| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 1 |
593898602 |
PLATE ENGINE; RZ, 23IN BLACK This part replaces 588017102. Price: $149.99 |
| 2 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $229.99 |
| 2 |
62-7240 |
DISCONTINUED Price: Call Us |
| 3 |
583955701 |
TUBE.EXHAUST.RH.FR961/FR730 Price: $24.99 |
| 3 |
62-7300 |
CHAIN Price: $9.30 |
| 4 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 4 |
583955601 |
TUBE.EXHAUST.LH.FR961/FR730 Price: $24.99 |
| 5 |
282-4 |
SHACKLE Price: $32.98 |
| 5 |
581886702 |
BRACKET MUFFLER MS431BLK Price: $19.99 |
| 6 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 6 |
583593901 |
ARM.IDLER This part replaces 532448145. Price: $11.99 |
| 7 |
582538902 |
SPINDLE.IDLER This part replaces 582538901. Price: $4.99 |
| 7 |
61-2930 |
DISCONTINUED Price: Call Us |
| 8 |
323-7 |
SCREW-HH Price: $0.65 |
| 8 |
531350601 |
PULLEY IDLER, BACKSIDE 3 INCH This part replaces 539110311. Price: $19.99 |
| 9 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 9 |
587537401 |
PULLEY.ENGINE Price: $22.99 |
| 10 |
3256-45 |
WASHER-FLAT Price: $0.28 |
| 10 |
587660101 |
SPACER.SPACER.625 W/OGURA.LCC Price: $5.99 |
| 11 |
539132859 |
HEAT SHIELD Price: $22.99 |
| 11 |
76-0250 |
BELT TENSIONER ASSY Price: $465.39 |
| 12 |
587633302 |
CLUTCH.STOP.OGURA LCC.BLACK Price: $7.99 |
| 12 |
76-0370 |
BOLT ASSY Price: $26.50 |
| 13 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 13 |
587451202 |
GUARD.MUFFLER.WO.TOW.HITCHX431 Price: $44.99 |
| 14 |
283-40 |
PIN-CLEVIS Price: $2.85 |
| 14 |
539131604 |
MUFFLER ASM TWIN Price: $39.99 |
| 15 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 15 |
547878302 |
SPRING BELT TENSIONER BLACK This part replaces 532196105. Price: $5.99 |
| 16 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 16 |
584825501 |
HOSE.ASSEMBLY.OIL.DRAIN Price: $27.99 |
| 17 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 17 |
539101363 |
CLAMP Price: $2.99 |
| 18 |
522599003 |
ADAPTER This part replaces 522599001. Price: $8.99 |
| 18 |
62-7250 |
VINYL SLEEVE Price: $32.91 |
| 19 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 19 |
585807101 |
PLUG OIL DRAIN Price: $2.99 |
| 20 |
283-1 |
PIN-CLEVIS Price: $1.63 |
| 20 |
501603701 |
BEARING.FLANGED.PLASTIC.3/4ID Price: $5.99 |
| 21 |
582539502 |
Bolts This part replaces 582539501. Price: $5.99 |
| 21 |
61-3820 |
DISCONTINUED Price: Call Us |
| 22 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 22 |
596433901 |
Screws This part replaces 874520656. Price: $2.99 |
| 23 |
322-4 |
SCREW-HH Price: $0.35 |
| 23 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 24 |
55-4300 |
DECAL-WARNING Price: $13.99 |
| 24 |
595901501 |
Bolts This part replaces 872140508. Price: $3.99 |
| 25 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 25 |
581332806 |
Bolts This part replaces 581332803. Price: $6.99 |
| 26 |
596637301 |
Screws This part replaces 817490410. Price: $2.99 |
| 26 |
61-3000 |
SHAFT Price: $102.19 |
| 27 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 27 |
596918101 |
Bolts This part replaces 539976949. Price: $2.99 |
| 28 |
325-4 |
SCREW-HH Price: $0.95 |
| 28 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 817490512. Price: $3.99 |
| 29 |
521991102 |
NUT 1/2-13 HEX FLANGE NYLOK CL This part replaces 521991101. Price: $3.99 |
| 29 |
61-2890 |
DISCONTINUED Price: Call Us |
| 30 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 30 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 539112899. Price: $5.99 |
| 31 |
3290-322 |
PIN-HAIR Price: $1.09 |
| 31 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 32 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 32 |
HY4486 |
NUT UNF 1/2"NYLOC EXT THIN5/16 This part replaces 283-8. Price: $1.36 |
| 33 |
3272-17 |
PIN-COTTER Price: $1.79 |
| 33 |
532126197 |
WASHER Price: $6.99 |
| 34 |
3253-7 |
WASHER-LOCK Price: $0.27 |
