| Ref | Part Number | Description |
|---|
| 1 |
108-0778 |
FRAME-PITCH Price: $3,360.53 |
| 1 |
532170803 |
CONTROL, THROTTLE Price: $24.99 |
| 2 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 3 |
107-1258 |
PIN-FLAG Price: $57.37 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
138-5901 |
CYLINDER-HYD This part replaces 107-1310. Price: $1,680.21 |
| 5 |
532181444 |
EXHAUST TUBE LH KAWI Price: $54.99 |
| 6 |
532181442 |
EXHAUST TUBE RH KAWI Price: $59.99 |
| 7 |
108-0669 |
PIN-FLAG Price: $64.35 |
| 8 |
323-7 |
SCREW-HH Price: $0.65 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 10 |
108-0826 |
PIN-FLAG Price: $47.30 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 25 |
532191812 |
NEEDS DESCRIPTION Price: Call Us |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 31 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532185534. Price: $44.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 101 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 105 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
