| Ref | Part Number | Description |
|---|
| 1 |
96512 |
STEERING C Not Available Price: |
| 2 |
9462 |
CAP-YELLOW Price: Call Us |
| 2A |
9248 |
CAP-BATTERY WHITE (PONY) Price: Call Us |
| 3 |
9009 |
TUBE-VENT BATTERY/HSE Price: Call Us |
| 4 |
1475 |
TUBING-RUBBER Price: Call Us |
| 5 |
9224 |
CLAMP Price: Call Us |
| 6 |
710-0599 |
SCREW 1/4-20 X.500 This part replaces 9552. Price: $3.86 |
| 7 |
11361 |
HDW PKG-BATTERY TERMINAL Price: Call Us |
| 8 |
925-0267B |
Ignition Switch This part replaces 1908112. Price: $33.31 |
| 9 |
1904570 |
KEY SWITCH W/DECAL Not Available Price: |
| 10 |
777S30648 |
Label, Ignition Switch This part replaces 1904548. Price: $4.25 |
| 11 |
925-0201 |
Key This part replaces 96520. Price: $8.70 |
| 12 |
96509 |
BATTERY CABLE Not Available Price: |
| 13 |
GW-96510 |
Cable (solenoid to starter motor) This part replaces 96510. Price: $10.43 |
| 15 |
GW-97020 |
BOOT-BATTERY CABLE Not Available This part replaces 97020. Price: |
| 16 |
GW-96514099 |
Solenoid (Incl. Nuts and Washers for Cables and Wires) This part replaces 96514. Price: $42.19 |
| 17 |
GW-20837 |
BATTERY BRACKET Not Available This part replaces 20837. Price: |
| 18 |
1186023 |
NUT-WELD 5/16-18 Price: Call Us |
| 19 |
710-04048 |
SCREW 5/16-18 x 1 GR5 This part replaces 1186331. Price: $4.19 |
| 20 |
736-0607 |
External L-Washer 5/16 This part replaces 1177548. Price: $3.66 |
| 21 |
1186389 |
NUT-HF/LK 1/4-20 ZP Price: $3.05 |
| 22 |
936-0119 |
LOCK WASHER 5/16 This part replaces 1100242. Price: $4.29 |
| 23 |
912-3057 |
NUT-5/16X 24 This part replaces 1186211. Price: $5.94 |
| 24 |
GW-9853 |
Sems Nut This part replaces 9853. Price: $6.01 |
| 25 |
N/A |
LOCKWASHER |
| 26 |
N/A |
NUT |
| 27 |
1901894 |
WIRE ASSEMBLY-RECHARGI Not Available Price: |
| 28 |
9218 |
CLIP-SPECIAL Price: Call Us |
| 29 |
GW-9265 |
TIE-TWIST LOCK Not Available This part replaces 9265. Price: |
