| Ref | Part Number | Description |
|---|
| 1 |
98-1880-03 |
KNUCKLE-PIVOT This part replaces 98-1880-01. Price: $350.23 |
| 2 |
532007070 |
KEY 1/4 X 2.5 Price: $4.99 |
| 2 |
93-6696 |
DECAL-WARNING Price: $14.78 |
| 3 |
532007563 |
WASHER T Price: $6.99 |
| 3 |
99-5610 |
PIN Price: $40.16 |
| 4 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 5 |
596322601 |
Nuts This part replaces 532171168. Price: $2.99 |
| 6 |
596029501 |
Pins This part replaces 532171165. Price: $2.99 |
| 6 |
94-8947 |
BUSHING-FLANGE Price: $4.54 |
| 7 |
532140507 |
HUB ASMBLY Price: $149.99 |
| 9 |
596218701 |
Bolts This part replaces 532171379. Price: $2.99 |
| 11 |
94-9974 |
RING-RETAINING Price: $0.70 |
| 14 |
140-6431 |
PIVOT PIN ASM This part replaces 95-7158. Price: $37.92 |
| 15 |
138-6952 |
CYLINDER ASM-HYDRAULIC This part replaces 99-2550. Price: $664.52 |
| 15 |
596322601 |
Nuts This part replaces 532171168. Price: $2.99 |
| 16 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 17 |
532140921 |
SPRING.ROD.BRAKE Price: $3.99 |
| 19 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 20 |
302-61 |
FITTING-GREASE Price: $10.99 |
| 20 |
873940800 |
NUT.HEX.1/2-20 This part replaces 532171128. Price: $3.99 |
| 21 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 22 |
532156103 |
SHAFT ARM ASM Price: $37.99 |
| 22 |
92-7548 |
PIN-CYLINDER Price: $16.62 |
| 23 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 23 |
532140845 |
KNOB.DELUXE.(PISTOL.GRIP).BLAC Price: $11.99 |
| 24 |
2412-96 |
CLAMP-R Price: $3.46 |
| 27 |
82-6840 |
SPACER Price: $3.31 |
| 28 |
322-7 |
SCREW-HH Price: $0.89 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 532171163. Price: $4.99 |
| 29 |
532140494 |
BRAKE ROD This part replaces 532171404. Price: $10.99 |
| 29 |
99-2560 |
PIN Price: $105.63 |
| 30 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 30 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 532171140. Price: $2.99 |
| 31 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 32 |
105-0108 |
LIFT ARM ASM # 3 This part replaces 99-2563. Price: $587.29 |
| 33 |
105-0107 |
LIFT ARM ASM # 2 This part replaces 99-2562. Price: $971.54 |
| 33 |
812000053 |
E RING HYT Price: $3.99 |
| 34 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 34 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 35 |
532137648 |
PARKING BRAKE ROD This part replaces 532171459. Price: $9.99 |
| 35 |
99-5608-03 |
SPRING-TORSION, RH This part replaces 99-5608. Price: $35.46 |
| 36 |
532149412 |
SPRING DRIVE GROUND Price: $4.99 |
| 36 |
99-5609-03 |
SPRING-TORSION, LH This part replaces 99-5609. Price: $35.46 |
| 37 |
532121749 |
WASHER This part replaces 532171038. Price: $2.99 |
| 37 |
67-6570 |
SPACER-WHEEL Price: $15.99 |
| 38 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 38 |
532150035 |
NYLINER Price: $3.99 |
| 39 |
874321016 |
Screw, Fin. #10-24 x 1 This part replaces 532171413. Price: $2.99 |
| 40 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 40 |
532178575 |
ACTUATOR INTERLOCK SWITCH This part replaces 532005304. Price: $3.99 |
| 41 |
873661000 |
Nut Toplock #10-24 UNC This part replaces 532171414. Price: $0.61 |
| 41 |
98-7974 |
WASHER-THRUST Price: $37.96 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 42 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 43 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 44 |
3-6781 |
WASHER-THRUST Price: $1.40 |
| 45 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 46 |
106-9004 |
BUMPER This part replaces 99-5605. Price: $6.35 |
| 46 |
532145170 |
RETAINER SPRING Price: $3.99 |
| 47 |
283-71 |
PIN-LYNCH Price: $2.73 |
| 47 |
532138228 |
CLUTCH ROD Price: $6.99 |
| 48 |
302-11 |
FITTING-LUBE, 45 DEG Price: $1.56 |
| 48 |
596136101 |
GSPW Bolts This part replaces 532171180. Price: $2.99 |
| 49 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 50 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 51 |
596322601 |
Nuts This part replaces 532171408. Price: $2.99 |
| 52 |
532139123 |
PULLEY.IDLER.V. Price: $32.99 |
| 53 |
532000207 |
WASHER T Price: $4.99 |
| 54 |
532161590 |
CLUTCH.ARM.ASM.IDLER.98 Price: $18.99 |
| 55 |
108-6715 |
GAUGE BAR ASM This part replaces 98-1852. Price: $148.12 |
| 55 |
532105706 |
BEARING LT (2 2) Price: $5.99 |
| 56 |
532140218 |
V-BELT. Price: $49.99 |
| 61 |
532140488 |
PULLEY This part replaces 532171484. Price: $37.99 |
| 64 |
532154752 |
SHAFT CLUTCH/BRAKE PEDAL Price: $39.99 |
| 65 |
532179613 |
BOLT.SHLDR.3/8-16 This part replaces 532171423. Price: $4.99 |
| 66 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 67 |
596134901 |
GSPH This part replaces 532171151. Price: $2.99 |
| 68 |
532005142 |
ROLL PIN STD Price: $3.99 |
| 69 |
532123800 |
WASHER This part replaces 532171378. Price: $3.99 |
| 70 |
532164892 |
FENDER CONSOLE This part replaces 532166624. Price: $16.99 |
| 71 |
532151179 |
PLATE CONSOLE SHIFT Price: $2.99 |
| 72 |
596040501 |
Hardware This part replaces 532171026. Price: $2.99 |
| 73 |
874490548 |
BOLT HEX FLGHD 5/16-18X3 GR. 5 This part replaces 532171400. Price: $4.99 |
| 74 |
596134101 |
Screws This part replaces 532171370. Price: $2.99 |
| 76 |
532140481 |
BRACKET TRANSAXLE Price: $5.99 |
| 77 |
596238601 |
Bolts This part replaces 532171330. Price: $2.99 |
| 79 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 532171401. Price: $2.99 |
| 80 |
532140484 |
TORQUE BRACKET RH Price: $2.99 |
| 81 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 532171154. Price: $3.99 |
| 82 |
532154561 |
KIT.BRAKET/HDW.MOUNT.HYDRO This part replaces 532150586. Price: $14.99 |
| 83 |
532140479 |
STRAP TORQUE MID Price: $5.99 |
| 84 |
532140490 |
SPACER Price: $5.99 |
| 85 |
817541020 |
Screw #10-24 x 1-1/4 This part replaces 532171402. Price: $3.99 |
| 86 |
532140462 |
FAN 7" HYDRO Price: $9.99 |
| 87 |
532140491 |
ADAPTOR.FAN.TRANSAXLE.VGTH Price: $7.99 |
| 88 |
532161592 |
PULLEY Price: $29.99 |
| 89 |
873680700 |
Locknut 7/16-14 This part replaces 532171331. Price: $2.99 |
| 90 |
532140489 |
KEEPER.BELT Price: $6.99 |
| 91 |
596564005 |
BOLT This part replaces 532171403. Price: $8.99 |
| 92 |
595305701 |
Screws This part replaces 532171409. Price: $3.99 |
| 93 |
532140502 |
LINK ASM SHIFT Price: $52.99 |
| 94 |
532133835 |
FASTENER.XMAS.TREE Price: $3.99 |
| 96 |
532141103 |
WASHER Price: $3.99 |
| 98 |
532141004 |
SHIFT BRACKET Price: $3.99 |
| 99 |
817060624 |
SCREW 3/8-16 X 1-1/2 This part replaces 532171411. Price: $4.99 |
| 100 |
532126881 |
WASHER Price: $3.99 |
| 101 |
532156106 |
WASHER BELLVILLE Price: $2.38 |
| 104 |
532140480 |
BRACKET IDLER Price: $3.99 |
| 105 |
596437001 |
Screws This part replaces 532171399. Price: $2.99 |
| 106 |
532142918 |
O-RING KIT 70110 Price: $22.99 |
| 107 |
532154739 |
LINE.VENT.HYDRO-GEAR Price: $4.99 |
| 108 |
532142578 |
VENT CAP 70109 This part replaces 532142917. Price: $37.99 |
| 109 |
532140929 |
RETURN SPRING Price: $14.99 |
| 111 |
532156240 |
SPACER SHIFT LEVER VGTH Price: $2.99 |
| 112 |
532178558 |
WASHER NYLON HIGH TEMP This part replaces 532156104. Price: $4.99 |
| 113 |
873220700 |
NUT This part replaces 532171412. Price: $2.99 |
| 115 |
532156109 |
BELT KEEPER KIT This part replaces 532171428. Price: $3.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 532171429. Price: $2.99 |
| 117 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532171422. Price: $3.99 |
