| Ref | Part Number | Description |
|---|
| 1 |
117-8004 |
TANK-RINSE, 30 GALLON Price: $659.43 |
| 1 |
588479201 |
CABLE.DRIVE.S/S.22+.FWGD This part replaces 532424919. Price: $17.99 |
| 2 |
107-8641 |
CAP-WATER, FRESH Price: $11.74 |
| 3 |
106-4896 |
FITTING-BULKHEAD Price: $25.30 |
| 4 |
100-6713 |
NUT-BULKHEAD Price: $7.19 |
| 5 |
106-4940 |
HOSEBARB-90 DEG Price: $42.11 |
| 6 |
136-2314-03 |
HOLD DOWN-TANK, RINSE Price: $21.57 |
| 7 |
119-0489 |
BULKHEAD Price: $45.11 |
| 7 |
532435281 |
BAIL.DRIVE.S/S.ROUND.MARI.21 Price: $8.99 |
| 8 |
119-0490 |
ELBOW-HOSEBARB Price: $4.72 |
| 9 |
117-7872 |
PUMP-RINSE Price: $1,424.28 |
| 10 |
119-0496 |
HOSEBARB Price: $3.81 |
| 11 |
108-3439 |
TEE Price: $10.76 |
| 12 |
119-0491 |
HOSE-SUPPLY Price: $50.49 |
| 12 |
812000058 |
E-RING 7/16 RE Price: $1.99 |
| 13 |
532403849 |
PINION.14.TEETH.FGD Price: $3.99 |
| 14 |
119-0493 |
HOSE-SUPPLY, RINSE Price: $19.86 |
| 14 |
581840401 |
COVER.DUST.WHEEL.INNER.WALK Price: $2.99 |
| 15 |
100-6708 |
FORK Price: $5.54 |
| 15 |
532404845 |
PAWL, DRIVE Price: $2.99 |
| 16 |
119-0479 |
NOZZLE-RINSE Price: $52.71 |
| 16 |
532067725 |
WASHER FLUT Price: $3.99 |
| 17 |
119-4881 |
BOLT-SHOULDER Price: $4.07 |
| 18 |
119-0528 |
BUSHING Price: $0.41 |
| 18 |
532701037 |
SELECTOR KNOB Price: $2.99 |
| 19 |
120-8635 |
VAIN-RINSE Price: $17.26 |
| 21 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 22 |
321-10 |
SCREW-HH Price: $1.29 |
| 23 |
32128-33 |
NUT-HF Price: $0.25 |
| 25 |
119-4898 |
COVER-PUMP, RINSE Price: $106.26 |
| 25 |
532430458 |
BRACKET.BELT.GUIDE.22+FGD This part replaces 532431711. Price: $2.99 |
| 26 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 26 |
532163409 |
SCREW Price: $3.99 |
| 27 |
323-8 |
SCREW-HH Price: $1.20 |
| 28 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 28 |
532432674 |
COVER.DR.ASM.421086.CE Price: $11.99 |
| 29 |
2412-129 |
CLAMP-HOSE Price: $2.10 |
| 29 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT Price: $2.99 |
| 32 |
532443262 |
PULLEY.DRIVE.EZ/VARI.SCREWON Price: $8.99 |
| 33 |
120-0695 |
SWITCH-ROCKER, ON-OFF-(ON) Price: $84.99 |
| 33 |
532196853 |
BELT.DRIVE.FGD. Price: $12.99 |
| 34 |
119-5778 |
TIMER-DELAY Price: $280.43 |
| 35 |
2412-106 |
CLAMP-R Price: $2.04 |
| 36 |
532424741 |
TRANSMISSION.22+.FWGD.SS Price: $64.99 |
| 36 |
99-7430 |
RELAY-MINI Price: $22.99 |
| 37 |
99-7435 |
RELAY Price: $32.43 |
| 38 |
3290-321 |
SCREW-HWH Price: $3.99 |
| 38 |
532191730 |
NUT.HEX.FLANGE.1/4 Price: $3.99 |
| 39 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 40 |
120-0721 |
CONDUIT-CONVOLUTED Price: $10.68 |
| 40 |
532406558 |
SPRING Price: $2.99 |
| 41 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 42 |
122-0859 |
SWITCH-ROCKER, ON-OFF-(ON) Price: $51.96 |
| 54 |
580947309 |
GBAG.A1640416S.BLK.PPRO.MRG. Price: $49.99 |
