| Ref | Part Number | Description |
|---|
| 1 |
108-9083 |
PLATE-SIDE, RH Price: $328.36 |
| 1 |
532124657 |
Extension, Spring (AYP part number) Price: $7.99 |
| 2 |
108-9082 |
PLATE-SIDE, LH Price: $328.36 |
| 2 |
873640400 |
Nut, Hex, Keps 1/4-20 (AYP part number) Price: $2.99 |
| 3 |
104-3396 |
SCREW-HH Price: $0.75 |
| 3 |
819091416 |
Washer, 9/32 x 7/8 x 16 Ga. (AYP part number) Price: $3.99 |
| 4 |
874780412 |
Bolt, Hex Fin 1/4-20 x 3/4 Gr. 5 (AYP part number) Price: $2.99 |
| 4 |
99-8662 |
TUBE-SPRING Price: $21.55 |
| 5 |
3218-5 |
NUT-JAM Price: $0.27 |
| 5 |
532139888 |
Bolt, Shoulder (AYP part number) Price: $2.99 |
| 6 |
532122549 |
Bracket, Hood R. H. (AYP part number) Price: $2.45 |
| 6 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 7 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 7 |
532122548 |
Bracket, Hood L.H. (AYP part number) Price: $2.99 |
| 8 |
32128-40 |
NUT-FLANGE Price: $0.88 |
| 8 |
817521312 |
Screw Sltd. Hex Hd W/PL Washer (AYP part number) Price: Call Us |
| 9 |
110-4079 |
SPRING-COMPRESSION Price: $13.57 |
| 9 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 873800400. Price: $1.99 |
| 10 |
532123693 |
Brace, Hood (AYP part number) Price: $5.99 |
| 11 |
532144647 |
Hood (AYP part number) Price: Call Us |
| 12 |
110-4069 |
BRACKET Price: $5.57 |
| 12 |
532122035 |
Lens Clear Bar (AYP part number) Price: $14.99 |
| 13 |
115-2007 |
ROD-SPRING This part replaces 107-7437. Price: $34.97 |
| 13 |
532127029 |
Grille (AYP part number) Price: $199.99 |
| 14 |
532002751 |
Clip, Insulated (AYP part number) This part replaces 532124996. Price: $2.42 |
| 14 |
92-2762 |
PIN-HAIR Price: $1.09 |
| 15 |
119-4162 |
SCREW-CARR This part replaces 3231-25. Price: $1.73 |
| 18 |
110-4058 |
BRACKET-CHAIN Price: $32.43 |
| 18 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111116. Price: $2.99 |
| 19 |
107-3258 |
FRAME Price: $331.61 |
| 20 |
107-2979 |
BOLT-SHOULDER Price: $3.94 |
| 21 |
3234-19 |
SCREW-HHF Price: $1.73 |
| 22 |
67-9410 |
WASHER Price: $2.04 |
| 23 |
108-4279 |
SPACER-FRAME Price: $8.34 |
| 24 |
108-4284 |
TUBE-SUPPORT Price: $60.29 |
| 25 |
107-7433 |
CARRIER FRAME ASM Price: $484.72 |
