| Ref | Part Number | Description |
|---|
| 1 |
104-3554 |
SHAFT-SPINDLE Price: $67.98 |
| 1 |
532436551 |
BATTERY.6A.12V.LEOCH Price: $89.99 |
| 1A |
31350 |
SHAFT & LEV Price: Call Us |
| 2 |
138-6416 |
SPACER-SPINDLE, SHAFT This part replaces 69-6950. Price: $18.44 |
| 2 |
30357 |
SCREW Price: $2.62 |
| 3 |
119-4546 |
SPINDLE HOUSING ASM Price: $244.67 |
| 3 |
30726 |
SHUTTER Price: Call Us |
| 3 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $9.99 |
| 4 |
106-7159 |
O-RING Price: $0.99 |
| 4 |
31727 |
SHAFT & LVR Price: Call Us |
| 4 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $6.99 |
| 5 |
104-3545 |
PULLEY-DRIVING Price: $250.04 |
| 6 |
120-5576 |
WASHER-HARDENED Price: $3.91 |
| 6 |
650399 |
SCREW This part replaces 630605. Price: $1.20 |
| 7 |
27112 |
IDLE SCREW Price: $1.26 |
| 7 |
3296-60 |
NUT-LOCK, NI Price: $5.08 |
| 8 |
27114 |
SPRING Price: $2.62 |
| 8A |
27114 |
SPRING Price: $2.62 |
| 9 |
539101080 |
SWITCH, INTERLOCK This part replaces 532109553. Price: $4.99 |
| 10 |
30927 |
SHUTTER Price: Call Us |
| 10 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 11 |
30356 |
GASKET Price: $2.22 |
| 12 |
27108 |
GASKET Price: Call Us |
| 12 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $12.99 |
| 13 |
29154 |
INLET NEEDLE Price: Call Us |
| 13 |
584299601 |
ELECTRICAL.LRVB.GEARDRIVE Price: $34.99 |
| 14 |
30354 |
FLOAT Price: Call Us |
| 15 |
27106 |
FLOAT SHAFT Price: $2.04 |
| 15 |
582042801 |
SOLENOID.STARTER.BRASS.PLUNGER This part replaces 532192507. Price: $7.99 |
| 16 |
27136A |
DRAIN ASSY This part replaces 27136. Price: $5.96 |
| 16 |
539990071 |
HCS 1/4-20. This part replaces 817720408. Price: $1.99 |
| 17 |
32131 |
FLOAT BOWL This part replaces 30350. Price: $11.15 |
| 17 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 18 |
27136A |
DRAIN ASSY This part replaces 27137. Price: $5.96 |
| 18 |
532416694 |
CABLE.BATTERY.20.RED.8 AWG Price: $11.99 |
| 19 |
27136A |
DRAIN ASSY This part replaces 27138. Price: $5.96 |
| 19 |
532421299 |
CABLE.STARTER.6GA.11"RED Price: $11.99 |
| 20 |
27110A |
GASKET This part replaces 27110. Price: $1.45 |
| 20 |
532421298 |
CABLE GROUND 6 GA. 12" BLACK Price: $9.99 |
| 21 |
28945 |
POWER SCREW Price: $18.86 |
| 21 |
532171877 |
BOLT, 5/16-18 X 1 3/4 This part replaces 817060512. Price: $3.99 |
| 22 |
532442148 |
SCREW.HEX.M5X0.8.9MM (2 2) Price: $2.99 |
| 22 |
630786 |
SPRING Price: $1.25 |
| 23 |
30355 |
NOZZLE Price: Call Us |
| 23 |
532438122 |
NUT.M5.(.393X.275) Price: $2.99 |
| 24 |
27113 |
SPRING Price: $2.62 |
| 24 |
574822701 |
SCR #10-24 X .75 SKT HD BLK Price: $1.99 |
| 25 |
27554 |
GASKET Price: $1.05 |
| 25 |
583501901 |
FUSE.10 This part replaces 532441622. Price: $2.99 |
| 26 |
27544 |
O RING Price: $1.26 |
| 27 |
650506 |
SCREW This part replaces 630606. Price: $0.87 |
| 28 |
30815 |
BAFFLE Price: Call Us |
| 29 |
30817 |
SCREW Price: Call Us |
| 29 |
532191834 |
MODULE.REVERSE.ROS Price: $22.99 |
| 30 |
31352 |
RET SPRING Price: Call Us |
| 30 |
581625201 |
JUMPER.PIGTAIL.ROS.LRVB Price: $3.99 |
