| Ref | Part Number | Description |
|---|
| 1 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 1 |
532140579 |
Deck Asm., Mower 44" Vented (AYP part number) Price: $3.33 |
| 2 |
3217-7 |
NUT-HEX Price: $0.28 |
| 2 |
873800500 |
Locknut, Hex W/Ins 5/16-18 Unc (AYP part number) Price: $2.99 |
| 3 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 3 |
872110506 |
Bolt, Carriage 5/16-18 x 3/4 (AYP part number) Price: $3.99 |
| 4 |
32140-79 |
Screw Price: Call Us |
| 4 |
532007631 |
Runner, Mower LH (AYP part number) This part replaces 532125074. Price: $11.99 |
| 5 |
3-8602 |
DISCONTINUED Price: Call Us |
| 5 |
532138457 |
Bracket Asm., Sway Bar (AYP part number) Price: $8.99 |
| 6 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 6 |
532124670 |
Retainer, Spring (AYP part number) Price: $5.99 |
| 7 |
282-4 |
SHACKLE Price: $32.98 |
| 7 |
532178024 |
BAR SWAY DECK This part replaces 532130832. Price: $5.99 |
| 8 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 8 |
532850857 |
Bolt 3/8-24 x 1.25 Gr. 8 Patched (AYP part number) Price: $1.99 |
| 9 |
3-8718 |
DISCONTINUED Price: Call Us |
| 9 |
539990118 |
SLW 3/8 STD This part replaces 810030600. Price: $1.99 |
| 10 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 10 |
532140296 |
Washer, Hard Blade Mower Vented (AYP part number) Price: $2.99 |
| 11 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 11 |
532130652 |
Blade (3 Required) (AYP part number) Price: $17.99 |
| 12 |
3-8601 |
DISCONTINUED Price: Call Us |
| 12 |
532129895 |
Bearing, Ball #6204 (Mandrel) (AYP part number) Price: $6.99 |
| 13 |
532137553 |
Shaft Asm., W/Lower Brg (Includes Key No. 12) (AYP part number) Price: $22.99 |
| 13 |
6-9960 |
DISCONTINUED Price: Call Us |
| 14 |
5-1640 |
DISCONTINUED Price: Call Us |
| 14 |
532137152 |
Housing, Mandrel 44" Vent (AYP part number) Price: $24.99 |
| 15 |
3290-255 |
PIN-COTTER, HAIR Price: $7.89 |
| 15 |
532110485 |
Bearing, Ball Mandrel (AYP part number) Price: $7.99 |
| 16 |
3220-3 |
NUT-HJ Price: $0.28 |
| 16 |
532174493 |
STRIPPER.MANDREL.ROUND.BLACK This part replaces 532140329. Price: $3.99 |
| 17 |
5-1637 |
DISCONTINUED Price: Call Us |
| 17 |
532106735 |
Rod, Hinge (AYP part number) Price: $4.99 |
| 18 |
5-1660 |
DISCONTINUED Price: Call Us |
| 18 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. (AYP part number) Price: $5.99 |
| 19 |
532105304 |
Cap, Sleeve (AYP part number) Price: $2.99 |
| 19 |
8-5129 |
DISCONTINUED This part replaces 6-0509. Price: Call Us |
| 20 |
38-7410 |
DISCONTINUED This part replaces 3-8597. Price: Call Us |
| 20 |
532123713 |
Spring, Torsion Deflector (AYP part number) Price: $3.99 |
| 21 |
12-0300 |
DISCONTINUED Price: Call Us |
| 21 |
532137607 |
Bracket, Deflector (AYP part number) Price: $3.99 |
| 22 |
352-276 |
DISCONTINUED Price: Call Us |
| 22 |
532110452 |
Nut, Push (AYP part number) Price: $1.99 |
| 23 |
352-277 |
DISCONTINUED Price: Call Us |
| 23 |
532109785 |
Shield, Deflector Mower (AYP part number) Price: $22.99 |
| 24 |
352-272 |
DISCONTINUED Price: Call Us |
| 24 |
532136321 |
Runner, RH (AYP part number) Price: $6.99 |
| 25 |
352-273 |
DISCONTINUED Price: Call Us |
| 25 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111216. Price: $2.99 |
| 26 |
352-268 |
DISCONTINUED Price: Call Us |
| 26 |
872110614 |
Bolt, Carriage 3/8-16 x 1-3/4 Gr. 5 (AYP part number) Price: $3.99 |
| 27 |
352-278 |
DISCONTINUED Price: Call Us |
| 27 |
819131316 |
Washer 13/32 x 13/16 x 16 Ga. (AYP part number) Price: $2.99 |
| 28 |
352-279 |
DISCONTINUED Price: Call Us |
| 28 |
532132823 |
Spacer, Spring Stop Idler Price: $4.99 |
| 29 |
3245-9 |
SCREW-SET, HSH Price: $0.81 |
| 29 |
873680600 |
LOCKNUT This part replaces 873800600. Price: $1.99 |
| 30 |
352-270 |
DISCONTINUED Price: Call Us |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $1.99 |
| 31 |
12-0280 |
DISCONTINUED Price: Call Us |
| 31 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $4.99 |
| 32 |
3-8596 |
SPRING-COMPRESSION Price: $29.97 |
| 32 |
532129861 |
Pulley, Mandrel (AYP part number) Price: $17.99 |
| 33 |
5-3942 |
DISCONTINUED Price: Call Us |
| 33 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $1.99 |
| 34 |
5-1865 |
DISCONTINUED Price: Call Us |
| 34 |
583611601 |
BOLT.3/8-14X1.25 This part replaces 872140610. Price: $3.99 |
| 35 |
28-1520 |
DISCONTINUED This part replaces 6-1200. Price: Call Us |
| 35 |
872110616 |
Bolt, Carriage 3/8-16 x 2 (AYP part number) Price: $3.99 |
| 36 |
3-8595 |
DISCONTINUED Price: Call Us |
| 36 |
872110608 |
Bolt, Carriage 3/8-16 x 1 Gr. 5 (AYP part number) Price: $3.99 |
| 37 |
5-3941 |
DISCONTINUED Price: Call Us |
| 37 |
532137166 |
Stiffener, Arm Idler (AYP part number) Price: $3.99 |
| 38 |
3-8607 |
DISCONTINUED Price: Call Us |
| 38 |
532173968 |
KEEPER.BELT.IDLER.PLATED This part replaces 532137554. Price: $4.99 |
| 39 |
5-3953 |
DISCONTINUED Price: Call Us |
| 39 |
532173438 |
PULLEY.IDLER.FLAT This part replaces 532131494. Price: $14.99 |
| 40 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 40 |
532136572 |
Pulley, Driven (AYP part number) Price: $24.99 |
| 41 |
5-1705 |
END SKID ASM Price: $139.95 |
| 42 |
5-3965 |
DISCONTINUED Price: Call Us |
| 42 |
539990316 |
BOLT 5/16C X 3/4" CARRIAGE This part replaces 872140506. Price: $1.99 |
| 43 |
323-6 |
SCREW-HH Price: $0.66 |
| 43 |
532136460 |
Arm, Idler Secondary (AYP part number) Price: $4.99 |
| 44 |
5-3824 |
DISCONTINUED Price: Call Us |
| 44 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $2.99 |
| 45 |
3245-35 |
SCREW-SET, HSH Price: $0.41 |
| 45 |
873680600 |
Nut, Crownlock 3/8-16 Unc Price: $1.99 |
| 46 |
5-3835 |
DISCONTINUED Price: Call Us |
| 46 |
582740701 |
BOLT This part replaces 874760628. Price: $2.99 |
| 47 |
5-3950 |
DISCONTINUED Price: Call Us |
| 47 |
532137200 |
Cover, Mandrel RH (AYP part number) Price: $14.99 |
| 48 |
11-4929 |
DISCONTINUED This part replaces 5-3944. Price: Call Us |
| 48 |
532137729 |
Screw, Thd Roll 1/4-20 x 5/8 (AYP part number) Price: $2.99 |
| 49 |
5-2186 |
REEL BEARING Price: $45.95 |
| 49 |
532136574 |
Cover, Mandrel LH (AYP part number) Price: $12.99 |
| 50 |
5-3838 |
DISCONTINUED Price: Call Us |
| 50 |
532137272 |
Arm, Idler Primary (AYP part number) Price: $3.99 |
| 51 |
253-121 |
DISCONTINUED Price: Call Us |
| 51 |
532137273 |
Spring, Secondary (AYP part number) Price: $3.99 |
| 52 |
5-2182 |
DISCONTINUED Price: Call Us |
| 52 |
532139245 |
Pulley, Idler V Groove (AYP part number) Price: $22.99 |
| 53 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 53 |
532137789 |
Shield, Idler (AYP part number) Price: $4.99 |
| 54 |
3296-45 |
NUT-HEX Price: $3.79 |
| 54 |
532131264 |
V-Belt, Mower Primary Price: $19.99 |
| 55 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 55 |
532144200 |
V-Belt Mower 42" This part replaces 532131290. Price: $32.99 |
| 56 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 56 |
532138687 |
Spring, Primary (AYP part number) Price: $2.99 |
| 57 |
5-3915 |
DISCONTINUED Price: Call Us |
| 58 |
5-3918 |
DISCONTINUED Price: Call Us |
| 59 |
5-3837 |
DISCONTINUED Price: Call Us |
| 60 |
5-3966 |
DISCONTINUED Price: Call Us |
| 61 |
5-1704 |
DISCONTINUED Price: Call Us |
| 62 |
2-1590 |
DISCONTINUED Price: Call Us |
| 62 |
532178515 |
WASHER This part replaces 532133943. Price: $2.99 |
| 63 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 63 |
872110612 |
Bolt Carriage 3/8-16 x 1-1/2 (AYP part number) Price: $3.99 |
| 64 |
322-2 |
SCREW-HH Price: $0.69 |
| 64 |
734117201 |
WASHER This part replaces 819121414. Price: $1.99 |
| 65 |
3279-2 |
DISCONTINUED Price: Call Us |
| 67 |
873680600 |
LOCKNUT This part replaces 873930600. Price: $1.99 |
| 95 |
532175746 |
BRACKET ASM, ROLLER (L) This part replaces 532132274. Price: $3.99 |
| 96 |
532175747 |
BRACKET ASM, ROLLER This part replaces 532132273. Price: $7.99 |
| 97 |
819171416 |
Washer 17/32 x 7/8 x 16 Ga. (AYP part number) Price: $2.99 |
| 98 |
532132264 |
Roller, Nose Price: $27.99 |
| 99 |
874780616 |
BOLT This part replaces 874760616. Price: $3.99 |
| 102 |
872110606 |
Bolt Carriage 3/8-16 x 3/4 (AYP part number) Price: $2.99 |
