| Ref | Part Number | Description |
|---|
| 1 |
93-4422-01 |
GUARD-BELT Price: $650.61 |
| 2 |
93-4034 |
V-BELT Price: $204.67 |
| 3 |
532007563 |
WASHER T Price: $6.99 |
| 3 |
93-4001 |
PULLEY-4 GROOVE This part replaces 93-4001-01. Price: $473.22 |
| 4 |
323-4 |
SCREW-HH Price: $1.02 |
| 4 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 5 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 5 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 6 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 6 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 7 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 7 |
532634692 |
HUB.ASSEMBLY.WHEEL.REAR This part replaces 532149176. Price: $42.99 |
| 8 |
325-14 |
SCREW-HH Price: $2.64 |
| 8 |
812000034 |
Ring, Klip Truarc #5304-75 Price: $2.99 |
| 9 |
3217-7 |
NUT-HEX Price: $0.28 |
| 9 |
596218701 |
Bolts This part replaces 532140080. Price: $2.99 |
| 10 |
13-2680 |
BUSHING Price: $217.68 |
| 10 |
532142509 |
DISC BRAKE Price: $17.99 |
| 11 |
532136927 |
YOKE-BRAKE DISC Price: $9.99 |
| 11 |
93-4445-01 |
ARM-TRAILING, RH This part replaces 93-4445. Price: $634.65 |
| 12 |
93-4428 |
SPACER-PULLEY Price: $21.92 |
| 13 |
532139419 |
WASHER Price: $4.99 |
| 13 |
93-4434 |
SUPPORT BRACKET WA Price: $151.43 |
| 14 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 14 |
532138901 |
BUSHING Price: $4.99 |
| 15 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 16 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 16 |
532143012 |
SET SCREW Price: $2.99 |
| 17 |
532126909 |
SPRING,ROD BRAKE Price: $4.99 |
| 17 |
93-4433-01 |
BRACKET-PULLEY Price: $40.65 |
| 18 |
327-6 |
SCREW-HH Price: $12.99 |
| 18 |
532137104 |
BRAKE LEVER Price: $5.99 |
| 19 |
532136926 |
BRAKE DISC CAM Price: $11.99 |
| 21 |
56-6230 |
BEARING-ROLLER Price: $72.34 |
| 21 |
823260412 |
Screw, Flat Head 1/4-28 x 3/4 Price: $3.99 |
| 22 |
13-4960 |
SHAFT-PLATE, FINGER Price: $126.35 |
| 22 |
532194121 |
LEVER.ASM.SHIFT Price: $64.99 |
| 23 |
13-2840 |
KEY-SQUARE Price: $1.40 |
| 23 |
532106932 |
KNOB T (3/8 HOLE) Price: $6.99 |
| 24 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 24 |
532136925 |
BRAKE PUCK SUPPORT Price: $3.99 |
| 25 |
115-9026 |
END PLATE ASM This part replaces 93-0189. Price: $75.83 |
| 25 |
532136923 |
BRAKE PUCK TOP Price: $14.99 |
| 26 |
144-3697-01 |
FLEX TIP REEL This part replaces 93-0197. Price: $1,218.97 |
| 26 |
532137552 |
RETURN SPRING Price: $4.99 |
| 27 |
115-9024 |
PLATE-CENTER This part replaces 93-0185. Price: $49.00 |
| 27 |
532193135 |
SCREW Price: $2.66 |
| 28 |
115-9028 |
END PLATE ASM This part replaces 93-0187. Price: $71.85 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
115-9022 |
FINGER-PLASTIC This part replaces 13-2470. Price: $1.83 |
| 29 |
532137213 |
ROD BRAKE ZINC GT Price: $20.99 |
| 30 |
13-3090 |
SPRING-FINGER Price: $9.71 |
| 30 |
596140201 |
Washers This part replaces 819131616. Price: $2.99 |
| 31 |
115-9023 |
CLAMP-FINGER This part replaces 13-2480. Price: $5.46 |
| 32 |
32140-94 |
SCREW-HH, SEMS Price: $5.89 |
| 33 |
120-5986 |
HOOK-TRANSPORT This part replaces 93-7711. Price: $70.97 |
| 34 |
13-0560 |
SPACER Price: $5.29 |
| 34 |
532071673 |
PLUNGER CAP Price: $4.99 |
| 35 |
532137648 |
PARKING BRAKE ROD Price: $9.99 |
| 35 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 36 |
13-0360 |
SPACER Price: $13.03 |
| 36 |
532149412 |
SPRING DRIVE GROUND Price: $4.99 |
| 37 |
13-3070 |
SPACER Price: $8.69 |
| 37 |
532121749 |
WASHER Price: $2.99 |
| 38 |
32153-5 |
NUT-HEX Price: $1.59 |
| 38 |
532150035 |
NYLINER Price: $3.99 |
| 39 |
13-5540-01 |
LIFTING LINK This part replaces 13-5540. Price: $40.11 |
| 39 |
874321016 |
Screw, Fin. #10-24 x 1 Price: $2.99 |
| 40 |
328-10 |
SCREW-HH Price: $14.93 |
| 40 |
532178575 |
ACTUATOR INTERLOCK SWITCH Price: $3.99 |
| 41 |
63-5300 |
DISCONTINUED Price: Call Us |
| 42 |
32153-6 |
NUT-LOCK Price: $3.46 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 43 |
325-9 |
SCREW-HH Price: $1.87 |
| 44 |
323-9 |
SCREW-HH Price: $1.29 |
| 45 |
13-0320 |
COLLAR-LOCK Price: $42.44 |
| 46 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 46 |
532145170 |
RETAINER SPRING Price: $3.99 |
| 47 |
13-0330 |
BLOCK-PIVOT Price: $112.26 |
| 47 |
532138228 |
CLUTCH ROD Price: $6.99 |
| 48 |
13-5550-01 |
ARM-WHEEL, GAUGE Price: $504.47 |
| 48 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 49 |
13-5570 |
PIVOT Price: $47.91 |
| 50 |
117-8544 |
WHEEL-CASTER This part replaces 13-2870. Price: $120.71 |
| 50 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 51 |
13-5590 |
ROD-ADJUSTING Price: $108.27 |
| 51 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 52 |
13-5670 |
SPACER-LOCKING Price: $189.75 |
| 52 |
532139123 |
PULLEY.IDLER.V. Price: $32.99 |
| 53 |
3217-9 |
NUT-HH Price: $0.37 |
| 54 |
93-4415-01 |
PULLEY - IDLER This part replaces 93-4415. Price: $63.14 |
| 55 |
325-5 |
SCREW-HH Price: $1.20 |
| 55 |
532105706 |
BEARING LT (2 2) Price: $5.99 |
| 56 |
532137153 |
V-BELT GROUND DRIVE Price: $59.99 |
| 56 |
63-5250 |
SPACER-ARM Price: $93.57 |
| 57 |
3254-8 |
WASHER-LOCK Price: $0.37 |
| 57 |
532141756 |
BRACKET SHIFT ROD Price: $3.99 |
| 58 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 59 |
256-298 |
BUSHING Price: $22.19 |
| 59 |
532122253 |
ROD SHIFT HI LO Price: $14.99 |
| 60 |
532122268 |
CONNECTING LINK Price: $4.99 |
| 60 |
93-4429 |
WASHER-PULLEY Price: $8.07 |
| 61 |
323-10 |
SCREW-HH Price: $0.89 |
| 61 |
532184787 |
PULLEY.TRANSAXLE Price: $59.99 |
| 62 |
117-8544 |
WHEEL-CASTER This part replaces 93-7715. Price: $120.71 |
| 62 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 63 |
323-5 |
SCREW-HH Price: $0.41 |
| 63 |
874780720 |
BOLT, HEX Price: $5.99 |
| 64 |
532154752 |
SHAFT CLUTCH/BRAKE PEDAL Price: $39.99 |
| 65 |
532179613 |
BOLT.SHLDR.3/8-16 Price: $4.99 |
| 66 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 67 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 68 |
532005142 |
ROLL PIN STD Price: $3.99 |
| 69 |
532136327 |
COVER.HUB.BLACK Price: $4.99 |
| 117 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 155 |
812000028 |
RETAINING RING LT Price: $1.99 |
| 157 |
532001370 |
THRUST WASHER Price: $4.99 |
