| Ref | Part Number | Description |
|---|
| 1 |
5-1106-01 |
HINGE-BALL, RH This part replaces 5-1106. Price: $66.76 |
| 2 |
5-1104-01 |
SOCKET ASM-HINGE,RH This part replaces 5-1104. Price: $165.99 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
11-9970 |
CENTER FRAME W.A. Price: $2,271.14 |
| 4 |
323-6 |
SCREW-HH Price: $0.66 |
| 5 |
4-8569 |
DISCONTINUED Price: Call Us |
| 6 |
32153-5 |
NUT-HEX Price: $1.59 |
| 7 |
5-1116-01 |
DISCONTINUED This part replaces 5-1116. Price: Call Us |
| 8 |
325-6 |
SCREW-HH Price: $1.42 |
| 8 |
532139123 |
PULLEY.IDLER.V. This part replaces 532121361. Price: $32.99 |
| 9 |
12-0030 |
DISCONTINUED Price: Call Us |
| 9 |
532177748 |
KEEPER ASM BELT ENGINE Price: $12.99 |
| 10 |
12-0010 |
U BOLT W.A. Price: $81.76 |
| 10 |
532175287 |
BUSHING Price: $17.99 |
| 11 |
532179335 |
CLUTCH MZ ZTR GT.48/54"1.125" Price: $299.99 |
| 11 |
6-0860 |
TRLG&3UNIT DRAWBAR WA*R Price: $840.26 |
| 12 |
5-1108 |
BOLT-HINGE CLAMP Price: $42.89 |
| 12 |
532143996 |
PULLEY ENG VGT ELECT CLUTCH Price: $37.99 |
| 13 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 14 |
5-1107-01 |
HINGE CAP ASM This part replaces 5-1107. Price: $161.71 |
| 15 |
5-1103-01 |
SOCKET ASM-HINGE, LH This part replaces 5-1103. Price: $146.47 |
| 16 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 17 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 18 |
323-7 |
SCREW-HH Price: $0.65 |
| 18 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 19 |
325-5 |
SCREW-HH Price: $1.20 |
| 20 |
5-1092 |
DISCONTINUED Price: Call Us |
| 20 |
532178147 |
CONTROL.THROTTLE.COBRA.42"BLK. Price: $29.99 |
| 21 |
5-1093 |
DISCONTINUED Price: Call Us |
| 21 |
532189747 |
SCREW.HI-LO#13-16X5/8 This part replaces 532171875. Price: $14.99 |
| 22 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 22 |
532175441 |
CHOKE CONTROL This part replaces 532178148. Price: $24.99 |
| 23 |
5-1094 |
FORK *R Price: $31.80 |
| 24 |
5-9390 |
LIFT HANDLE *B Price: $45.72 |
| 24 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 25 |
3-7877 |
GRIP-HANDLE Price: $10.69 |
| 25 |
873920600 |
Nut Keps 3/8 - 24 UNF Price: $3.99 |
| 26 |
287-2 |
DISCONTINUED Price: Call Us |
| 26 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
| 27 |
5-1096 |
CHAIN-LIFT Price: $18.82 |
| 27 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 28 |
283-15 |
PIN-CLEVIS Price: $4.07 |
| 28 |
532008542 |
FUEL LINE 42" This part replaces 532124703. Price: $5.99 |
| 29 |
3272-16 |
PIN-COTTER Price: $0.31 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
5-2942 |
SHACKLE Price: $16.99 |
| 31 |
325-4 |
SCREW-HH Price: $0.95 |
| 31 |
532145006 |
PUSH CLIP Price: $2.99 |
| 32 |
12-0120 |
DISCONTINUED Price: Call Us |
| 33 |
5-1091 |
SPACER Price: $4.98 |
| 34 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 35 |
3-7254-01 |
DRAW BAR BRACKET This part replaces 3-7254. Price: $227.92 |
| 35 |
810010500 |
WASHER Price: $3.99 |
| 36 |
325-10 |
SCREW-HH Price: $1.82 |
| 37 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 38 |
5-1111 |
CASTOR WHEEL BUSHING Price: $10.11 |
| 39 |
5-1112 |
DRAWBAR PIN Price: $9.77 |
| 39 |
596564004 |
SCREW TT 3/8-16X2.31 UNC This part replaces 817490636. Price: $1.99 |
| 40 |
4-8669 |
DISCONTINUED Price: Call Us |
| 40 |
817490664 |
Screw TT 3/8-16 x 4 unc Price: $3.99 |
| 41 |
12-0060 |
DISCONTINUED Price: Call Us |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
5-1105-01 |
HINGE-BALL, LH This part replaces 5-1105. Price: $57.25 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
5-1087 |
DISCONTINUED Price: Call Us |
| 43 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED This part replaces 532179953. Price: $3.99 |
| 44 |
3290-256 |
PIN-HAIR Price: $1.01 |
| 45 |
4-8629 |
DISCONTINUED Price: Call Us |
| 46 |
5-1085 |
DRAWBAR COUPLER *R Price: $231.54 |
| 47 |
5-1086 |
SPRING REBOUND PIN Price: $86.79 |
| 47 |
532175288 |
BUSHING Price: $4.99 |
| 48 |
5-1084 |
DISCONTINUED Price: Call Us |
| 49 |
5-1088 |
DISCONTINUED Price: Call Us |
| 50 |
3272-38 |
PIN-COTTER Price: $3.05 |
| 62 |
532176252 |
HEAT SHIELD Price: $5.59 |
| 70 |
532175766 |
TUBE EXHAUST LH Price: $48.99 |
| 71 |
532175767 |
TUBE.EXHAUST.KAWASAKI.RH Price: $54.99 |
| 80 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 83 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 84 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
