| Ref | Part Number | Description |
|---|
| 1 |
127-5027 |
EDUCTOR Price: $267.84 |
| 2 |
127-5042 |
CONTAINER-RINSE Price: $163.89 |
| 2 |
530015241 |
Screw Price: $1.99 |
| 3 |
120-8679 |
PROCLEAN BOTTLEWASH ASM This part replaces 127-5048. Price: $181.40 |
| 3 |
525592801 |
Assy - Muffler This part replaces 545081845. Price: $22.99 |
| 4 |
127-6934 |
VALVE-TANK Price: $529.57 |
| 4 |
530058982 |
Bolt Price: $1.99 |
| 5 |
127-6923 |
VALVE-DRAIN Price: $496.56 |
| 5 |
545081832 |
Gasket-Muffler (gasket kit) Price: $11.99 |
| 6 |
127-6916 |
LID Price: $152.43 |
| 6 |
545115301 |
Cylinder Price: $27.99 |
| 7 |
127-6939 |
STRAINER Price: $62.43 |
| 7 |
530015953 |
Bolt Price: $1.99 |
| 8 |
127-6900 |
GROMMET Price: $23.10 |
| 8 |
952030249 |
Spark Plug (RCJ-6Y) Price: $3.99 |
| 9 |
127-6904 |
ELBOW-FITTING Price: $12.05 |
| 9 |
545084901 |
Adapter - Carb. Price: $9.99 |
| 10 |
127-6903 |
ELBOW-FITTING Price: $53.60 |
| 10 |
530016441 |
Screw Price: $1.99 |
| 11 |
127-6905 |
VALVE-TWO WAY Price: $103.18 |
| 11 |
545115501 |
Linkage - Throttle Price: $2.99 |
| 12 |
127-5049 |
FITTING Price: $38.20 |
| 13 |
127-6906 |
FITTING-TEE Price: $64.06 |
| 13 |
545135905 |
Lever- Choke (Yellow) Price: $6.99 |
| 14 |
127-5030 |
RING-MOUNTING Price: $107.03 |
| 14 |
545163401 |
Base - Airbox Price: $1.07 |
| 15 |
127-6922 |
SCREW-HH Price: $8.41 |
| 15 |
530016429 |
Screw Price: $1.99 |
| 16 |
127-5031 |
SCREW-HH Price: $2.99 |
| 16 |
545146501 |
Filter Price: $3.99 |
| 17 |
127-5029 |
BRACKET Price: $254.39 |
| 17 |
545163501 |
Cover - Air Box Filter Price: $8.99 |
| 18 |
127-6938 |
WASHER Price: $13.50 |
| 18 |
530035497 |
Bulb - Purge (walbro 188-16) Price: $4.99 |
| 19 |
127-6932 |
GASKET Price: $5.13 |
| 19 |
545081832 |
Gasket (Carb / Adapter) (gasket kit) Price: $11.99 |
| 20 |
127-5005 |
CLAMP-WORM SCREW Price: $10.92 |
| 20 |
545081832 |
O-Ring (Adapter / Cylinder) (gasket kit) Price: $11.99 |
| 22 |
545154009 |
PISTON RING This part replaces 530012472. Price: $1.99 |
| 23 |
530015162 |
Retainer - Wrist Pin Price: $1.99 |
| 24 |
545156002 |
KIT PISTON CONN ROD FORGED This part replaces 545081865. Price: $14.99 |
| 25 |
545081826 |
Kit - Ignition Module This part replaces 545158001. Price: $32.99 |
| 26 |
530016357 |
Screw Price: $1.99 |
| 27 |
545127601 |
Assy - Wire Harness Price: $5.99 |
| 28 |
545081832 |
O-Ring (Cyl./Crankcase) (gasket kit) Price: $11.99 |
| 29 |
530015828 |
Washer Price: $1.99 |
| 30 |
545221701 |
FLYWHEEL ASSY This part replaces 530054115. Price: $8.99 |
| 31 |
530015941 |
Retainer - Crankshaft Price: $1.99 |
| 32 |
530055728 |
Bearing - Outer Price: $6.99 |
| 33 |
530019264 |
Seal Price: $2.99 |
| 34 |
530032125 |
Bearing - Inner Price: $11.99 |
| 37 |
545081832 |
O-Ring (Rear Plug) (gasket kit) Price: $11.99 |
| 39 |
530016386 |
Screw Price: $5.99 |
