| Ref | Part Number | Description |
|---|
| MK20FRD |
Mulcher |
Price: Call Us MK20FRD |
| 1 |
323-6 |
SCREW-HH Price: $0.66 |
| 1 |
532086902 |
Control Bar (AYP part number) Price: $4.99 |
| 2 |
532125338 |
UPPER HANDLE This part replaces 532125306. Price: $17.99 |
| 2 |
94-2703 |
PLUG Price: $1.86 |
| 3 |
112-6967 |
O-RING Price: $2.70 |
| 3 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532125160. Price: $54.99 |
| 4 |
120-5118 |
SHAFT-ADJUSTER Price: $44.64 |
| 4 |
532194788 |
GUIDE.ROPE.STD.BLK.ZIN This part replaces 532132001. Price: $3.99 |
| 5 |
106-5344 |
BUSHING-FLANGE, KEYED Price: $2.37 |
| 5 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 532063601. Price: $1.99 |
| 6 |
119-4067 |
SCREW-HH Price: $0.81 |
| 6 |
532183724 |
KNOB.HANDLE.KIT.SERVICE This part replaces 532131959. Price: $6.99 |
| 7 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $3.99 |
| 7 |
99-2097 |
DETENT Price: $12.71 |
| 8 |
120-5116 |
WASHER-WAVE Price: $9.17 |
| 8 |
532158755 |
SCREW.PAN.HEAD This part replaces 532144929. Price: $3.99 |
| 9 |
108-0015 |
WASHER-FLAT Price: $0.39 |
| 9 |
532700644 |
Throttle Control (AYP part number) Price: $9.99 |
| 10 |
137-6130 |
SCREW-ADJUSTER, BEDBAR This part replaces 115-7039. Price: $25.42 |
| 11 |
119-4155 |
WASHER-HARDENED Price: $4.16 |
| 11 |
532130861 |
Engine Zone Control Cable Price: $8.99 |
| 12 |
120-5120 |
SPRING-COMPRESSION Price: $2.89 |
| 12 |
817021008 |
Screw, Hex Hd. Tap #10-24 x 1/2 (AYP part number) This part replaces 532750097. Price: $1.99 |
| 13 |
119-4039 |
NUT-HEX, NI Price: $0.28 |
| 13 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $3.99 |
| 14 |
532128638 |
Wing Nut (AYP part number) Price: $3.99 |
| 15 |
107-3273-01 |
BEDBAR Price: $303.02 |
| 15 |
532051793 |
Hairpin Cotter (AYP part number) Price: $3.99 |
| 16 |
119-4151 |
SCREW-BEDKNIFE Price: $0.41 |
| 16 |
532125035 |
Rear Baffle (AYP part number) This part replaces 532700063. Price: $9.99 |
| 17 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 18 |
532086344 |
Self Tapping Screw #10-24 x 1/2 (AYP part number) Price: $3.99 |
| 19 |
532138865 |
Back Plate (AYP part number) Price: $14.99 |
| 20 |
532138866 |
Side Baffle (AYP part number) Price: $3.99 |
| 21 |
532188984 |
SKIRT.REAR.20RD This part replaces 532140657. Price: $11.99 |
| 21 |
61-1950 |
WASHER-PLASTIC Price: $0.55 |
| 22 |
532133188 |
This part replaces 532125378. Price: $4.64 |
| 22 |
56-9520 |
BUSHING-FLANGED Price: $2.15 |
| 23 |
532147613 |
Rear Door Assembly Kit (AYP part number) Price: $20.80 |
| 23 |
69-8980 |
WASHER Price: $0.58 |
| 24 |
106-9623 |
BOLT-BEDBAR Price: $18.27 |
| 24 |
873680600 |
LOCKNUT This part replaces 532751592. Price: $1.99 |
| 25 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 25 |
532142008 |
Handle Bracket Assembly (Left) (AYP part number) Price: $6.99 |
| 26 |
323-12 |
SCREW-HH Price: $1.14 |
| 26 |
532142007 |
Handle Bracket Assembly (Right) (AYP part number) Price: $6.99 |
| 27 |
108-4269-01 |
WEIGHT Price: $146.07 |
| 27 |
532055187 |
Screw 5/16-18 x 3/4 (AYP part number) Price: $3.99 |
| 28 |
107-2954 |
NUT-ADJUSTER, BEARING Price: $17.63 |
| 29 |
532139901 |
Wheel Adjusting Bracket (AYP part number) Price: $5.99 |
| 29 |
93-2489 |
BEARING Price: $24.37 |
| 30 |
107-4028 |
SEAL-GREASE Price: $21.51 |
| 30 |
532084920 |
Spacer (AYP part number) Price: $1.99 |
| 32 |
137-8439 |
ES REEL+,7IN FWY(22)11 BLD(FSR) This part replaces 127-0294. Price: $847.09 |
| 32 |
532141730 |
Selector Spring (AYP part number) Price: $3.99 |
| 33 |
532087877 |
Selector Knob (AYP part number) Price: $2.99 |
| 34 |
532187930 |
ARM.ASM.AXLE. This part replaces 532125172. Price: $9.99 |
| 35 |
532062335 |
Belleville Washer (AYP part number) Price: $6.99 |
| 36 |
3296-33 |
NUT-LOCK, NI Price: $2.39 |
| 36 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532142748. Price: $3.99 |
| 37 |
532752005 |
Wheel Assembly (AYP part number) Price: $3.33 |
| 38 |
137-6093 |
BEDKNIFE-EDGEMAX LOWCUT This part replaces 127-7132. Price: $166.88 |
| 38 |
532052160 |
Washer (AYP part number) Price: $3.99 |
| 39 |
532085179 |
Retainer Clip (AYP part number) Price: $3.99 |
| 40 |
532800090 |
Hubcap (AYP part number) Price: $1.26 |
| 41 |
532088652 |
Hinge Screw (AYP part number) Price: $3.99 |
| 43 |
532054583 |
Hex Tapping Screw 1/4-20 x 1/2 (AYP part number) Price: $3.99 |
| 45 |
532150406 |
BOLT 3/8-16X1-1/8 This part replaces 532850998. Price: $3.99 |
| 46 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $4.99 |
| 51 |
532125311 |
Front Baffle (AYP part number) Price: $10.83 |
| 52 |
532147923 |
Housing Assembly (Incl. Ref. #46) Price: Call Us |
| 53 |
532851084 |
Hex Head Screw 3/8-24 x 1-3/8 Grd. 8 Price: $2.99 |
| 54 |
539990118 |
SLW 3/8 STD This part replaces 532850263. Price: $1.99 |
| 55 |
532851074 |
Hardened Washer (AYP part number) Price: $2.99 |
| 57 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532850977. Price: $11.99 |
| 65 |
532083816 |
Screw #10 x 5/8 (AYP part number) Price: $3.99 |
| 67 |
532148718 |
Grass Bag (AYP part number) Price: Call Us |
| 68 |
532088614 |
Catcher Frame Price: $39.99 |
| 72 |
532128415 |
Pop Rivet (AYP part number) Price: $2.99 |
