| Ref | Part Number | Description |
|---|
| 1 |
52-2930 |
BOLT-SHOULDER Price: $22.99 |
| 2 |
3220-6 |
NUT-JAM Price: $1.25 |
| 3 |
52-2860 |
WASHER Price: $0.84 |
| 4 |
52-2900 |
WASHER-PLASTIC Price: $0.75 |
| 5 |
66-7240 |
SCREW-PIVOT Price: $23.00 |
| 7 |
77-0330 |
HOUSING-PIVOT Price: $55.40 |
| 8 |
77-0350 |
WASHER-THRUST, NYLON Price: $1.42 |
| 10 |
257-5 |
WASHER-THRUST Price: $1.83 |
| 11 |
66-7220 |
ARM-SPRING Price: $17.78 |
| 12 |
77-0300-01 |
HANDLE ASM This part replaces 77-0300. Price: $72.03 |
| 14 |
324-25 |
SCREW-HH Price: $9.84 |
| 15 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 16 |
302-18 |
FITTING-GREASE Price: $3.46 |
| 17 |
107-7409 |
PIN-PIVOT, BEDBAR This part replaces 57-5260. Price: $33.41 |
| 18 |
52-2890 |
BUSHING-NYLON Price: $2.49 |
| 19 |
62-5510 |
BUSHING-RUBBER Price: $7.42 |
| 20 |
57-4940-01 |
BEDBAR This part replaces 57-4940. Price: $287.88 |
| 21 |
119-4153 |
RUBBER BUSHING ASM This part replaces 63-9510. Price: $6.66 |
| 22 |
119-4151 |
SCREW-BEDKNIFE This part replaces 57-4910. Price: $0.41 |
| 23 |
93-4263 |
BEDKNIFE-TOURNAMENT CUT This part replaces 63-8560. Price: $62.54 |
| 24 |
52-2910 |
BOLT-ECCENTRIC Price: $43.15 |
| 25 |
66-7230 |
SPRING-COMPRESSION Price: $9.25 |
| 26 |
77-0490 |
DECAL-BOLT, ECCENTRIC Price: $2.31 |
| 535051101 |
535051101 |
SPACER Price: $27.99 |
| 535057701 |
535057701 |
DAMPER Price: $9.99 |
| 535057702 |
535057702 |
DAMPER Price: $9.99 |
| 535059001 |
535059001 |
POST FRONT DAMPER Price: $149.99 |
| 535087601 |
575231701 |
WHEEL, FRONT This part replaces 535087601. Price: $19.99 |
| 535087701 |
535087701 |
AXLE, FRONT WHEEL Price: $13.79 |
| 535087801 |
535087801 |
WASHER, SEALING Price: $2.99 |
| 535090701 |
535103101 |
BRACKET This part replaces 535090701. Price: $17.14 |
| 535091201 |
535091201 |
RETAINER, AXLE CAP Price: $2.99 |
| 535092401 |
535092401 |
FRONT WHEEL ASSY W/AXLE Price: $52.51 |
| 732251201 |
588222101 |
HEXAGON NUT FLANGE M4 A2-70 This part replaces 732251201. Price: $2.99 |
| 734113741 |
734113741 |
WASHER Price: $3.99 |
| 738229555 |
738229555 |
BEARING Price: $7.99 |
