| Ref | Part Number | Description |
|---|
| 1 |
66-6370 |
LIFT ARM ASM Price: $430.43 |
| 1 |
71191008 |
SCREW.PNHD.10-24 Price: Call Us |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 3 |
104164X |
TIE CABLE CRT Price: Call Us |
| 3 |
32136-2 |
NUT-SHH Price: $3.55 |
| 4 |
21-3020-01 |
MOUNT-BALLJOINT, RH This part replaces 21-3020. Price: $178.87 |
| 4 |
8206H |
GRIP T Price: Call Us |
| 5 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 6 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 6 |
81328 |
SHOULDER BOLT ST Price: Call Us |
| 7 |
109335X |
SHIFT HANDLE CRT Price: Call Us |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 8 |
109313X |
GROMMET CRT Price: Call Us |
| 8 |
3217-8 |
NUT-HEX Price: $1.34 |
| 9 |
109337X |
SHIFT ROD CRT Price: Call Us |
| 9 |
66-7150 |
ARM-PUSH, RH Price: $536.26 |
| 10 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 10 |
72110608 |
BOLT D Price: Call Us |
| 11 |
109229X |
LOCK CRT Price: Call Us |
| 11 |
24-9510 |
PIN Price: $77.49 |
| 12 |
55-4300 |
DECAL-WARNING Price: $13.99 |
| 12 |
73930600 |
LOCKNUT Price: Call Us |
| 13 |
19131611 |
WASHER CRT Price: Call Us |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 14 |
109228X |
LEVER LOCK CRT Price: Call Us |
| 14 |
46-8840-01 |
SPRING-LIFT ARM This part replaces 46-8840. Price: $35.71 |
| 15 |
150256X550 |
SUB= 150256X431 Price: Call Us |
| 15 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 16 |
10040400 |
LOCKWASHER Price: Call Us |
| 16 |
256-126 |
BUSHING Price: $9.36 |
| 17 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 17 |
73220400 |
SUB= 50675 Price: Call Us |
| 18 |
23-1950-01 |
SUPPORT-REINFORCEMENT This part replaces 23-1950. Price: $69.64 |
| 18 |
73731000 |
NUT Price: Call Us |
| 19 |
159231 |
CABLE.CLUTCH Price: Call Us |
| 19 |
324-4 |
SCREW-HH Price: $0.95 |
| 20 |
3-7292 |
PIN-CLEVIS Price: $44.11 |
| 20 |
9484R |
CONDIUT CLIP T Price: Call Us |
| 21 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 21 |
86777 |
SUB= 750097 Price: Call Us |
| 22 |
102604X |
GRIP BAR CRT Price: Call Us |
| 22 |
3241-7 |
SCREW-SQH This part replaces 324-12. Price: $3.39 |
| 23 |
102744X |
SUB= 102744X431 Price: Call Us |
| 24 |
159228 |
BAR ASM CONTROL Price: Call Us |
| 24 |
21-2860-01 |
PUSH ARM BRACKET ASM This part replaces 21-2860. Price: $154.46 |
| 25 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 26 |
21-2990 |
SHAFT-PIVOT Price: $227.21 |
| 26 |
72140404 |
BOLT Price: Call Us |
| 27 |
32128-42 |
NUT-HF Price: $0.98 |
| 27 |
9266R |
SUB= 624A78 Price: Call Us |
| 28 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 28 |
73510400 |
NUT Price: Call Us |
| 29 |
21-2960 |
ARM-PUSH, LH Price: $519.38 |
| 30 |
21-2900-01 |
SPRING-TORSION, LH This part replaces 21-2900. Price: $566.83 |
| 31 |
21-2890-01 |
SPRING-TORSION, RH This part replaces 21-2890. Price: $566.83 |
| 32 |
21-3050-01 |
LH BALL JOUNT MOUNT ASM This part replaces 21-3050. Price: $153.41 |
| 33 |
86-8100-01 |
BALL JOINT ASM This part replaces 86-8100. Price: $137.53 |
| 34 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 35 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 36 |
3-1365 |
CHAIN Price: $72.97 |
| 37 |
68-3270 |
BUMPER-RUBBER This part replaces 67-9800. Price: $37.99 |
| 38 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 39 |
5-2942 |
SHACKLE Price: $16.99 |
