| Ref | Part Number | Description |
|---|
| 2 |
82341 |
Recoil Starter Guard Price: $111.20 |
| 3 |
22769GS |
WASHER, SHAKE PROOF INT.# 10 This part replaces 22769. Price: $2.49 |
| 5 |
5045771B |
SKID PLATE This part replaces 45771. Price: $55.95 |
| 6 |
10953621 |
Ground Wire Price: Call Us |
| 7 |
27482GS |
WASHER, 5/16" Ext. Shakeproof This part replaces 27482. Price: $2.19 |
| 8 |
83990 |
Cradle Price: Call Us |
| 9 |
24911GS |
TRILOBLAR, 8-32 x 3/8 This part replaces 24911. Price: $2.64 |
| 10 |
38150GS |
WASHER This part replaces 38150. Price: $2.49 |
| 11 |
22769GS |
WASHER, SHAKE PROOF INT.# 10 This part replaces 22769. Price: $2.49 |
| 12 |
22129GS |
WASHER, Lock This part replaces 22129. Price: $2.61 |
| 14 |
66443BGS |
MNT, VIBR, GEN 1.25OD This part replaces 66443B. Price: $16.79 |
| 15 |
66365FGS |
HSNG, ENG, FML This part replaces 66365F. Price: $63.99 |
| 17 |
80023G |
Rotor Assembly Price: Call Us |
| 18 |
65791GS |
BEARING This part replaces 65791. Price: $32.00 |
| 19 |
67451 |
Flat Washer (special) Price: Call Us |
| 20 |
36180GS |
HHCS, 5/16-24 X 6 3/8 This part replaces 36180. Price: $9.39 |
| 21 |
84292 |
Stator Assembly Price: Call Us |
| 22 |
52618GS |
SCREW, M5 x 0.8 x 12 This part replaces 52618. Price: $2.64 |
| 23 |
81887F |
Stator Wrapper Price: Call Us |
| 24 |
52856GS |
NUT, LOCKING-M5 This part replaces 52856. Price: $2.59 |
| 25 |
66825 |
Rear Bearing Carrier Price: Call Us |
| 26 |
66386GS |
ASSEMBLY, BRUSH HOLDER This part replaces 66386. Price: $21.52 |
| 27 |
66443A |
Vibration Mount Price: Call Us |
| 28 |
49815GS |
HHCS, M5-0.8 X 16 This part replaces 66849. Price: $2.96 |
| 29 |
66850GS |
ASSY, RECTIFIER, BRIDGE This part replaces 66850. Price: Call Us |
| 30 |
66449B |
M6-1.0 x 90mm Stator Bolt Price: Call Us |
| 31 |
5022097SM |
CAP This part replaces 22097. Price: $2.75 |
| 32 |
67022GS |
GROMMET, RUBBER This part replaces 67022. Price: $2.55 |
| 33 |
84277 |
Back Panel Cover Price: Call Us |
| 34 |
84276 |
Control Panel Price: Call Us |
| 35 |
63036GS |
CRIMPTITE, #8-18X1/4L This part replaces 63036. Price: $2.25 |
| 36 |
74908GS |
TAPTITE, M5-0.8 x 10 LG. This part replaces 74908. Price: $2.69 |
| 37 |
25433 |
Grounding Lug Price: Call Us |
| 38 |
67025 |
Bearing Carrier Cover Price: Call Us |
| 39 |
83706GS |
OUTLET, 230V 16A, BLUE This part replaces 83706. Price: $28.20 |
| 40 |
76040GS |
SCREW This part replaces 76040. Price: $2.64 |
| 42 |
75207DGS |
BREAKER, Circuit This part replaces 75207D. Price: $12.69 |
| 43 |
82881GS |
WASHER, 7/16" Int Lock This part replaces 82881. Price: Call Us |
| 44 |
49226GS |
WASHER, M5 Lock This part replaces 49226. Price: $1.89 |
| 45 |
51716GS |
NUT, M5 x 0.8 This part replaces 51716. Price: $2.30 |
| 46 |
84302 |
Generac Decal Price: Call Us |
| 47 |
84313 |
Strain Relief Price: Call Us |
