| Ref | Part Number | Description |
|---|
| 1 |
01-182-0816 |
BOLT-HH Price: $2.85 |
| 1 |
532186094 |
STEERING WHEEL.PREM.2.BLK This part replaces 532193651. Price: $169.99 |
| 2 |
3217-9 |
NUT-HH Price: $0.37 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 3 |
596873901 |
KIT SPINDLE ASM.PNT.LH.15 This part replaces 532169840. Price: $14.99 |
| 3 |
93-6586 |
BUSHING Price: $26.89 |
| 4 |
596873801 |
KIT SPINDLE ASM.PNT.RH.15" This part replaces 532169839. Price: $27.99 |
| 4 |
93-6587 |
BEARING Price: $14.99 |
| 5 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 5 |
93-6584 |
KING PIN ASM Price: $68.03 |
| 6 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 6 |
532121748 |
WASHER Price: $3.99 |
| 7 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 8 |
121-5087-03 |
FRONT AXLE ASM Price: $1,295.09 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
138-6102 |
CYLINDER ASM This part replaces 93-6510. Price: $1,096.53 |
| 10 |
532175121 |
DRAGLINK.15".TIRES.2001 Price: $59.99 |
| 10 |
93-6509 |
END-TIE ROD This part replaces 93-6509-03. Price: $98.38 |
| 11 |
117-5899-03 |
LH SPINDLE HOUSING ASM Price: $973.03 |
| 11 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 12 |
87-1470-03 |
END-TIE ROD, LH Price: $101.78 |
| 13 |
3218-21 |
NUT-JAM Price: $3.19 |
| 13 |
532136518 |
TUBE, PIVOT AXLE Price: $7.99 |
| 14 |
93-6588-03 |
ROD-STEERING This part replaces 93-6588. Price: $296.55 |
| 15 |
32136-13 |
NUT-SHH Price: $2.85 |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 16 |
3220-11 |
NUT-JAM Price: $0.81 |
| 17 |
532190753 |
SHAFT STEERING SPLINE Price: $37.99 |
| 17 |
87-1480-03 |
END-TIE ROD, RH Price: $101.78 |
| 18 |
117-5897-03 |
SPINDLE ASM Price: $461.32 |
| 19 |
119-6003 |
HUB ASM Price: $163.68 |
| 20 |
127-1100 |
WHEEL AND TIRE ASM Price: $422.57 |
| 21 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 22 |
87-7270 |
WASHER-THRUST Price: $0.89 |
| 23 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 29 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 32 |
532170162 |
ROD.ASM.TIE.BALL.JOINT.NOVAN Price: $79.99 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
873540500 |
NUT, CROWNLOCK Price: $3.99 |
| 36 |
532155106 |
KIT.BUSHING.STEERING This part replaces 532155099. Price: $8.99 |
| 37 |
532152927 |
SCREW.TT.#10-32X.5.3/8.FLANGE Price: $3.99 |
| 38 |
532193652 |
INSERT.CAP.STRG.WH.GRAY Price: $11.99 |
| 39 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 40 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 41 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 43 |
532121749 |
WASHER Price: $2.99 |
| 44 |
532190752 |
SHAFT.EXTEN.STRG.SPLINE Price: $11.99 |
| 46 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 65 |
532414736 |
SPACER.BRACE.AXLE This part replaces 532160367. Price: $5.99 |
| 67 |
872110618 |
BOLT CARRIAGE Price: $4.99 |
| 68 |
531167401 |
SERVICE KIT BRACE.AXLE.1 This part replaces 532169827. Price: $19.99 |
| 71 |
531167801 |
SERVICE KIT STEERING ASM This part replaces 532175146. Price: $139.99 |
| 82 |
531170201 |
SERVICE.KIT BRACKET This part replaces 532199978. Price: $19.99 |
| 87 |
532173966 |
WASHER, FLAT .781 X 1 1/2" Price: $4.99 |
| 88 |
532175118 |
BOLT, SHOULDER 7/16-20 Price: $4.99 |
| 91 |
532175553 |
CLIP.STEERING Price: $9.99 |
| 95 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 97 |
874780564 |
BOLT Price: $4.99 |
