| Ref | Part Number | Description |
|---|
| 1 |
104-8219 |
GRASS BASKET ASM This part replaces 75-4010. Price: $331.12 |
| 1 |
532150383 |
RAIL KIT This part replaces 532144737. Price: $99.99 |
| 2 |
323-6 |
SCREW-HH Price: $0.66 |
| 2 |
532175282 |
DRAWBAR, GT This part replaces 532140506. Price: $59.99 |
| 3 |
532140676 |
PANEL LH This part replaces 532143364. Price: $45.27 |
| 3 |
75-4030-03 |
SUPPORT-BASKET, LH This part replaces 75-4030. Price: $12.56 |
| 4 |
75-3930 |
PIN-BASKET Price: $17.00 |
| 4 |
873680700 |
Nut, Crownlock 7/16-14 Unc Price: $2.99 |
| 5 |
32121-11 |
PIN-ROLL Price: $0.47 |
| 5 |
532140452 |
DASH Price: $32.53 |
| 6 |
322-6 |
SCREW-HH Price: $0.45 |
| 6 |
532145053 |
DASH, LOWER Price: $69.99 |
| 7 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 7 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 8 |
3256-71 |
WASHER-FLAT Price: $0.81 |
| 8 |
532145166 |
SUPPORT, BATTERY Price: $4.69 |
| 9 |
75-3970 |
SPRING-TORSION, RH Price: $26.75 |
| 10 |
75-3940 |
COLLAR-BASKET Price: $3.80 |
| 11 |
75-3950-03 |
BRACKET-BASKET This part replaces 75-3950. Price: $29.53 |
| 12 |
75-3920 |
GUIDE-BASKET Price: $11.33 |
| 13 |
322-1 |
SCREW-HH Price: $0.22 |
| 14 |
3269-28 |
RIVET-POP Price: $0.47 |
| 14 |
532125454 |
HOOD.HUSQVARNA.ORANGE Price: $361.99 |
| 15 |
532157068 |
LENS LH This part replaces 532124250. Price: $13.99 |
| 15 |
75-4040-03 |
PLATE-BASKET, LH This part replaces 75-4040. Price: $18.18 |
| 16 |
532121794 |
COVER ACCESS Price: $3.99 |
| 17 |
534200501 |
BOLT HEX PATCH 3/8-16X3/4 This part replaces 817490612. Price: $1.99 |
| 18 |
532157236 |
GRILLE.ASM.HUSQVARNA.YTGT This part replaces 532127320. Price: $119.99 |
| 19 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 20 |
596564401 |
Bolts This part replaces 874760616. Price: $3.99 |
| 21 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 22 |
532140677 |
SIDE PANEL RH This part replaces 532143365. Price: $39.61 |
| 23 |
817000616 |
SCREW 3/8-16X1 This part replaces 817490616. Price: $5.99 |
| 24 |
532145243 |
FOOTREST LT/YT/GT RH This part replaces 532147202. Price: $9.15 |
| 25 |
532157069 |
LENS.RH.HUSQVARNA.YTGT.CL This part replaces 532124251. Price: $12.99 |
| 27 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 28 |
532127203 |
Footrest, LH Price: Call Us |
| 29 |
532145205 |
DASH SUPT YP Price: $7.99 |
| 30 |
532148411 |
SADDLE Price: $5.99 |
| 31 |
532145183 |
BRACE, SUPPORT STEERING Price: $4.35 |
| 32 |
532141315 |
FRAME PIVOT BRKT ASSY LH Price: $7.99 |
| 33 |
532141314 |
FRAME PIVOT BRKT ASSY RH Price: $7.99 |
| 34 |
532142131 |
ENGINE SUPPORT BRKT Price: $3.99 |
| 35 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 36 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874780512. Price: $3.99 |
| 37 |
532121642 |
FENDER This part replaces 532124927. Price: $131.32 |
| 38 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 39 |
532136961 |
FRONT AXLE BRACKET Price: $8.84 |
| 40 |
532156111 |
BRACKET, SUPPORT AXLE/ENGINE This part replaces 532142132. Price: $9.99 |
| 43 |
532136939 |
FRONT SUSPENSION BRKT LH Price: $12.99 |
| 44 |
532136940 |
FRONT SUSPENSION BRKT RH Price: $12.99 |
| 45 |
532155887 |
KIT.SERV.R.H.CHASSIS BRKT/HDW This part replaces 532138460. Price: $17.99 |
| 46 |
596204201 |
Washers This part replaces 819091216. Price: $2.99 |
| 47 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 50 |
532136575 |
CHASSIS BRKT Price: $7.82 |
| 52 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 54 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 56 |
532155886 |
KIT.SERV.LH.CHASSIS BRKT/HDW This part replaces 532138461. Price: $7.99 |
| 57 |
532108067 |
PAL NUT LT Price: $3.10 |
| 58 |
532183569 |
BRACKET ASM., FENDER This part replaces 532137113. Price: $9.99 |
| 60 |
874760620 |
BOLT This part replaces 817490620. Price: $4.99 |
| 63 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 65 |
532149577 |
Strap, Asm. Hinge Front Price: Call Us |
| 67 |
532140737 |
BELT GUIDE Price: $3.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 70 |
532177679 |
KEEPER, BELT VGT GROUND This part replaces 532137159. Price: $4.99 |
| 72 |
874180512 |
Screw, Mach Trhd 5/16-18 x 3/4 Price: $3.99 |
| 73 |
532306781 |
Strap, Asm. Hinge Rear Price: Call Us |
| 74 |
871191008 |
SCREW.PNHD.10-24 This part replaces 874191008. Price: $7.99 |
| 75 |
810071000 |
LOCKWASHER #10 Price: $3.99 |
| 76 |
596987401 |
Nuts This part replaces 532125004. Price: $2.99 |
| 79 |
874981024 |
SCREW.PAN.HEAD This part replaces 874981020. Price: $4.99 |
| 80 |
532007206 |
SPACER LT Price: $5.99 |
| 81 |
819070818 |
WASHER Price: $5.99 |
| 82 |
873271000 |
NUT This part replaces 873731000. Price: $2.99 |
| 84 |
532142992 |
MOWER STOP Price: $4.99 |
| 85 |
532193923 |
BRKT.SUPPT This part replaces 532144911. Price: $6.99 |
| 86 |
596238601 |
Bolts This part replaces 874760716. Price: $2.99 |
| 88 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 90 |
596238701 |
Washers This part replaces 811050600. Price: $3.99 |
| 91 |
532151630 |
RAIL KIT This part replaces 532144735. Price: $82.46 |
| 92 |
532140130 |
PLATE, SILKSCR. This part replaces 532141626. Price: $7.04 |
| 94 |
532100207 |
CLIP GTV Price: $3.99 |
| 95 |
532105531 |
NUT-PUSH YT Price: $2.99 |
| 106 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $3.99 |
| 107 |
532109808 |
LATCH.HOOD. Price: $5.99 |
| 108 |
532110356 |
SNAP CAP LT Price: $3.99 |
| 109 |
532110357 |
WASHER LT Price: $2.99 |
| 110 |
532140625 |
GRILL SUPPORT ASSY Price: $91.16 |
| 111 |
532127316 |
RETAINER Price: $3.12 |
| 113 |
532146525 |
NUT.WING.LCK.NYL.NOTCH.1/4-20 This part replaces 532123198. Price: $3.99 |
| 114 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 115 |
954040608 |
This part replaces 532141460. Price: $51.95 |
| 116 |
532170310 |
BUMPER BRACKET This part replaces 532141461. Price: $4.99 |
| 117 |
532143679 |
PLUG PLASTIC Price: $2.99 |
| 118 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 119 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 120 |
596140201 |
Washers This part replaces 819131616. Price: $2.99 |
| 123 |
532007605 |
BOLT This part replaces 532123481. Price: $4.99 |
| 124 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
