| Ref | Part Number | Description |
|---|
| 1 |
114-5422 |
ROLLER-SHOULDER, PLASTIC Price: $525.86 |
| 1 |
530035017 |
Screw - Pump Cover Price: $0.99 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 2 |
530035191 |
Pump Cover Ass'y (incl. #28) Price: $3.99 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
504130906 |
GASKET This part replaces 530035164. Price: $1.99 |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
504130807 |
PUMP DIAPHRAGM This part replaces 530035166. Price: $2.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 6 |
530035192 |
Swivel Lever Ass'y. Price: $3.33 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 8 |
530035007 |
Clip - Throttle Shaft Price: Call Us |
| 13 |
530035016 |
Screw - Metering Lever Pin Price: $2.99 |
| 14 |
503896701 |
DIAPHRAGM This part replaces 530035014. Price: $4.99 |
| 15 |
530035149 |
Cover - Metering Diaphragm Price: $3.33 |
| 16 |
530035153 |
Screw Assembly - Metering Cover & Throttle Shaft Clip Price: $3.33 |
| 17 |
530035151 |
Gasket - Metering Diaphragm Price: $1.99 |
| 19 |
530035042 |
Plate - Circuit Price: $3.33 |
| 20 |
501781301 |
GASKET This part replaces 530035147. Price: $0.45 |
| 21 |
530035036 |
Spring - Hi Speed Needle Price: Call Us |
| 22 |
501782201 |
H-NEEDLE This part replaces 530035142. Price: $6.30 |
| 23 |
530035141 |
Needle - Idle Price: $2.99 |
| 24 |
530035023 |
Spring - Idle Needle Price: $0.99 |
| 25 |
530035192 |
Shaft Assembly - Throttle Price: $3.33 |
| 26 |
530035138 |
Spring - Throttle Return Price: Call Us |
| 27 |
530035133 |
Valve - Throttle Price: $3.33 |
| 28 |
530035156 |
Screw - Idle Adjustment Price: $1.99 |
| 29 |
530035185 |
Kit - Carb. Kwik Repair Price: $24.99 |
