| Ref | Part Number | Description |
|---|
| 1 |
3234-25 |
SCREW-HHF Price: $7.69 |
| 2 |
503974301 |
COVER Price: $5.99 |
| 2 |
71-4540 |
WASHER-THRUST Price: $1.97 |
| 3 |
503480501 |
SCREW Price: $2.99 |
| 3 |
63-6430-03 |
FRAME-REAR This part replaces 63-6430. Price: $757.78 |
| 4 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 4 |
537020201 |
COVER Price: $19.99 |
| 5 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 5 |
537020701 |
SCREW Price: $6.99 |
| 6 |
325-5 |
SCREW-HH Price: $1.20 |
| 6 |
503481101 |
PLUG Price: $3.99 |
| 7 |
503479601 |
SCREW Price: $2.99 |
| 7 |
63-6770-03 |
PIN-MASKED This part replaces 63-6770. Price: $145.71 |
| 8 |
321-4 |
SCREW-HH Price: $0.99 |
| 8 |
537048901 |
DIAPHRAGM Price: $11.99 |
| 9 |
537020401 |
GASKET Price: $3.99 |
| 9 |
67-1750 |
BUSHING Price: $0.92 |
| 10 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 10 |
537020101 |
GASKET Price: $3.99 |
| 11 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 11 |
537020001 |
PUMP DIAPHRAGM Price: $7.99 |
| 12 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 12 |
503535701 |
STRAINER Price: $3.99 |
| 13 |
503480101 |
SCREW Price: $2.99 |
| 14 |
537020801 |
PIN This part replaces 503480001. Price: $2.99 |
| 14 |
66-2990 |
CAP-SPINDLE Price: $13.27 |
| 15 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 15 |
503665901 |
LEVER Price: $3.99 |
| 16 |
256-121 |
WASHER-THRUST Price: $4.55 |
| 16 |
537273401 |
SPRING This part replaces 537020301. Price: $4.99 |
| 17 |
503479701 |
INLET NEEDLE Price: $8.99 |
| 17 |
76-4510 |
DISCONTINUED Price: Call Us |
| 18 |
231-105 |
TIRE-RIBBED Price: $62.56 |
| 18 |
537020801 |
PIN Price: $2.99 |
| 19 |
217-118 |
WHEEL Price: $247.15 |
| 19 |
537012501 |
BALL Price: $2.99 |
| 20 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 20 |
537012601 |
SPRING Price: $2.99 |
| 21 |
254-94 |
BEARING-CONE, TAPERED Price: $8.48 |
| 21 |
537020901 |
CHOKE SHAFT Price: $8.99 |
| 22 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 22 |
537370301 |
CHOKE CAP Price: $6.99 |
| 23 |
32136-5 |
NUT-HEX, SLOTTED Price: $2.71 |
| 23 |
503481801 |
SCREW Price: $2.99 |
| 24 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 24 |
503481901 |
BUSHING Price: $5.99 |
| 25 |
537049001 |
LEVER Price: $2.99 |
| 26 |
5108 |
VALVE This part replaces 232-35. Price: $6.29 |
| 26 |
537021001 |
SPRING Price: $2.99 |
| 27 |
253-129 |
SEAL Price: $21.73 |
| 27 |
503755301 |
SCREW * Price: $2.99 |
| 28 |
100-6598 |
PIVOT-STEERING This part replaces 76-4810. Price: $314.27 |
| 28 |
537019601 |
SHAFT Price: $6.99 |
| 29 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 29 |
537019901 |
THROTTLE FLAP Price: $3.99 |
| 30 |
21-0151 |
LH BALL JOINT ASM Price: $126.28 |
| 30 |
503479201 |
SCREW Price: $2.99 |
| 31 |
3220-12 |
NUT-HEX JAM LH Price: $1.83 |
| 31 |
537019701 |
SPRING THROTTLE Price: $2.99 |
| 32 |
503478901 |
SPACER Price: $3.99 |
| 32 |
63-6880 |
TIE ROD-STEERING Price: $50.74 |
| 33 |
3220-5 |
NUT-JAM Price: $0.65 |
| 33 |
537019801 |
LEVER Price: $3.99 |
| 34 |
21-0141 |
RH BALL JOINT ASM Price: $109.12 |
| 34 |
503479001 |
SCREW Price: $2.99 |
| 35 |
537020601 |
NEEDLE HIGH SPEED Price: $3.99 |
| 35 |
76-4520 |
DISCONTINUED Price: Call Us |
| 36 |
537127801 |
LOW SPEED NEEDLE Price: $14.99 |
| 36 |
67-7300 |
SCREW-HH Price: $81.39 |
| 37 |
503974001 |
WASHER Price: $2.99 |
| 37 |
76-3000-03 |
REAR AXLE ASM This part replaces 76-3000. Price: $1,003.02 |
| 38 |
32153-6 |
NUT-LOCK Price: $3.46 |
| 38 |
503994301 |
SPRING This part replaces 503480801. Price: $2.99 |
| 39 |
537021601 |
CAP Price: $2.99 |
| 39 |
67-7250 |
SPACER-RING Price: $3.32 |
| 40 |
115-4525 |
CYLINDER ASM This part replaces 76-2070. Price: $1,342.36 |
| 40 |
537021601 |
CAP Price: $2.99 |
| 41 |
328-25 |
SCREW-HH Price: $4.07 |
| 43 |
3220-3 |
NUT-HJ Price: $0.28 |
| 44 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 45 |
237-78 |
O-RING Price: $3.85 |
| 46 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 47 |
237-21 |
O-RING Price: $0.70 |
| 48 |
56-2460 |
WASHER-FLAT Price: $3.32 |
| 49 |
32128-45 |
NUT-HHF Price: $7.67 |
| 50 |
302-62 |
FITTING-GREASE Price: $1.34 |
| 51 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 52 |
67-9410 |
WASHER Price: $2.04 |
| 53 |
32151-77 |
RING-RETAINING, EXTERNAL Price: $4.07 |
| 54 |
76-2980 |
WASHER-THRUST Price: $5.08 |
| 55 |
76-2970 |
BUSHING-STRAIGHT Price: $9.02 |
