| Ref | Part Number | Description |
|---|
| 1 |
196495X421 |
Mower Housing Price: Call Us |
| 1 |
69-5930 |
TUBE-HYD, RH Price: $140.26 |
| 1 |
69-5940 |
TUBE-HYD, LH Price: $140.26 |
| 2 |
340-82 |
FITTING-ELBOW, 90 DEG Price: $20.57 |
| 3 |
340-91 |
FITTING-STR Price: $36.83 |
| 4 |
106-0211 |
HYD HOSE ASM Price: $211.85 |
| 5 |
92-1742 |
TUBE ASM Price: $93.56 |
| 6 |
195186 |
Arm Suspension Price: Call Us |
| 6 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 7 |
191611 |
Screw 10 x 3/4 Single Hex Price: Call Us |
| 7 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 8 |
139775 |
Blade, 42" Mulching Premium (For better wear when mulching) Price: Call Us |
| 8 |
193003 |
Bolt/Washer Asm 7/16-20 unf Price: Call Us |
| 8 |
71-3880 |
CLEVIS Price: $61.78 |
| 9 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 10 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 11 |
134149 |
Blade, 42" Mulching Std (For mulching mowers only) Price: Call Us |
| 11 |
138971 |
Blade, 42" Hi-Lift (For bagging or discharge) Price: Call Us |
| 11 |
323-6 |
SCREW-HH Price: $0.66 |
| 12 |
71-3810 |
COUPLING-MOTOR, HYD Price: $258.45 |
| 13 |
192872 |
Shaft Assembly, Mandrel Price: Call Us |
| 13 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 14 |
187281 |
Housing, Mandrel Price: Call Us |
| 14 |
32120-84 |
RING-SNAP, EXTERNAL Price: $0.61 |
| 15 |
110485X |
Bearing, Ball, Mandrel Price: Call Us |
| 15 |
302-39 |
FITTING-PLUG Price: $10.74 |
| 16 |
174493 |
Stripper, Mower Deck Price: Call Us |
| 16 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 17 |
327-22 |
SCREW-HH Price: $4.41 |
| 18 |
69-9790 |
FRONT WHEEL ASM Price: $708.06 |
| 19 |
196539 |
Bolt, Shoulder Price: Call Us |
| 19 |
72-4070 |
DECAL-DANGER Price: $19.16 |
| 20 |
159770 |
Baffle, Vortex Price: Call Us |
| 20 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 21 |
3219-5 |
NUT-HEX Price: $1.22 |
| 21 |
73680500 |
Nut, Crownlock 5/16-18 unc Price: Call Us |
| 22 |
107-4338-03 |
DRIVE-GEAR, PLANETARY This part replaces 69-1730-03. Price: $4,832.04 |
| 23 |
192557 |
Bracket, Deflector Price: Call Us |
| 23 |
251-340 |
BEARING-BALL Price: $42.56 |
| 24 |
105304X |
Cap, Sleeve Price: Call Us |
| 24 |
253-156 |
SEAL-OIL Price: $32.46 |
| 25 |
197026 |
Spring, Torsion, Deflector Price: Call Us |
| 25 |
323-6 |
SCREW-HH Price: $0.66 |
| 26 |
110452X |
Nut, Push Price: Call Us |
| 27 |
193108X428 |
Shield, Deflector Price: Call Us |
| 27 |
71-3990 |
CAP-HOUSING, BRAKE Price: $310.53 |
| 28 |
71-0470 |
MIDDLE DISC ASM Price: $135.95 |
| 29 |
131491 |
Rod, Hinge Price: Call Us |
| 29 |
71-0460 |
ACTUATING DISC ASM Price: $475.59 |
| 30 |
173984 |
Screw Thdrol Rolling Wsh Hd Price: Call Us |
| 31 |
187690 |
Washer, Spacer Price: Call Us |
| 31 |
71-4010-03 |
DISCONTINUED Price: Call Us |
| 32 |
195945 |
Pulley, Mandrel Price: Call Us |
| 32 |
253-157 |
SEAL-U CUP Price: $36.39 |
| 33 |
237-158 |
O-RING Price: $4.42 |
| 33 |
400234 |
Nut, Toplock, Flanged Price: Call Us |
| 34 |
72110612 |
Bolt Carr Sh. 3/8-16 x 1-1/2 Gr. Price: Call Us |
| 34 |
92-1741 |
TUBE ASM Price: $183.07 |
| 35 |
340-142 |
FITTING-ELBOW-90 Price: $65.90 |
| 36 |
106-0054 |
FITTING-ELBOW, 45 DEG Price: $76.65 |
| 36 |
196106 |
Pulley, Idler, Flat Price: Call Us |
| 37 |
106-0076 |
TUBE-HYD, TRACTION (LH) Price: $139.55 |
| 37 |
19131316 |
Washer 13/32 x 13/16 x 16 Ga. Price: Call Us |
| 38 |
199189 |
Keeper Belt LH Mandrel Price: Call Us |
| 38 |
69-3050 |
MOTOR ASM Price: $4,239.01 |
| 39 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 40 |
325-7 |
SCREW-HH Price: $1.53 |
| 40 |
73900600 |
Nut, Lock Flg. 3/8-16 unc Price: Call Us |
| 41 |
2412-104 |
CLAMP-R Price: $2.37 |
| 42 |
198410 |
Spring Torsion Brake Price: Call Us |
| 42 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 43 |
197256 |
Spring Torsion Retainer Price: Call Us |
| 43 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 44 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 45 |
340-148 |
FITTING-TEE Price: $186.40 |
| 46 |
137729 |
Screw Thd Roll 1/4-20 x 5/8 Price: Call Us |
| 47 |
197250 |
Bracket Clutch Cable Price: Call Us |
| 55 |
197249 |
Arm, Idler Price: Call Us |
| 56 |
199092 |
Spacer, Retainer Price: Call Us |
| 57 |
17000616 |
Screw Hexwsh Thd 3/8-16 x 1 Price: Call Us |
| 59 |
141043 |
Guard, Tuv Idler (94) Price: Call Us |
| 60 |
197402 |
Arm Brake Mower Price: Call Us |
| 62 |
72110616 |
Bolt Rdhd Sqnk 3/8-16 unc x 2 Price: Call Us |
| 63 |
199478 |
Arm Brake Mower Price: Call Us |
| 64 |
199918 |
Linkage Brake Price: Call Us |
| 67 |
198398X421 |
Handle, Clutch Cable Price: Call Us |
| 68 |
197253 |
V-Belt Price: Call Us |
| 69 |
72140505 |
Bolt Rdhd Sqnk 5/16-18 x 5/8 Price: Call Us |
| 70 |
198332 |
Clutch Asm. Manual Price: Call Us |
| 113 |
17000510 |
Screw 5/16-18 Price: Call Us |
| 116 |
4898H |
Bolt Price: Call Us |
| 117 |
188606 |
Wheel Gauge Price: Call Us |
| 118 |
73930600 |
Nut Lock 3/8-16 unc Price: Call Us |
| 119 |
19121414 |
Washer 3/8-7/8 x 14 Ga. Price: Call Us |
| 122 |
197258 |
Keeper Belt Eng. LH Price: Call Us |
| 123 |
197259 |
Keeper Belt Eng. RH Price: Call Us |
| 144 |
199204 |
Keeper Belt Price: Call Us |
| 145 |
177968 |
Pulley Idler Price: Call Us |
| 147 |
401971 |
Spring Return Price: Call Us |
| 152 |
408714 |
Cable Clutch Manual w/Spr. Price: Call Us |
| 188 |
195161 |
Stud Fastener Price: Call Us |
| 189 |
73900500 |
Nut Lock Hex Flange Price: Call Us |
| 192 |
197260 |
Bracket Brake Stand LH Price: Call Us |
| 195 |
17000612 |
Screw Hexwsh Thdr 3/8-16 x 3/4 Price: Call Us |
