| Ref | Part Number | Description |
|---|
| 1 |
117-8460 |
RH TRAILING ARM ASM Price: $808.58 |
| 1 |
532124416 |
INSERT,STR WHEEL Price: $7.89 |
| 2 |
117-8504-03 |
CRANK-BELL, LIFTING RH Price: $74.36 |
| 2 |
873610600 |
NUT This part replaces 532124701. Price: $2.99 |
| 3 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 4 |
3231-29 |
SCREW-CARR Price: $0.68 |
| 4 |
532124415 |
STEERING WHEEL Price: $58.99 |
| 5 |
105-4886 |
NUT-TINNERMAN This part replaces 112-4576. Price: $2.37 |
| 5 |
532127396 |
STEERING SLEEVE Price: $2.66 |
| 6 |
121-2771-03 |
BRACE-COVER, BELT Price: $57.73 |
| 6 |
817211008 |
Screw Slftp #10-16 x 1/2 Ty-Ab This part replaces 817431008. Price: $3.99 |
| 7 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 8 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 8 |
532148966 |
KIT.SERVICE.SHAFT.STEERING.LR This part replaces 532123651. Price: $119.99 |
| 9 |
3233-2 |
SCREW-CARR Price: $1.49 |
| 9 |
532124210 |
STEERING CLIP Price: $4.99 |
| 10 |
119-6188 |
TUBE-PIVOT Price: $4.23 |
| 10 |
532123438 |
BUSHING STEER LWR Price: $5.99 |
| 11 |
812000045 |
RING Price: $5.99 |
| 12 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 13 |
532104820 |
ADAPTER-WHEEL LT Price: $13.99 |
