| Ref | Part Number | Description |
|---|
| 1 |
114-5401 |
ROLLER-WIEHLE, PLASTIC Price: $248.52 |
| 1 |
530012112 |
Cylinder Price: $3.33 |
| 2 |
114-5403 |
SHAFT-ROLLER, FRONT Price: $82.00 |
| 3 |
114-3717 |
SEAL-OIL Price: $2.77 |
| 3 |
530026681 |
Ring - Piston Price: Call Us |
| 4 |
112-5290 |
BEARING-STEEL, STAINLESS Price: $12.64 |
| 4 |
530015162 |
Retainer - Wrist Pin Price: $1.99 |
| 5 |
112-7494 |
SEAL Price: $6.37 |
| 5 |
530015239 |
Screw - 1/4 - 20 x 3/4 - Hex Soc. Hd. Cylinder Price: $1.99 |
| 6 |
114-5411 |
NUT-LOCK, BEARING Price: $24.46 |
| 7 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 12 |
530026621 |
Spring - Muffler Attachment Price: $1.99 |
| 13 |
502069203 |
Piston Kit (incl. #3, 4, Pin) Price: $17.99 |
| 14 |
530626605 |
Nut - Flywheel Price: $1.99 |
| 15 |
530023817 |
Spring-Starter Dog This part replaces 530042059. Price: $1.99 |
| 18 |
530010844 |
Ass'y. - Crankshaft & Rod Price: $3.33 |
| 19 |
530032092 |
Bearing - Wrist Pin Price: $6.99 |
| 20 |
530015351 |
Washer - Thrust - Crankcase Price: $3.99 |
| 21 |
530032029 |
Bearing - Crankcase Price: $7.99 |
| 22 |
530010757 |
Crankcase Ass'y. (Incl. #21, 23 & Qty. 4 of #28) Price: Call Us |
| 24 |
530010765 |
Drum & Coupling Assembly Price: $3.33 |
| 25 |
530069195 |
Clutch Assembly Kit (incl. Clutch Washer) Price: $9.68 |
| 26 |
530069196 |
Kit - Clutch Washer Price: $3.33 |
| 27 |
530015126 |
Key-Flywheel Price: $1.99 |
| 28 |
530015369 |
Screw - 10 - 24 x 5/8 Fil. Hd. Crankcase Price: $0.04 |
| 29 |
530039114 |
Flywheel Assembly (incl. #15) Price: Call Us |
| 30 |
530015127 |
Washer - Flywheel Price: $1.99 |
| 34 |
530010762 |
Ass'y. Carburetor Housing & Eyelet Price: $3.33 |
| 37 |
530024438 |
Reed Valve Price: Call Us |
| 38 |
530015241 |
Screw - 6 - 19 x 5/16 - Pan Hd. - Reed Valve Price: $1.99 |
| 39 |
530023367 |
Washer - Reed Valve Screw Price: Call Us |
| 45 |
530015566 |
Screw - 10 - 24 x 2-1/4" - Fil. Hd. - Carburetor Price: $0.99 |
| 46 |
530015235 |
Screw - 8 - 18 x 9/16 - Pan. Hd - Carburetor Case Cover Price: Call Us |
| 47 |
530026047 |
Cover - Carburetor Case Price: $3.33 |
| 48 |
530035190 |
Carburetor - WA - 149 - Cable Price: $60.08 |
| 49 |
530015565 |
Screw - 8 x 18 x 1" - Accumulator Price: $3.33 |
| 50 |
530010651 |
Accumulator Assembly (incl. #51 & 54) Price: $3.33 |
| 51 |
530019131 |
O - ring (Orifice) Price: $1.99 |
| 53 |
530021055 |
Fuel Line - Carburetor Price: $1.99 |
| 54 |
530010677 |
Cap Assembly - Accumulator (incl. #56) Price: $3.33 |
| 55 |
530015235 |
Screw - 8 - 16 x 9/16 Price: Call Us |
| 56 |
530019128 |
O - Ring (Accumulator Chamber) Price: $3.33 |
| 57 |
530030054 |
Sealant - Crankcase (not supplied with unit) Price: $17.99 |
