SPACER Price: $3.99 |
| 503479001 |
503479001 |
SCREW Price: $2.99 |
| 503479201 |
503479201 |
SCREW Price: $2.99 |
| 503479601 |
503479601 |
SCREW Price: $2.99 |
| 503479701 |
503479701 |
INLET NEEDLE Price: $8.99 |
| 503480001 |
537020801 |
PIN This part replaces 503480001. Price: $2.99 |
| 503480101 |
503480101 |
SCREW Price: $2.99 |
| 503480501 |
503480501 |
SCREW Price: $2.99 |
| 503480801 |
503994301 |
SPRING This part replaces 503480801. Price: $2.99 |
| 503481101 |
503481101 |
PLUG Price: $3.99 |
| 503481801 |
503481801 |
SCREW Price: $2.99 |
| 503481901 |
503481901 |
BUSHING Price: $5.99 |
| 503535701 |
503535701 |
STRAINER Price: $3.99 |
| 503665901 |
503665901 |
LEVER Price: $3.99 |
| 503755301 |
503755301 |
SCREW * Price: $2.99 |
| 503974001 |
503974001 |
WASHER Price: $2.99 |
| 503974301 |
503974301 |
COVER Price: $5.99 |
| 531004552 |
531004552 |
GASKET KIT (ZAMA GND39) Price: $9.99 |
| 531004553 |
531004553 |
CARBURETOR KIT (ZAMA RB69) Price: $17.99 |
| 537012501 |
537012501 |
BALL Price: $2.99 |
| 537012601 |
537012601 |
SPRING Price: $2.99 |
| 537019601 |
537019601 |
SHAFT Price: $6.99 |
| 537019701 |
537019701 |
SPRING THROTTLE Price: $2.99 |
| 537019801 |
537019801 |
LEVER Price: $3.99 |
| 537019901 |
537019901 |
THROTTLE FLAP Price: $3.99 |
| 537020001 |
537020001 |
PUMP DIAPHRAGM Price: $7.99 |
| 537020101 |
537020101 |
GASKET Price: $3.99 |
| 537020201 |
537020201 |
COVER Price: $19.99 |
| 537020301 |
537273401 |
SPRING This part replaces 537020301. Price: $4.99 |
| 537020401 |
537020401 |
GASKET Price: $3.99 |
| 537020501 |
537020501 |
LOW SPEED NEEDLE Price: $5.66 |
| 537020601 |
537020601 |
NEEDLE HIGH SPEED Price: $3.99 |
| 537020801 |
537020801 |
PIN Price: $2.99 |
| 537020901 |
537020901 |
CHOKE SHAFT Price: $8.99 |
| 537021001 |
537021001 |
SPRING Price: $2.99 |
| 537021101 |
537370301 |
CHOKE CAP This part replaces 537021101. Price: $6.99 |
| 537048901 |
537048901 |
DIAPHRAGM Price: $11.99 |
| 537140901 |
537140901 |
CAP Price: $1.99 |
| 537143401 |
537143401 |
LEVER Price: $2.99 |
