| Ref | Part Number | Description |
|---|
| 1 |
532170863 |
CONTROL,TH/CH FLAG This part replaces 532155274. Price: $27.99 |
| 2 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 3 |
323-8 |
SCREW-HH Price: $1.20 |
| 4 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
340-105 |
FITTING-ELBOW, 90 DEG Price: $39.67 |
| 5 |
583954501 |
PIPE.EXHAUST.LH.CV18/20 This part replaces 532146699. Price: $19.99 |
| 6 |
340-139 |
FITTING-ELBOW 90 Price: $117.76 |
| 6 |
583954801 |
PIPE.EXHAUST.RH.CV18/20 This part replaces 532146700. Price: $17.99 |
| 7 |
340-18 |
FITTING-HYD, 90 DEG Price: $38.93 |
| 8 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 9 |
56-9530 |
FITTING-HYD, 90 DEG Price: $109.45 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 10 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 11 |
105-1214 |
HOSE-HYD Price: $327.26 |
| 12 |
104-4845 |
HOSE-SUCTION Price: $162.85 |
| 13 |
32128-54 |
NUT-HF Price: $5.25 |
| 14 |
813280336 |
Nipple, Pipe 3/8 NPT x 4-1/2 Price: $2.42 |
| 14 |
99-3529 |
SHAFT-PIVOT, IDLER Price: $87.59 |
| 15 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 15 |
532428287 |
VALUE.OIL.DRAIN This part replaces 813200300. Price: $14.99 |
| 16 |
32128-21 |
NUT-HF Price: $0.39 |
| 17 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 18 |
323-10 |
SCREW-HH Price: $0.89 |
| 19 |
74-1810 |
WASHER Price: $0.39 |
| 20 |
95-8802 |
PULLEY-IDLER Price: $72.50 |
| 21 |
95-8806 |
SPACER Price: $9.91 |
| 22 |
95-8917 |
SPRING-TORSION Price: $17.88 |
| 23 |
137-1653 |
IDLER ARM ASM This part replaces 99-3623-03. Price: $37.07 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 25 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 25 |
532145996 |
CONTROL, CHOKE Price: $19.99 |
| 26 |
323-19 |
SCREW-HH Price: $1.70 |
| 26 |
873920600 |
Nut Keps 3/8 - 24 UNF Price: $3.99 |
| 27 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 28 |
99-3436-0P |
SUPPORT-PUMP This part replaces 99-3436-03. Price: $150.02 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
99-3440 |
SPACER Price: $6.78 |
| 30 |
33114-060 |
SCREW-HH Price: $0.88 |
| 31 |
532151346 |
FUEL TANK 3.5G Price: $84.99 |
| 31 |
87-8640 |
WASHER-FLAT Price: $0.68 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532140527. Price: $22.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 33 |
95-8933-0P |
PLATE - PUMP MOUNT *B This part replaces 95-8933-03. Price: $105.46 |
| 34 |
532106082 |
PAD-SPACER LT Price: $3.99 |
| 34 |
95-8941 |
SPACER-MOUNT, PUMP Price: $8.87 |
| 35 |
93-6841 |
PULLEY Price: $209.67 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 38 |
93-6842 |
BUSHING-LOCK, TAPER Price: $75.86 |
| 39 |
532109227 |
PAD IDLER TI Price: $3.99 |
| 39 |
95-8730 |
V-BELT Price: $35.43 |
| 40 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
| 40 |
70-2041 |
TRIM Price: $5.30 |
| 41 |
100-4852 |
WASHER-HARDENED Price: $4.63 |
| 41 |
532139277 |
STEM FUEL TANK Price: $6.99 |
| 101 |
596433401 |
Nuts This part replaces 532163305. Price: $2.99 |
