| Ref | Part Number | Description |
|---|
| 1 |
132-7105 |
SHAFT-GROOMER, FAIRWAY Price: $298.12 |
| 1 |
873510500 |
Nut, Keps 5/16-18 (AYP part number) Price: $5.99 |
| 2 |
140-5606 |
SPACER-SS This part replaces 107-4430. Price: $2.49 |
| 2 |
539990118 |
SLW 3/8 STD This part replaces 810040600. Price: $1.99 |
| 3 |
130-4105 |
BLADE-GROOMER Price: $4.43 |
| 3 |
873220600 |
Nut, Hex 3/8-16 (AYP part number) Price: $3.99 |
| 4 |
140-5616 |
SPACER-SS This part replaces 70-1350. Price: $2.60 |
| 4 |
874930568 |
Bolt, Hex 5/16-18 x 4-1/4 (AYP part number) Price: $5.99 |
| 5 |
3296-60 |
NUT-LOCK, NI Price: $5.08 |
| 5 |
532001572 |
Pin, Roll, 3/16 x 1 (AYP part number) This part replaces 532124963. Price: $3.99 |
| 6 |
532110111 |
Lever, Shift Price: $11.99 |
| 7 |
872110404 |
Bolt, Carriage 1/4-20 x 1/2 Gr. 5 (AYP part number) Price: $3.99 |
| 8 |
532008700 |
Plate, Shift Indicator (AYP part number) Price: $2.99 |
| 9 |
532086777 |
Screw, Hex, Washer Head, Slotted #10-24 x 1/2 (AYP part number) Price: $1.99 |
| 10 |
532009484 |
Clip (AYP part number) Price: $3.99 |
| 11 |
810040400 |
Washer, Lock 1/4 (AYP part number) Price: $3.99 |
| 12 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $3.99 |
| 13 |
823230506 |
Screw, Set, Hex 5/16-18 x 3/8 (AYP part number) Price: $2.99 |
| 14 |
532120938 |
Spacer, Split 0.327 x 0.42 x 2.68 (AYP part number) Price: $2.70 |
| 15 |
734116301 |
WASHER - 15X7.3X1.6 This part replaces 819111116. Price: $2.99 |
| 16 |
532100473 |
Sheave, Transmission (AYP part number) Price: $30.75 |
| 17 |
873220500 |
Nut, Hex 5/16-18 (AYP part number) Price: $3.99 |
| 18 |
532110651 |
Spacer, Split 0.327 x 0.42 x 1.75 (AYP part number) Price: $2.99 |
| 19 |
532002649 |
Key, Square 3/16 x 1-1/8 (AYP part number) Price: $2.99 |
| 20 |
532110653 |
Guard, Pinch Point (AYP part number) Price: $3.57 |
| 21 |
532131691 |
Spacer, Split 0.327 x 0.42 x 1.627 (AYP part number) Price: $3.99 |
| 22 |
532104214 |
Nut, Cap 5/16-18 (AYP part number) Price: $2.99 |
| 23 |
532005015 |
Tire (AYP part number) Price: $99.99 |
| 24 |
532126875 |
Rivet, Drilled (AYP part number) Price: $2.99 |
| 25 |
532004497 |
RETAINER M This part replaces 532124788. Price: $5.99 |
| 26 |
532125341 |
Guard, Belt (AYP part number) Price: $3.33 |
| 27 |
532132801 |
Belt, V (AYP part number) Price: $19.99 |
| 28 |
532104679 |
Pulley, Idler (AYP part number) Price: $11.99 |
| 29 |
812000032 |
Ring, Klip (AYP part number) Price: $3.99 |
| 30 |
584289401 |
BRACKET.IDLER.ASM.SHORT This part replaces 532105611. Price: $11.99 |
| 31 |
532102384 |
Bolt, Hex 5/16-16 x 12 (AYP part number) Price: $3.99 |
| 32 |
532102141 |
Shaft, Idler Arm (AYP part number) Price: $3.99 |
| 33 |
874780616 |
BOLT This part replaces 874760616. Price: $3.99 |
| 34 |
532102383 |
Counterweight, L. H. (AYP part number) Price: $89.99 |
| 35 |
539976935 |
CAPSCREW 5/16 X 1/1/2 HEX HEAD This part replaces 874760524. Price: $1.99 |
| 36 |
584366901 |
BRACKET.REINFORCEMENT.LH.PNT This part replaces 532102331. Price: $5.99 |
| 37 |
532130812 |
Sheave, Engine (AYP part number) Price: $17.99 |
| 38 |
532131556 |
Bracket, Guard Belt Price: $6.39 |
| 532065139 |
VALVE |
STEM LT This part replaces 532124718. Price: $5.99 532065139 |
