| Ref | Part Number | Description |
|---|
| 1 |
591117901 |
SERVICE KIT SVC.WELDMENT.42F This part replaces 589029002. Price: $899.99 |
| 2 |
587397301 |
MANDREL.FAB.STYLE.REV.ASSY.ALM Price: $74.99 |
| 6 |
589028701 |
BLADE.42.CLEARCUT.EURO.REV.MUL Price: $32.99 |
| 8 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 9 |
594092501 |
Rods This part replaces 532179127. Price: $5.99 |
| 10 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 13 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 17 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 24 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 26 |
532178515 |
WASHER Price: $5.99 |
| 27 |
532196104 |
PULLEY.IDLER.MWR.STATI.LH Price: $37.99 |
| 28 |
586874002 |
ARM.42"FCS.CLUTCHING.X431 Price: $17.99 |
| 29 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
| 30 |
532196106 |
PULLEY.IDLER.2006 Price: $34.99 |
| 34 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 39 |
588907502 |
SHIELD.42.CLEARCUT.RH.DECK.431 Price: $19.99 |
| 40 |
589527301 |
WHEEL.GAUGE.RALLY This part replaces 532174873. Price: $8.99 |
| 41 |
596434404 |
Bolts This part replaces 532193406. Price: $4.99 |
| 42 |
531169201 |
SERVICE KIT ARM ARM.SUSPENSION This part replaces 532195185. Price: $12.99 |
| 43 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 44 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 46 |
501138901 |
BELT.42.CLEARCUT.DECKDRIVE.EUR Price: $54.99 |
| 47 |
595901601 |
GSPW Bolts This part replaces 539990316. Price: $2.99 |
| 48 |
587354701 |
SPRING.42.FCS.DEFLECTOR Price: $5.99 |
| 49 |
588907402 |
SHIELD.42CLRCUT.LH.DECK.SD.431 Price: $32.99 |
| 51 |
532195945 |
PULLEY.MANDREL.5.438.P This part replaces 532197473. Price: $12.99 |
| 52 |
588438301 |
SCREW.7/16-14 X 2.125.WASHER Price: $5.99 |
| 53 |
532415598 |
PORT.WASHOUT Price: $6.99 |
| 55 |
596240801 |
GSPW Bolts This part replaces 539115574. Price: $3.99 |
| 56 |
587358401 |
SPRING.EXTN.42.FCS.TR.DECK.DRV Price: $6.99 |
| 57 |
596039201 |
GSPW Hardware This part replaces 539990585. Price: $2.99 |
| 61 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 Price: $3.99 |
| 63 |
580954003 |
HOLDER.BLADE.REVOLUTION Price: $179.99 |
| 64 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 584309301. Price: $6.99 |
| 65 |
532110452 |
NUT PUSH M Price: $2.99 |
| 66 |
587305701 |
DEFLECTOR.ASM.42.FCS.ORANGE Price: $69.99 |
| 67 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 68 |
532198468 |
KEEPER.BELT.IDLER.54"T Price: $7.99 |
| 69 |
588907601 |
COVER.42.CLRCUT.EU.MANDREL.498 Price: $44.99 |
| 71 |
586638501 |
CAP.REVOLUTION ASM Price: $29.99 |
| 72 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 73 |
532423062 |
PALNUT 1/4 Price: $2.99 |
| 74 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 75 |
582683201 |
BUMPER.42.CLEARCUT.TRIMSDE.ASM Price: $9.99 |
| 77 |
596134901 |
GSPH This part replaces 819132012. Price: $2.99 |
| 78 |
501808302 |
BRACKET.PNT.GA-WHEEL.FCS.42.RH Price: $19.99 |
| 79 |
590439002 |
BRACKET.PNT.GA-WHEEL.42FCS.LH This part replaces 501801602. Price: $17.99 |
| 81 |
582360501 |
BUSHING.NOSE.ROLLER Price: $3.99 |
| 83 |
596637301 |
Screws This part replaces 817490410. Price: $2.99 |
