| Ref | Part Number | Description |
|---|
| 0010 |
84003022 |
BRACKET, Pedal Pivot Price: Call Us |
| 0020 |
84003023 |
UPSTOP Price: $11.01 |
| 0030 |
1727246SM |
PEDAL, Reverse Price: $19.05 |
| 0040 |
1727282SM |
SUPPORT, Battery Price: $26.49 |
| 0050 |
1727902SM |
PLATE, Axle Support Price: $39.47 |
| 0060 |
1727911ASM |
PLATE, Bearing Price: $11.40 |
| 0070 |
1727935SM |
SPACER-PIVOT 0.330ID Price: $5.17 |
| 0080 |
1728024SM |
SPACER, Foot Pedal Price: $4.41 |
| 0090 |
1728025BMYP |
ACTUATOR, RMO Switch Price: $5.88 |
| 0100 |
1730186SM |
BUSHING, Axle Pivot Price: $6.02 |
| 0110 |
1761926CJYP |
LATCH, PARKING BRAKE Price: $12.29 |
| 0120 |
84003024 |
PEDAL ASSEMBLY Price: $103.87 |
| 0130 |
1738051YP |
LINK, Drag (with Bearing), 5/16 Price: $56.13 |
| 0140 |
1751110YP |
GEAR, Steering Price: $31.79 |
| 0170 |
84003025 |
BRACKET, Support LH Price: $14.03 |
| 0180 |
84003026 |
BRACKET, Support RH Price: $14.03 |
| 0190 |
84003027 |
SUPPORT, Back Plate Price: $34.97 |
| 0200 |
84003028 |
SUPPORT, Lower Back Plate Price: $19.18 |
| 0220 |
84003029 |
BRACKET, Pivot Price: $8.29 |
| 0230 |
84003030 |
SUPPORT, Upper, Back Plate Price: $22.78 |
| 0240 |
1960035SM |
WASHER-0.625(0.64IDX1 Price: $3.72 |
| 0250 |
84003031 |
NUT Price: $2.87 |
| 0260 |
2860744SM |
CAPSCREW, Hex Head, 5/8-11 x 3 1/4 Price: $7.55 |
| 0270 |
7014296YP |
WASHER, Shim Price: $3.82 |
| 0290 |
703851 |
BOLT, 5/16-18X1.15 Price: $4.70 |
| 0300 |
703409 |
NUT, 5/16-18, GR5 Price: $4.92 |
| 0310 |
703354 |
SCREW, 5/16-18 Price: $4.70 |
| 0320 |
1919326SM |
WASHER, 5/16 Price: $3.61 |
| 0330 |
703446 |
BOLT, 5/16-18X1.25 G5 Price: $3.61 |
| 0340 |
703570 |
CAPSCREW, Hex Head, 5/16-18 x 1 1/4 Price: $3.95 |
| 0350 |
703949 |
SCREW, 5/16-18.625 Price: $3.40 |
| 0360 |
704067 |
NUT, HEX FLNG,5/16-18 Price: $3.17 |
| 0400 |
84003032 |
PEDAL ASSEMBLY Price: $97.99 |
| 0410 |
1761913AYP |
SUPPORT, FOOTREST Price: $30.73 |
| 0420 |
1759842BMYP |
SUPPORT, Front Footrest, RH Price: $36.85 |
