| Ref | Part Number | Description |
|---|
| 1 |
117-0158 |
LIFT CONTROL MANIFOLD ASM Price: $1,840.83 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 2 |
117-0180 |
HOSE-HYD Price: $95.39 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
163-3531 |
CYLINDER-HYDRAULIC This part replaces 119-6989. Price: $517.81 |
| 4 |
119-6990 |
HYD CYLINDER ASM Price: $562.41 |
| 5 |
119-6991 |
HYD CYLINDER ASM Price: $562.41 |
| 6 |
117-0253 |
HOSE-HYD Price: $109.19 |
| 7 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 8 |
532007603 |
TRAY.BATTERY This part replaces 532124886. Price: $5.99 |
| 8 |
92-5694 |
HOSE-HYDRAULIC Price: $92.15 |
| 9 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 10 |
117-0262 |
HOSE-HYD Price: $135.67 |
| 10 |
532150177 |
BATTERY TIEDOWN KIT This part replaces 532145211. Price: $8.99 |
| 11 |
117-0261 |
HOSE-HYD Price: $133.49 |
| 11 |
532150109 |
BATTERY HOLDDOWN FRONT MOUNT Price: $4.99 |
| 12 |
532150177 |
BATTERY TIEDOWN KIT This part replaces 532145769. Price: $8.99 |
| 12 |
85-4940 |
HOSE-HYD Price: $103.60 |
| 13 |
2412-137 |
CLAMP-R, DOUBLE Price: $5.08 |
| 14 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 15 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 16 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
117-0148 |
PIN-CYLINDER Price: $52.54 |
| 18 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 19 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 20 |
104-0046 |
PIN-SLIDE, CYLINDER Price: $10.19 |
| 21 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 21 |
532175688 |
HARNESS.W/LIGHT SOCKET Price: $29.99 |
| 22 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
323-9 |
SCREW-HH Price: $1.29 |
| 24 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 25 |
532146148 |
CABLE BATTERY 6 GA 22" W/16W Price: $11.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $12.99 |
| 30 |
532175566 |
IGNITION SWITCH Price: $22.99 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 40 |
532188024 |
HARNESS.IGNITION Price: $119.99 |
| 41 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532178861. Price: $19.99 |
| 46 |
532169642 |
KIT.HOURMETER.SNAP-IN This part replaces 532169635. Price: $109.99 |
| 48 |
532140844 |
ADAPTER.AMMETER Price: $4.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 51 |
532140405 |
FRAME RETAINING RING Price: $3.99 |
| 55 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 89 |
532169639 |
BRACKET SNAP-IN HOURMETER Price: $4.99 |
