| Ref | Part Number | Description |
|---|
| 1 |
N/A |
ENGINE, TEC. 4HP, ELECTRIC START #TVS-105- 53629J |
| 2 |
1908115 |
PLUG-OIL DRAIN Not Available Price: |
| 2A |
1908179 |
GASKET-DRAIN PLUG Not Available Price: |
| 4 |
94013 |
WASHER-FELT Price: Call Us |
| 5 |
40022 |
ASSM-BELT GUIDE PTO Price: Call Us |
| 6 |
97069 |
PIN-COTTER .188X1.5 Price: Call Us |
| 7 |
40020 |
PULLEY-ENG PTO MACHINE Price: Call Us |
| 8 |
90038 |
SCR-HFLK 5/16-18X.62 G5ZP Price: Call Us |
| 9 |
9848 |
NUT-HFLK 5/16-18 ZP Price: $10.95 |
| 10 |
97094 |
SPACER-1.125X.343X1.125 Price: Call Us |
| 11 |
55053 |
DECAL-HOT SURFACE Not Available Price: |
| 12 |
1901318 |
BELT COVER Not Available Price: |
| 13 |
1900396 |
SCREW-HW M10-32X.5 Not Available Price: |
| 14 |
1900962010 |
DECK PLATE Not Available Price: |
| 15 |
40158 |
DECAL-OIL DRAIN TUBE Price: Call Us |
| 16 |
1900969010 |
DECK SUPPO Not Available Price: |
| 17 |
90068 |
SCR HH 5/16-18X2.75 G8 Price: Call Us |
| 18 |
94020 |
WASHER-BELLEVILLE .328 ID Price: Call Us |
| 19 |
97041 |
KEY-WOODRUFF .156X.625 Price: Call Us |
| 20 |
40023 |
BEARING-BA Not Available Price: |
| 21 |
97066 |
RING-RET INTERNAL Price: Call Us |
| 22 |
9933 |
WASHER-1.25X.375X.1 Price: Call Us |
| 23 |
9925 |
WASHER-.994X.413X.145 Price: Call Us |
| 24 |
9549 |
SCR-HH 3/8-24X1.0 G5 Price: Call Us |
| 25 |
9831 |
NUT-HFLK 3/8-16 Price: Call Us |
| 26 |
40126 |
ARM-IDLER BLADE DR Price: Call Us |
| 27 |
97064 |
BUSHING-.5X.31X.843 LG Price: Call Us |
| 28 |
40142 |
KEY-SPECIA Not Available Price: |
| 29 |
90047 |
SCR-HFLK 3/8-16X1.50 Price: Call Us |
| 30 |
96404 |
SPRING-RETURN Price: Call Us |
| 31 |
690-900-0040 |
SCREW - HEX HEAD S Not Available This part replaces 9466. Price: |
| 32 |
9902 |
WASHER-FLAT 5/16 SAE Price: Call Us |
| 33 |
96403 |
SPRING-CABLE Price: Call Us |
| 34 |
97043 |
BELT-CUTTER BAR Price: Call Us |
| 35 |
40132 |
GUIDE-BELT Price: Call Us |
| 36 |
90065 |
SCR-HXFL 5/16-18X.5 G5 Price: Call Us |
| 37 |
1900952010 |
BELT COVER Not Available Price: |
| 38 |
1900970010 |
PAINTED GU Not Available Price: |
| 39 |
EB396800-2 |
SPARK ARRESTER ASSEMBLY Price: Call Us |
| 40 |
90002 |
SCREW, #8 x 3/8, HEX FLANGE LOCK, SELF- THREADING Price: Call Us |
| 41 |
GW-9929 |
Flat Washer This part replaces 9929. Price: $3.15 |
| 42 |
9919 |
WASHER-LK .312 EXT TOOTH Price: Call Us |
| 43 |
690-120-0058 |
BLADE - 21-1/2" x 1/2" Not Available This part replaces 94-019. Price: |
