| Ref | Part Number | Description |
|---|
| 1 |
137-6115 |
TUBE ROLLER 3.0IN DIA X 20.5IN This part replaces 112-1740-03. Price: $139.68 |
| 1 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532122015. Price: $14.99 |
| 2 |
112-1707 |
SHAFT-ROLLER, WIEHLE Price: $73.35 |
| 2 |
532123986 |
Assembly, Dash & Fuel Tank (AYP part number) This part replaces 532124540. Price: $89.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
532123487 |
Clamp, Hose (AYP part number) Price: $3.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
532008548 |
Line, Fuel (AYP part number) Price: $2.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
532008544 |
Line, Fuel (AYP part number) Price: $2.99 |
| 6 |
114-5411 |
NUT-LOCK, BEARING This part replaces 114-3745. Price: $24.46 |
| 6 |
874780412 |
Bolt, Hex, 1/4-20 x 3/4 (AYP part number) Price: $2.99 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 7 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 8 |
874760432 |
Bolt, Fin. Hex 1/4-20 x 1 1/2 (AYP part number) Price: $3.99 |
| 9 |
532130051 |
Plate, Support (AYP part number) Price: $22.99 |
| 10 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873690400. Price: $2.99 |
| 11 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111116. Price: $2.99 |
| 12 |
532123494 |
Spacer, Split (AYP part number) Price: $2.38 |
| 13 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 14 |
532123493 |
Knob, Height Retainer (AYP part number) Price: $2.38 |
| 15 |
532126115 |
Knob, Height Stop (AYP part number) Price: $3.99 |
| 16 |
532122023 |
Adjustment, Quadrant Height (AYP part number) Price: $9.99 |
| 17 |
532124346 |
Nut, Self Thread 3/16-18 (AYP part number) Price: $3.99 |
| 18 |
532121789 |
Support, Dash (AYP part number) Price: $47.06 |
| 19 |
531003379 |
WASHER This part replaces 819091216. Price: $2.99 |
| 20 |
532009151 |
Grommet (AYP part number) This part replaces 532110436. Price: $2.99 |
| 21 |
532002751 |
Clip, Insulated (AYP part number) This part replaces 532124996. Price: $2.42 |
| 22 |
872110404 |
Bolt, Carriage 1/4-20 x 1/2 Gr.5 (AYP part number) Price: $3.99 |
| 23 |
532122016 |
Brace, Cross (AYP part number) Price: $17.57 |
| 24 |
818000408 |
Screw, Self-Tapping 1/4-20 x 1/2 This part replaces 532130052. Price: $3.99 |
