| Ref | Part Number | Description |
|---|
| 1 |
532429673 |
RB KIT.CNTL.CHUTE.ROTA.GRY.SNO This part replaces 532428274. Price: $139.99 |
| 1 |
58-2800 |
BUSHING Price: $16.22 |
| 1 |
703-1550A |
FRAME ASSEMBLY Not Available Price: |
| 2 |
60-3720 |
PIN-ROLL Price: $2.43 |
| 2 |
703-1119-0498 |
DRAWBAR Not Available This part replaces 703-1119. Price: |
| 2 |
817501010 |
SCREW #10-24 X 5/8 Price: $4.99 |
| 3 |
58-2810 |
ROD Price: $77.22 |
| 3 |
759-3457 |
COVER, FRAME W/GRAPHIC Not Available Price: |
| 4 |
3256-7 |
WASHER-FLAT Price: $0.75 |
| 4 |
703-1964-4021 |
FRONT DECK BRACKET (CUB YELLOW 2) Not Available This part replaces 703-1964. Price: |
| 5 |
48-6780 |
SPRING-COMPRESSION Price: $28.08 |
| 5 |
703-1297 |
DECK SUPPORT ROD Not Available Price: |
| 6 |
60-1240 |
SPRING Price: $37.47 |
| 6 |
736-0169 |
Washer, Lock, 3/8 Price: $3.33 |
| 7 |
60-6660 |
NUT Price: $4.07 |
| 7 |
710-0216 |
Bolt, 3/8 X 3/4 Type 5 This part replaces 710-3000. Price: $3.93 |
| 8 |
703-1535 |
BRACKET-LIFT SHAFT Not Available Price: |
| 8 |
76-3470-03 |
EXHAUST ASM This part replaces 76-3470. Price: $781.13 |
| 9 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 9 |
710-3008 |
SCREW 5/16-18 x .75 GR5 Price: $3.76 |
| 10 |
936-0119 |
Washer, Lock, 5/16 This part replaces 736-0119. Price: $4.29 |
| 11 |
712-3010 |
HEX NUT 5/16-18 This part replaces 7123010. Price: $3.89 |
| 11 |
74-2850 |
SILENCER ASM Price: $669.97 |
| 12 |
323-9 |
SCREW-HH Price: $1.29 |
| 13 |
2412-132 |
CLAMP, T-BOLT Price: $15.50 |
| 16 |
58-6520 |
DECAL-GREASE Price: $2.57 |
| 17 |
58-5910 |
DISCONTINUED Price: Call Us |
| 17 |
93-9405 |
DECAL-PRESSURE, AIR Price: $9.81 |
| 18 |
33116-030 |
SCREW-HH This part replaces 60-6870. Price: $1.56 |
| 19 |
48-7080 |
GRIP-PLASTIC Price: $7.04 |
| 20 |
86-6570-03 |
LATCH This part replaces 86-6570. Price: $157.07 |
| 21 |
51-2070 |
NUT Price: $0.68 |
| 22 |
82-4910 |
ROLLER Price: $26.42 |
| 23 |
51-2060 |
WASHER Price: $0.68 |
| 24 |
60-0160 |
PIN Price: $39.08 |
| 25 |
60-2110 |
PIN Price: $1.42 |
| 26 |
48-8830 |
PIN-EXPANSION Price: $1.52 |
| 27 |
48-8850 |
SPRING-DISC Price: $4.79 |
| 28 |
86-6590-03 |
LATCH-LH This part replaces 86-6590. Price: $47.66 |
| 29 |
92-4761 |
DISCONTINUED Price: Call Us |
| 30 |
60-4190-03 |
SHIELD-GRASS, LH This part replaces 60-4190. Price: $45.54 |
| 31 |
60-4200-03 |
SHIELD-GRASS, RH This part replaces 60-4200. Price: $49.14 |
| 32 |
48-6900 |
SCREW Price: $1.52 |
| 33 |
33093-00 |
WASHER-FLAT This part replaces 48-8010. Price: $0.70 |
| 34 |
60-2080 |
CLAMP-HOSE Price: $21.62 |
| 35 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 36 |
48-7680 |
SCREW-HH Price: $0.61 |
| 39 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 40 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 41 |
76-3560 |
CLAMP Price: $5.32 |
| 42 |
3289-25 |
SCREW-SFH Price: $25.39 |
| 43 |
92-4768-03 |
TIEDOWN ASM This part replaces 92-4768. Price: $97.23 |
| 44 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 45 |
92-6059 |
PLUG-BUTTON Price: $0.88 |
| 49 |
321-9 |
SCREW-HH Price: $0.27 |
| 50 |
82-2990 |
CLAMP-HALF Price: $12.30 |
