| Ref | Part Number | Description |
|---|
| 1 |
105-9861 |
STEERING CYLINDER ASM Price: $1,317.06 |
| 1 |
532140779 |
PULLEY.V-GROOVE Price: $24.99 |
| 2 |
532009204 |
NUT STD Price: $2.38 |
| 3 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 3 |
532140607 |
TRANSAXLE.HYDRO.319-0500.LR Price: $556.99 |
| 4 |
74-5700 |
BEARING-NEEDLE, ROLLER Price: $27.84 |
| 4 |
819171912 |
WASHER Price: $3.99 |
| 5 |
32120-15 |
RING-SNAP, EXT Price: $1.20 |
| 5 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 6 |
32120-76 |
RING-SNAP, EXT Price: $0.34 |
| 6 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 7 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 8 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 8 |
596582201 |
Bolts This part replaces 874760524. Price: $2.99 |
| 9 |
325-7 |
SCREW-HH Price: $1.53 |
| 9 |
532146682 |
SPRING,BRAKE RETURN This part replaces 532110422. Price: $5.99 |
| 10 |
106-9888 |
WASHER-FLAT Price: $0.49 |
| 10 |
532121749 |
WASHER Price: $2.99 |
| 11 |
121-3101 |
MOTOR-PISTON Price: $2,639.96 |
| 11 |
532123583 |
SQUARE KEY Price: $3.99 |
| 12 |
237-166 |
O-RING Price: $10.46 |
| 12 |
874760540 |
Bolt, Hex, Fin. 5/16 x 18 UNC x 2-1/2 Price: $2.99 |
| 13 |
104-5663 |
PINION-28T Price: $203.65 |
| 13 |
532140778 |
FAN.TRANSMISSION.HYDRO.6" Price: $5.99 |
| 14 |
104-5664 |
GEAR-44T Price: $267.37 |
| 14 |
596029601 |
Pins This part replaces 876020416. Price: $1.99 |
| 15 |
819212013 |
Washer 21/32 x 1-1/4 x 13 Ga. Price: $2.99 |
| 16 |
734117771 |
BUSHING This part replaces 819171216. Price: $3.99 |
| 17 |
532140763 |
SUPPORT, SHIFT HANDLE Price: $2.42 |
| 17 |
93-5268 |
NUT-LUG Price: $2.20 |
| 18 |
532140769 |
PIN Price: $2.38 |
| 19 |
532140767 |
LINK, SHIFT Price: $2.64 |
| 20 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 20 |
532140773 |
LEVER, SHIFT Price: $2.99 |
| 21 |
32136-14 |
NUT-HST Price: $3.38 |
| 21 |
532156047 |
PIVOT SHAFT This part replaces 532140764. Price: $11.51 |
| 22 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 22 |
92-5836 |
WASHER Price: $5.34 |
| 23 |
110-4750 |
DRIVE AXLE ASM Price: $8,909.28 |
| 23 |
532140845 |
KNOB.DELUXE.(PISTOL.GRIP).BLAC Price: $11.99 |
| 24 |
100-3796 |
SPACER-JOINT, BALL Price: $13.33 |
| 24 |
532140765 |
ROD, SHIFTER Price: $27.99 |
| 25 |
353-989 |
PLUG-HEX, HOLLOW Price: $21.59 |
| 25 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 26 |
32121-110 |
PIN-ROLL, SLOTTED Price: $1.93 |
| 27 |
115-9142 |
PIN-REAR AXLE Price: $103.95 |
| 27 |
532142564 |
LINE FUEL HYD 4" Price: $3.99 |
| 28 |
532140772 |
SPRING, TORSION Price: $19.99 |
| 28 |
92-1765 |
WASHER-THRUST Price: $2.57 |
| 29 |
98-3867 |
WASHER-THRUST Price: $3.21 |
| 30 |
3296-68 |
NUT-LOCK, NI Price: $14.67 |
| 30 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 31 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 31 |
532121199 |
SPACER SPLIT Price: $3.12 |
| 32 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 32 |
532140912 |
ACTUACTOR Price: $8.60 |
| 33 |
33114-025 |
SCREW-HH Price: $0.70 |
| 33 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111216. Price: $2.99 |
| 34 |
596580801 |
Bolts This part replaces 874760516. Price: $2.99 |
| 35 |
812000001 |
E-RING LT Price: $3.99 |
| 36 |
95-7541 |
PLATE-COVER Price: $89.04 |
| 37 |
104-2353 |
PIN-DOWEL Price: $2.17 |
| 38 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 39 |
340-98 |
FITTING-ELBOW, 90 DEG Price: $31.91 |
| 40 |
110-8829 |
SENDER-TEMPERATURE Price: $80.84 |
